Salrayworks K-M20 Full HD NDI 1/2.8'' Exmor R CMOS Sensor 20x PTZ Camera, Black

SKU: SRWKM20B MFR: K-M20-B
Earn VIP Reward Points

Key Features

  • Capture stunning Full HD video with the K-M20 PTZ camera's remarkable 20x optical zoom.
  • Experience superior low-light performance with the Exmor R CMOS sensor for clear video.
  • Easily integrate this PTZ camera into existing systems with versatile 3G-SDI and HDMI outputs.
  • Remotely control pan, tilt, and zoom functions for dynamic video capture in any environment.
  • Perfect for live streaming, broadcast, or video conferencing with its smooth PTZ operation.
  • Achieve professional-grade video quality with customizable settings for white balance and focus.
See More Product Details
Special Order?Estimated to Ship: 08/19/2025
Calculate Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Salrayworks K-M20 Specifications

Camera
  • Module

    (20x) 1/2.8" Exmor R CMOS

  • Valid Pixels (H x V)

    1920 x 1080 (Approximately 2.1 million pixels)

  • Video output format

    1920x1080p60, 1920x1080i60, 1920x1080p30, 1280x720p60, 1280x720p30, 720x576i50(CVBS only)
    1920x1080p59.94, 1920x1080i59.94, 1280x720p59.94, 1920x1080p50, 1920x1080i50, 1920x1080p25, 1280x720p50, 1280x720p25

  • Video output

    HD/3G-SDI, HDMI, DVI, CVBS

  • Zoom Scale

    Optical zoom: 20x
    Digital zoom: 12x

  • Lens

    12x Zoom Lens [f=4.7-56.4 mm F1.6-F3.5] / 20x Zoom Lens [f=4.7-94 mm F1.6-F4.7]

  • Viewing Angle

    57.4 Degree (W), 3.2 Degree (T)

  • Minimum Luminance

    0.2lx (Day)
    0.1lx (Night)
    0.005lx (DSS on)

  • Interface

    3G-SDI, HDMI, CVBS

  • Day&Night

    AGC, TDN(ICR)

  • Focus

    Semiauto/ Auto/ Manual

  • Image Flip

    On/ Off

  • Zoom Speed

    0-7

  • Focus Near Limit

    30cm/ 1m/ 1.5m/ 2m/ 3m/ 5m/ 10m

  • AF Sensitivity

    Normal/ Low

  • Defog Mode

    Off/ Low/ Mid/ High

  • High Sensitivity

    Off/ On

  • Noise Reduction

    Off/ 1-5

  • Aperture

    10, 0-15

  • White Balance

    Auto/ Indoor/ Outdoor/ One Push/ ATW/ Manual/ Outdoor Auto/ Sodium Auto/ Sodium/ Sodium Out Auto

  • Program AE

    Full Auto/ Bright/ Shutter Pri/ Iris Pri/ Manual

  • WDR

    Off/ On/ VE

  • BLC

    On/ Off

Pan/Tilt

Jump to...
  • Moving Angle

    Pan: -172 Degree - 172 Degree (Non-Endless)
    Tilt: total 220 Degree (-20 Degree - 0 Degree - 180 Degree - -160 Degree )

  • Moving Speed

    Manual: 0.002 Degree /sec -180 Degree /sec (Interlocked with the Zoom Scale)
    Preset: 300 Degree /sec, Swing: 1 Degree /sec - 180 Degree /sec

  • Preset setup

    256 Presets [VISCA], 255 Presets (Label setup, each display setup) [PELCO]

  • Swing setup

    8 swings

  • Pattern setup

    8 Patterns

  • Group setup

    8 Groups (20 motions/Group)

  • Other functions

    Smart-Flip, Home Position Set, Auto Parking, Power Up Action etc.

General

Jump to...
  • Color

    Black

  • Cam ID

    PELCO: 1-14
    VISCA: 1-14 setting

  • Communication

    RS-422/485, RS-232C, IR Remote

  • Protocol

    PELCO-D/P, VISCA

  • OSD

    Menu, Position, etc.

