About Sonifex Flashlog 8 Multi Channel Logger, AM/FM/DAB+ and IP Streams Software
The Sonifex Flashlog 8 Multi Channel Logger is a configurable, ultra powerful multi-channel logger which uses the Auricon and Digitorc sound cards, IP based line inputs (Axia or Wheatstone), radio capture cards and internet radio streams, in a rugged, reliable 4U chassis to continuously log up to 2 years of radio broadcasts or audio. Using the PC-DAB1-4 DAB+ multi-ensemble PCIe Radcap card, this latest hard disc logger records the entire contents of up to four ensembles. Decoding occurs during playback, showing DLS text, MOT slide shows and electronic programme guides along with the audio.
But DAB+ isn't all you get with Flashlog 8. Taking advantage of today's powerful multi-core processors and growing hard disc capacities, Flashlog 8 pushes back the barriers on traditional line and radio capture logging with the ability to record up to 64 stereo line channels, 32 stereo FM stations, 32 AM stations, 4 DAB+ ensembles and 32 internet radio streams, limited only by the number of PCIe slots on the motherboard. The number of logging days can be independently set for each line, AM or FM channel and for each DAB+ ensemble. All text fields are Unicode-based, allowing multilingual display and entry. Playback on both the logger and through Flashback 8 supports saving log extracts as MP3 (not available in the USA until 2018) as well as WAV, WMA and AVI files.
Sonifex Flashlog 8 Multi Channel Logger, AM/FM/DAB+ and IP Streams Software Features
- Analogue, AES-3, Axia Livewire and Wheatstone Wheatnet-IP line inputs
- Up to 64 stereo inputs, each reconfigurable as a pair of mono inputs
- Up to four assignable line sub-categories for grouping channels
- Selectable audio compression rates ranging from 80kbps to lossless compression
- Adjustable number of logging days on each input
- Balanced inputs and outputs with XLR breakout cables supplied
- Optional skimming control inputs
- Live input monitoring on logger unit
- Selectable audio failure alarms
- AM and FM Radio Capture: Up to 32 AM stations and 32 FM stations and Adjustable number of logging days on each station
- AM and FM Radio Capture: All FM logging in stereo and Received signal strength, FM stereo pilot and RDS indicators
- AM and FM Radio Capture: Live monitoring on logger unit and FM RDS radiotext logging
- AM and FM Radio Capture: Selectable carrier & audio failure alarms
- DAB+ Radio Capture: Up to four DAB+ ensembles and Adjustable number of logging days on each ensemble
- DAB+ Radio Capture: Entire MSC (main service channel) contents recorded and Decodes legacy MP2 as well as HE-AAC v2 audio compression
- DAB+ Radio Capture: Receiver spectrum display, signal strength and quality indicators and uncorrected error counter
- DAB+ Radio Capture: Displays DLS text, MOT slides and electronic programme guide
- DAB+ Radio Capture: Live monitoring of audio and data
- DAB+ Radio Capture: Selectable ensemble, stream and audio failure alarms
- Internet Stream Capture: Up to 32 internet radio streams and Shoutcast, Icecast and RTMP protocols
- Internet Stream Capture: MP3 and HE-AAC audio encoding & Metadata recording
- Industrial 4U rack mount case and Optional inbuilt Color LCD screen with slide-out keyboard and mouse pad
- Dual redundant hot-swappable power supplies and Inbuilt DVD R/W drive for easy archiving
- Hardware RAID-1 or RAID-5 swappable SATA hard discs with optional hot-standby disc and 64-bit quad-core processor
- Recording time of up to two years, settable on each channel or ensemble (subject to available disc space and dependent on the number of channels and audio compression rate used)
