SolidDrive SD-1 Glass Surface Mount Actuator, Titanium

SKU: SOSD1GTI MFR: SD-1G-TI
Earn VIP Reward Points

Key Features

  • Experience superior sound with the SolidDrive SD-1, a glass surface mount actuator.
  • Enjoy easy installation; simply adhere this titanium SolidDrive to any glass surface.
  • This durable SolidDrive actuator features an anodized aluminum enclosure for longevity.
  • Optimize audio with a wide 120-degree coverage angle from this powerful power supply.
  • Get certified safety: UL1480, UL2043, CE, and RoHS ensure a reliable SolidDrive product.
  • This 8 Ohm impedance SolidDrive system delivers 30W RMS for crystal-clear audio.
See More Product Details
Special Order?Estimated to Ship: 09/15/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$59.99

2 Year

$99.99

3 Year

$159.00

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Learn
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

SolidDrive SD-1 Specifications

  • Color

    Titanium

  • Category

    The Original SolidDrive

  • Certifications

    CE
    RoHS
    UL1480
    UL2043

  • Enclosure Properties

    Anodized Aluminum

  • Source Inputs

    Wire Leads

  • Coverage Angle (-6dB @ 2kHz)

    120 Degree

  • Frequency Response

    +/- 10 dB: 60 Hz - 15 kHz Nominal without EQ
    +/- 3 dB: 80 Hz - 10 kHz Nominal without EQ

  • Magnetically Boosted

    No

  • Max. Continuous Power RMS

    30 W

  • Max. Program Power

    50 W w/ 100 Hz 12 dB octave high-pass

  • Impedance

    Minimum: 8 Ohm
    Nominal: 8 Ohm

  • Dimensions (Diameter x H)

    2.3 x 2.06" (58.42 x 52.32mm)

  • Weight

    1.2 lbs (0.54kg)

  • UPC Code

    644216214303

Related Articles & Videos

Weekend Wrap For July 8, 2011

Weekend Wrap For July 8, 2011

In recent weeks, with the introduction of the Pentax Q, the third generation of the Read more

About SolidDrive SD-1

For audio enthusiasts seeking superior sound quality, the SD-1 Glass Surface Mount Actuator, Titanium, is a game-changer. This innovative device adheres securely to glass and other non-porous surfaces using a double-sided adhesive disk, which is included with your purchase. Each SD-1 unit is meticulously engineered to handle a single channel of audio, ensuring crisp, clear sound every time.

An optional equalization module is available to fine-tune the SD-1 for optimal performance on glass surfaces. This device is a marvel of modern audio technology, employing a patent-pending dual-voice coil system housed within a robust aluminum enclosure. This unique design allows the SD-1 to transfer acoustic energy to any substrate with remarkable efficiency.

The SD-1 Glass Surface Mount Actuator is powered by high-intensity neodymium magnets and dual symmetrically opposed motors. These components work in harmony to convert audio signals into potent vibrations. These vibrations are then transferred directly into solid surfaces, transforming them into large-scale speakers.

The result is high-quality, full-range sound radiating from the entire surface, with a frequency response ranging from 60 Hz to 15 kHz. The symmetrically opposed neodymium magnets, coupled with specially engineered mounting hardware, create hidden planar-source acoustics. This innovative design ensures acoustical uniformity throughout your listening space, providing an immersive audio experience like no other.

SolidDrive SD-1 Features

  • SolidDrive is a patent-pending technol-ogy that utilizes neodymium magnets and dual symmetrically opposed motors to convert audio signals into acoustical energy in a wide variety of substrates.
  • With direct contact to glass, drywall and tabletops, SolidDrive units radiate full-range sound across the entire surface
  • Full-frequency sound can be delivered from 60 Hz - 15 kHz with a max SPL of 88.8 dB and a coverage angle greater than 120 Degree (60 Hz - 3 kHz)
  • Capable of handling 5 - 100 Watts, Solid-Drive units can deliver single to multi-channel audio for home theater, home audio and commercial audio application
  • Patent pending balanced cantilever spring bracket for behind-wall mount-ing allows for a completely hidden speaker system in drywall applications
  • For extended system performance, active and passive subwoofers are available
  • SolidDrives operate in a virtually friction-free environment and are engineered for infinite life

Key Features

  • Experience superior sound with the SolidDrive SD-1, a glass surface mount actuator.
  • Enjoy easy installation; simply adhere this titanium SolidDrive to any glass surface.
  • This durable SolidDrive actuator features an anodized aluminum enclosure for longevity.
  • Optimize audio with a wide 120-degree coverage angle from this powerful power supply.
  • Get certified safety: UL1480, UL2043, CE, and RoHS ensure a reliable SolidDrive product.
  • This 8 Ohm impedance SolidDrive system delivers 30W RMS for crystal-clear audio.

What's in the box:

  • SD-1 Glass Surface Mount Actuator
  • Adhesive Pad
  • Mounting Hardware
  • SolidDrive 7 Year Limited Warranty
