Squier Jim Root Telecaster Specifications

Body
  • Body Material

    Mahogany

  • Body Shape

    Telecaster

  • Body Finish

    Polyester Satin Matte

  • Neck Material

    Maple

  • Neck Finish

    Polyester Satin Matte

  • Neck Shape

    Modern "C"

  • Scale Length

    25.5" (647.70mm)

  • Fingerboard Material

    Indian Laurel

  • Fingerboard Radius

    12" (304.80mm)

  • Number of Frets

    22

  • Fret Size

    Medium Jumbo

  • Nut Material

    Synthetic Bone

  • Nut Width

    1.650" (41.91mm)

  • Position Inlays

    Pearloid Dots

  • Truss Rod

    Standard

Electronics

Jump to...
  • Bridge Pickup

    Covered Passive Humbucking

  • Neck Pickup

    Covered Passive Humbucking

  • Controls

    Master Volume

  • Switching

    3-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup

  • Configuration

    HH

Hardware

Jump to...
  • Bridge

    6-Saddle Standard Strings-Through-Body Tele with Block Saddles

  • Hardware Finish

    Black

  • Tuning Machines

    Die-Cast

  • Pickguard

    1-Ply White

  • Control Knobs

    Black Plastic

  • Switch Tip

    Black

  • Neck Plate

    4-Bolt Standard

Miscellaneous

Jump to...
  • Strings

    Fender USA, NPS, (.010-.046 Gauges)

  • Other Functions

    Mahogany Body, Covered Passive Humbucking Pickups, Rosewood Fingerboard with 12" Radius (305mm), Parchment Dot Position Inlays on Rosewood Fingerboard, Black Hardware, Black Pickguard Screws, Flat Finishes

  • UPC Code

    885978883752

About Squier Jim Root Telecaster

The Root of Squier Telecaster Tone
Squier brings you a brand-nu signature model-the crushing Squier Jim Root Telecaster. Designed in cooperation with the acclaimed Slipknot/Stone Sour guitarist, it boasts several foreboding features, such as a black or white satin-matte finish, starkly simple control layout, two pulverizing passive humbucking pickups with black covers and blacked-out hardware, including tuning machines.

• Mahogany body
• Maple neck with "C"-shaped profile and 22-fret Indian Laurel fingerboard with 12" radius
• Dual passive humbucking pickups with black covers
• Three-way pickup switch and single control knob (master volume)
• Strings-thru-body Telecaster bridge
• Black hardware

Humbucking Pickups With Black Covers
These humbucking pickups feature sleek black covers for a distinctive look.

Black Hardware
In a pleasingly malevolent touch, the sparsely appointed Jim Root Tele features an all-black bridge, controls, bridge pickup bezel, tuners, strap buttons and more.

12"-radius Indian Laurel Fingerboard
This instrument features a fingerboard radius (the amount of curvature across the width of the fingerboard) that, at 12", is substantially more flattened than both a vintage-style 7.25" radius and a modern 9.5" radius. Feels notably flat even though there's still slight curvature-great for bending notes without fretting out.

Satin Matte Finish
The satin finish on this model is a smooth and stylish touch, offering a muted matte finish appearance versus the glassy sheen of conventional gloss finishes.

Vintage-style Hardtail Bridge
This model features a hardtail bridge, rather than the classic tremolo, engineered for enhanced tuning stability and sustain. This design element also hearkens back to the early- to mid-'70s when hardtail guitars surged in popularity again.

Modern Neck with "C"-Shaped Profile
This instrument features a modern neck designed for comfort and performance, with a contemporary "C"-shaped profile (the shape of the neck in cross section) and a smooth back finish-ideal for those who play with the thumb on the back or side of the neck.

What's in the box:

  • Squier Jim Root Signature Telecaster Electric Guitar
  • Squier 2 Year Limited Warranty
