Sony Integrated Test and Measurement Module for LCD Monitors

SKU: SOVMM4SNY MFR: VMM4SNY
Earn VIP Reward Points

Key Features

  • Optimize your Sony LCD monitor's performance with this integrated test and measurement module.
  • Ensure accurate color reproduction on your Sony monitor with precise measurement capabilities.
  • Compatible with a range of Sony LCD monitors, including LMD and BVM series for versatile use.
  • Analyze video signals with terminating inputs and BNC connectors for professional monitoring tasks.
  • Equipped with SD-SDI, HD-SDI, and 3G-SDI inputs, ensuring compatibility with various video formats.
  • Digital audio input supports AES/EBU formats, perfect for comprehensive audio/video analysis.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$699.99

4 Year

$849.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Sony Integrated Test and Measurement Module for LCD Monitors Specifications

  • Compatibility

    LMD- 1751W, LMD-2050W, LMD-2450W, LMD-2451W, LMD-4250W, BVM-L170, BVM-L230 and PVM-L2300 LCD monitors

  • Inputs

    Input Type -2 terminating inputs
    Input Connector Type -BNC, female
    Input Impedance -75 ohms nominal
    Signal Source Amplitude-800 mV nominal
    Signal Source DC Offset - +/-0.5 VDC

  • SD-SDI Input

    Input Return Loss - =-25 dB, 5 to 270 MHz
    Cable EQ - =300 m, Belden 8281

  • HD-SDI Input

    Input Return Loss - =-15 dB, 5 MHz to 1.485 GHz
    Cable EQ - =100 m, Belden 8281

  • 3G-SDI Input

    Input Return Loss - =-10 dB, 1.485 to 2.97 GHz
    Cable EQ - =80 m, Belden 1694A

  • External Reference Input

    Input Connector Type - BNC, femaleInput Type - TerminatingInput Impedance - 75 ohms nominalBlackburst Input Amplitude - NTSC: sync and burst 286 mV, nominalPAL: sync and burst 300 mV, nominalBlackburst Input Amplitude - +/-6 dBToleranceTri-Level Sync Amplitude -600 mV pk-pkTri-Level Sync Amplitude Tolerance -+/-3 dBReturn Loss - =-40 dB

  • Digital Audio Input

    Audio Formats - AES/EBU and embeddedAES Input Connector Type - 1 BNC, femaleAES Input Impedance - 75 ohms, nominalAES Input Return Loss - >25dB, 0.1 to 6 MHzAES Input Level -0.2 to 2 VInput Sample Rate - AES 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz(internal sample rate converted to 48 kHz)

About Sony Integrated Test and Measurement Module for LCD Monitors

If you're seeking a high-quality, durable, and user-friendly solution for integrated testing and measurement of LCD monitors, look no further than the Sony VMM-4SNY Integrated Test & Measurement Module. This innovative device, designed by the reputable Sony brand, offers comprehensive monitoring of up to 16-channels of embedded audio and an AES input.

The Sony VMM-4SNY provides precise measurements through a scalable waveform, vector, picture, gamut, timing, alarms, and audio. It's compatible with a range of Sony LCD monitors, including the LMD-1751W, LMD-2050W, LMD-2450W, LMD-2451W, LMD-4250W, BVM-L170, BVM-L230, and PVM-L2300 models.

This reliable module boasts two HD-SDI/SD-SDI input connections with embedded audio support, an AES input connection, and an external reference connection. It's designed to allow you to view and measure up to four signals on a single display, enhancing efficiency and convenience.

The VMM-4SNY features an MLT display with independent size and position control of waveform, vector, and picture. The audio output is seamlessly connected to the monitor's internal speakers, eliminating the need for external connections.

With the capacity to store up to 99 presets, this module supports both HD and SD-SDI signals. It also features a user-friendly web interface or RCU-CMS control, and its functional control can be enabled using a standard Ethernet connection via a Web browser or an optional remote control panel (RCU-CMS).

The Sony VMM-4SNY Integrated Test & Measurement Module is powered by the monitor, eliminating the need for an external power supply. This makes it an efficient and convenient choice for all your LCD monitor testing and measurement needs.

Sony Integrated Test and Measurement Module for LCD Monitors Features

  • High-quality integrated test and measurement module designed by Sony for LCD monitors
  • Comprehensive monitoring of up to 16-channels of embedded audio and an AES input
  • Compatible with a range of Sony LCD monitors, including LMD and BVM series
  • Offers precise measurements through scalable waveform, vector, picture, gamut, timing, alarms, and audio
  • Features two HD-SDI/SD-SDI input connections, an AES input connection, and an external reference connection
  • User-friendly web interface or RCU-CMS control with functional control enabled via a standard Ethernet connection

Warranty Information

This product has a limited warranty of 12 months for parts and 3 months for labor.

Key Features

  • Optimize your Sony LCD monitor's performance with this integrated test and measurement module.
  • Ensure accurate color reproduction on your Sony monitor with precise measurement capabilities.
  • Compatible with a range of Sony LCD monitors, including LMD and BVM series for versatile use.
  • Analyze video signals with terminating inputs and BNC connectors for professional monitoring tasks.
  • Equipped with SD-SDI, HD-SDI, and 3G-SDI inputs, ensuring compatibility with various video formats.
  • Digital audio input supports AES/EBU formats, perfect for comprehensive audio/video analysis.