  • Power

    DC 12V +/- 10% (Max 1A)

  • Operating temperature

    32 Degree F - 104 Degree F (0 Degree C - 40 Degree C)

  • Dimensions (W x D x H)

    6.54 x 7.20 x 6.89" (166 x 183 x 175mm)

  • Weight

    4.30 lbs (1.95kg) Approximately

  • UPC Code

    706249186092

About Salrayworks K-M20

You can experience advanced, high-quality imaging with the K-M20 Full HD NDI 1/2.8'' Exmor R CMOS Sensor 20x PTZ Camera in sleek black. This state-of-the-art camera is designed to deliver professional-grade, full HD 1920x1080 resolution images at a smooth 60fps frame rate. This ensures you capture every detail with exceptional clarity, even in challenging low light conditions where other cameras may falter.

The sophisticated 1/3-type CMOS image sensor is engineered to capture crisp, detailed images with minimal noise. The high frame rate operation guarantees smoother, more fluid reproduction of moving subjects, making it an ideal choice for video surveillance or conference settings.

The camera's powerful 20x optical zoom is complemented by a 12x digital zoom, allowing for frame-filling close-ups where every detail is clearly visible. The responsive autofocus feature ensures that images remain sharp and clear, even at high zoom settings.

The K-M20 Full HD NDI 1/2.8'' Exmor R CMOS Sensor 20x PTZ Camera offers a variety of video interfaces, including SD/HD/3G-SDI, HDMI, and CVBS. This allows for greater flexibility in terms of connectivity and compatibility with different devices and systems. The KM/KS Model series can simultaneously output 1080/60p baseband video through 3G-SDI and HDMI stream, providing versatile connectivity options.

The camera's enhanced PTZ operation offers a wide pan/tilt angle range, with a powerful direct drive motor ensuring quiet, rapid movement to the target position. PTZ synchronization ensures smoothly coordinated camera movements, and the pan/tilt speed can be set to 'Slow' for smooth, professional-looking transitions.

With a wide 57.4-degree viewing angle, this camera is perfect for capturing every participant in a boardroom or surveillance area. It also offers 256 programmable presets, allowing you to store and instantly recall up to 256 camera positions. Whether you choose to mount it on a desktop or ceiling, the image flip feature ensures proper image orientation. Experience the sophistication and high-quality performance of the K-M20 Full HD NDI 1/2.8'' Exmor R CMOS Sensor 20x PTZ Camera.

Salrayworks K-M20 Features

  • The 20x optical zoom range is complemented by 12x digital zoom for frame-filling close-ups with every detail seen clearly
  • Can simultaneously output 1080/60p baseband video through 3G-SDI, HDMI, CVBS stream
  • Support for RS-232C,422,485 communication allows easy connection with a wide range of peripheral products. The camera can also be controlled via VISCA protocols over a standard VISCA, PELCO-D/P
  • The powerful direct drive motor assures quiet, rapid movement to the target position over a wide pan/tilt angle rang
  • Store and instantly recall up to 256 camera positions via KM/KS Model PTZ Controller C series from specific controller

Key Features

  • Capture stunning Full HD video with the K-M20 PTZ camera's remarkable 20x optical zoom.
  • Experience superior low-light performance with the Exmor R CMOS sensor for clear video.
  • Easily integrate this PTZ camera into existing systems with versatile 3G-SDI and HDMI outputs.
  • Remotely control pan, tilt, and zoom functions for dynamic video capture in any environment.
  • Perfect for live streaming, broadcast, or video conferencing with its smooth PTZ operation.
  • Achieve professional-grade video quality with customizable settings for white balance and focus.

What's in the box:

  • K-M20 1080p 1/2.8'' Exmor R CMOS Sensor PTZ Camera (Black)
  • AC Adapter
  • IR Remote
  • Salrayworks 1 Year Limited Warranty
