Sony UMC-S3C Specifications

  • Camera type

    Interchangeable lens digital camera

  • Lens mount

    E-mount

  • Lens compatibility

    Sony E-mount lenses

  • Image sensor Type

    35mm full frame Exmor CMOS sensor

  • Number of pixels

    Effective: Approx.12.2Megapixels
    Total: Approx.12.4Megapixels

  • Image sensor aspect ratio

    3:2

  • Color filter

    R, G, B primary color

  • Anti-Dust function

    Yes

  • Anti-Dust system

    Charge protection coating on Optical Filter and ultrasonic vibration mechanism

  • Anti-Dust operation (auto)

    Power off

  • Still Image: Recording format

    JPEG (DCF Ver. 2.0, Exif Ver.2.3, MPF Baseline compliant), RAW (Sony ARW 2.3 format)

  • Still Image: Image size (pixels)

    [3:2]
    35mm full frame:
    L: 4240 x 2832 (12M)
    M: 2768 x 1848 (5.1M)
    S: 2128 x 1416 (3.0M)
    APS-C:
    L: 2768 x 1848 (5.1M)
    M: 2128 x 1416 (3.0M)
    S: 1376 x 920 (1.3M)

    [16:9]
    35mm full frame:
    L: 4240 x 2384 (10M)
    M: 2768 x 1560 (4.3M)
    S: 2128 x 1200 (2.6M)
    APS-C:
    L: 2768 x 1560 (4.3M)
    M: 2128 x 1200 (2.6M)
    S: 1376 x 776 (1.1M)

  • Still Image: Image quality modes

    RAW
    RAW & JPEG
    JPEG Extra fine
    JPEG Fine
    JPEG Standard

  • Still Image: 14bit RAW

    Yes

  • Still Image: Picture Profile

    Yes (Off / PP1-PP9) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset

  • Still Image: Dynamic Range functions

    Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))

  • Still Image: Color space

    sRGB standard (with sYCC gamut)

  • Still Image: Delete

    Yes

  • Movie: Recording format

    XAVC S

  • Movie: Video compression

    XAVC S: MPEG-4 AVC/H.264

  • Movie: Image size (pixels)

    XAVC S 4K: 3810 x 2160
    XAVC S HD: 1920 x 1080

  • Movie: Picture Profile

    Yes (Off / PP1-PP9) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset

  • Movie: Color space

    xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS Color

  • Movie recording system

    (XAVC S 4K)
    3840 x 2160 (29.97P, 100M): Approx. 100 Mbps (NTSC mode)
    3840 x 2160 (25P, 100M): Approx. 100 Mbps (PAL mode)
    3840 x 2160 (23.98P, 100M): Approx. 100 Mbps (NTSC mode)
    3840 x 2160 (29.97P, 60M): Approx. 60 Mbps (NTSC mode)
    3840 x 2160 (25P, 60M): Approx. 60 Mbps (PAL mode)
    3840 x 2160 (23.98P, 60M): Approx. 60 Mbps (NTSC mode)

  • Movie recording system (cont.)

    (XAVC S HD)
    1920 x 1080 (119.88P, 100M): Approx.100Mbps (NTSC mode)
    1920 x 1080 (100P, 100M): Approx.100Mbps (PAL mode)
    1920 x 1080 (119.88P, 60M): Approx.60Mbps (NTSC mode)
    1920 x 1080 (100P, 60M): Approx.60Mbps (PAL mode)
    1920 x 1080 (59.94P,50M): Approx.50Mbps (NTSC mode)
    1920 x 1080 (50P, 50M): Approx.50Mbps (PAL mode)
    1920 x 1080 (29.97P, 50M): 50Mbps (NTSC mode)
    1920 x 1080 (25P,50M): Approx.50Mbps (PAL mode)
    1920 x 1080 (23.98P, 50M): Approx 50Mbps (NTSC mode)

  • High Frame Rate Recording

    1920 x 1080 (29.97P, 16M): Approx.16Mbps (NTSC mode)
    1920 x 1080 (25P, 16M): Approx.16Mbps (PAL mode)
    1920 x 1080 (23.98P, 12M): Approx.12Mbps (NTSC mode)

  • Movie function: PAL/NTSC Selector

    Yes

  • Movie function: TC/UB

    Yes (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec)

  • Movie function: Auto Slow Shutter

    Yes

  • Movie function: REC Control

    Yes

  • Movie function: HDMI Output

    3840 x 2160 (25P)
    1920 x 1080 (50P)
    1920 x 1080 (50i)
    1920 x 1080 (23.98P)
    1920 x 1080 (59.94P)
    1920 x 1080 (59.94i)
    3840 x 2160 (29.97P)
    3840 x 2160 (23.98P),
    YCbCr 4:2:2 8bit / RGB 8bit

  • Media

    SD memory card
    SDHC memory card (UHS-I compliant)
    SDXC memory card (UHS-I compliant)
    microSD memory card
    microSDHC memory card
    microSDXC memory card

  • Memory card slot

    SD memory card

  • File system

    FAT12, 16, 32, exFAT

  • Noise reduction

    Long exposure NR: On/Off , available at shutter speeds longer than 1 sec.
    High ISO NR: Normal/Low/Off

  • Multi Frame NR

    Auto/ISO 100 to 409600

  • White balance: Modes

    Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent / Flash /Underwater/ Color Temperature & color filter

  • White balance: AWB micro adjustment

    Yes

  • Focus system Type

    Contrast-detection AF

  • Focus sensor

    "Exmor" CMOS sensor

  • Focus point

    169 points (contrast-detection AF)

  • Sensitivity range

    EV-4 to EV20 (ISO100 equivalent with F2.0 lens attached)

  • AF mode

    AF-S (Single-shot AF), AF-C ( Continuous AF), Manual Focus

  • Focus area

    Wide (169 points(contrast-detection AF))

  • Other Functions

    Focus lock

  • Metering type

    1200-zone evaluative metering

  • Metering sensor

    "Exmor" CMOS sensor

  • Metering sensitivity

    EV-3 to EV20 (at ISO100 equivalent with F2.0 lens attached)

  • Modes

    Multi-segment

  • Exposure modes

    AUTO(iAuto/Superior Auto)
    Programmed AE (P)
    Aperture priority (A)
    Shutter-speed priority (S)
    Manual (M)
    Movie / High Frame Rate (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) )

  • Exposure compensation

    +/- 5.0EV(1/3 EV, 1/2 EV steps selectable)

  • AE Lock

    Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)

  • ISO sensitivity

    Still images: ISO 100-102400 (ISO numbers up from ISO 50 to ISO 409600 can be set as expanded ISO range.)
    AUTO (ISO 100-12800, selectable lower limit and upper limit) Movies: ISO 100-102400 equivalent (ISO numbers up to ISO 409600 can be set as expanded ISO range.)
    AUTO (ISO 100-12800, selectable lower limit and upper limit) (Recommended Exposure Index)

  • ISO AUTO Min. SS

    Yes

  • Clock Function Setting

    Yes

  • Area Setting

    Yes

  • Clear Image Zoom

    Still images: Approx. 2x
    Movies: Approx. 2x

  • Digital zoom

    Still images:
    35mm full frame
    L:approx 4x
    M:approx 6.1x
    S:approx 8x
    APS-C:
    L:approx 4x
    M:approx 5.2x
    S:approx 8x

    Movie:
    35mm full frame: approx. 4x
    APS-C: approx. 4x

  • Shutter Type

    Electronically-controlled, vertical-traverse, focal-plane type

  • Shutter speed

    Still images:1/8000 to 30 sec, Bulb, Movies: 1/8000 to 1/4(1/3 steps) up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode)

  • Electronic Front Curtain Shutter

    Yes(ON/OFF)

  • Silent Shooting

    Yes(ON/OFF)

  • Drive modes

    Single Shooting
    Continuous shooting

  • Speed

    Continuous mode: max. 2.5 fps (approx., max.)

  • No. of frame recordable (approx.)

    Continuous mode:
    JPEG Extra fine L: 109 frames
    Continuous mode:
    JPEG Fine L: 200 frames
    Continuous mode:
    JPEG Standard L: 200 frames
    Continuous mode:
    RAW: 67 frames
    Continuous mode:
    RAW&JPG: 42 frames

  • Playback

    Delete

  • PC interface

    PC remote

  • Multi / Micro USB Terminal

    Yes

  • HD output

    HDMI (Type-D)

  • DC IN Terminal

    VDC 12V - 25%+10% (9V to 13.2V)

  • PC Remote

    Yes

  • Battery for clock

    MS621T, Button Type, Manganese-Silicon, Approx.0.23g (without Tabs), 1pcs

  • Power consumption

    With Viewfinder: 19W (including lens)

  • Body material

    Magnesium alloy, High rigidity engineering plastic exterior

  • Operating temperature

    0 to 45 deg. C (32 to 113 deg. F)

  • Safety Regulations

    UL60950-1, cUL No.60950-1, IEC60950-1 VCCI (Class A), FCC Part15B (Class A), IC ICES-003 (Class A)
    Emission: EN55032 (Class A), EN61326-1 (Class A)
    Immunity: EN55024, EN61326-1
    Emission: AS/NZS CISPR32(EN55032) (Class A)
    MSIP EMC KN32 (Class A), KN35
    EAC(EMC-TR) CISPR32 (Class A), CISPR24

  • Dimensions (WxHxD)

    Approx. 104 x 84 x 48mm (4.09 x 3.31 x 1.89") excluding protrusions

  • Weight

    Body only: Approx. 390g (13.76 oz) (without lens)

About Sony UMC-S3C

With an ultra-high sensitivity of ISO 409600 (Standard ISO 100-102400) and internal recording, this compact 4K video camera is ideal for a wide range of remote shooting applications in almost total darkness. The UMC-S3C can capture smooth 4K/29.97P/25P color video in almost pitch-black conditions, from night-time starlight to poorly lit rooms. It's extremely compact size and on-board recording capability make the camera ideal for remote PoV (Point of View), documentaries, wildlife and live action shooting, plus challenging environments where cabling or space are limited.

In addition to its amazing low-light capabilities, this camera's form factor makes it ideal in specialized environment such as Point of View (POV), on Drones or in Virtual Reality rigs (VR). With the highest sensitivity in its class with minimum illumination of 0.004 lx, ISO 409600, the camera is ideal for environments where the human eye struggles to see. Extraordinary low-light imaging performance is delivered by the highly sensitive 35 mm full-frame Exmor CMOS sensor, advanced signal processing and interchangeable E-mount FE lenses. This UMC-S3C records crisp, clear 4K/29.97P/25P color video using the XAVC S format at up to 100 Mbps, as well as very low-noise 12 megapixel color still images.

The high-speed electronic shutter can capture blur-less color video of written characters, numbers and human faces. The camera is also equipped with a mechanical shutter for extremely sharp still images, even when there's movement in a scene. A choice of interchangeable E-mount FE lenses (available separately) offers the flexibility to adjust the camera's viewing angle to suit a wide range of applications. Long-duration video and still images can be recorded to the camera's on-board SD memory card or output to an external recorder or monitor via HDMI. For example: with a 64 GB memory card, users can record up to 125 minutes of 4K footage with standard quality (29.97P/60 Mbps). Weighing approximately 13.8 oz (390g), the UMC-S3C is ideal for installation in mobile platforms like vehicles and robots. The camera can be controlled via multi terminal (Supports Micro USB compatible devices), remote controller or a PC and compatible software.

Crisp, clear 4K video and still images, even in near darkness
With an ultra-high sensitivity of ISO 409600 (Standard ISO 100-102400, expandable to 50-409600), the UMC-S3C captures crisp, clear 4K/29.97P/25P color video and low-noise 12 megapixel still images in minimum illumination conditions of 0.004 lx. The 35 mm full-frame Exmor sensor captures significantly more incident light than conventional cameras, while the image processing extremely enhances the high sensitivity with very low noise. Area-specific noise reduction selectively divides the image into areas based on patterns (such as edges, textures and evenly colored areas like blue skies) to efficiently reduce noise and improve image quality. Detail reproduction technology helps to accurately depict details with a more natural sense of dimension.

Greater shooting flexibility with choice of E-mount FE lenses
The camera's versatility in a wide range of shooting applications is enhanced by compatibility with a wide range of interchangeable E-mount FE lenses (available separately) (Compatible E mount FE lenses include the SEL35F14Z (35 mm, F1.4), SEL35F28 (35 mm, F2.8), SEL28F20 (28 mm, F2.0) and SEL55F18Z (55 mm, F1.8)). These maximize the performance of the 35 mm full-frame sensor, maintaining high resolution across the entire image area from center to edges.

Small and light enough to go anywhere
Ideal for use in space-limited situations, the compact camera measures approximately 104.0 mm x 84.0 mm x 48.0 mm (4 1/8 inches x 3 3/8 inches x 1 15/16 inches). With a light weight of approximately 390 g (13.8 oz), it's ideal for installation in mobile environments such as vehicles and robots.

Easy operation even on the move
4K video or still images can be recorded internally to an SD card or fed via HDMI to an external recorder or monitor, even when the camera is on the move. The camera's multi terminal can connect to Micro USB-compatible devices, allowing remote control of functions such as zoom and shutter release, Rec Start/Stop and Zoom using widely-available consumer accessories.

High quality internal recording
The camera can continuously record 4K/29.97P/25P color video in the XAVC S format at up to 100 Mbps and 12 megapixel color still images in JPEG or RAW format at 14 bits to an SD memory card. For example, a 64 GB SD card can record up to 125 minutes of continuous 4K footage with standard quality (29.97P/60 Mbps). Recorded video files can be reviewed on a wide range of ordinary PC media players compatible with the MP4 format such as Windows Media Player.

What's in the box:

  • Sony UMCS3C/P 12.2MP 4K Extreme Low Light Ultra High Sensitivity Interchangeable Lens Digital Video Camera
  • Body Cap
  • Tripod Adapter
  • 4x Tripod Adapter Fixing Screw
  • Power Supply
  • Power Cord
  • Sony 1 Year Warranty
