Review Summary
49" (124.4cm)
60Hz D-LED BLU
1920x1080 (Full HD)
0.186 x 0.559mm
42.24 x 23.77" (1073.7 x 604mm)
300 nit
3000:1
178:178
8ms
16.7 M
72%
16/7
2%
MEGA
16:09
H-Scanning: 30 - 81kHZ
V-Scanning: 48 - 75HZ
Maximum: 148.5MHz
Built in Speaker (10W + 10W)
RGB: DVI-I
Video: HDMI 1.4 (2), Component(CVBS Common)
HDCP: HDCP 1.4
Audio: Stereo Mini Jack, RGB/DVI/HDMI/CVBS/Component
USB: USB 2.0 x 1
Audio: Stereo Mini Jack
External Control: RS232C(in/out) thru stereo jack, RJ45
Tuner: Yes(only for NA/KR)
Internal
AC 100 - 240 V- (+/- 10 %), 50/60 Hz
Max [W/h]: 121
Typical [W/h]: (W/W)64, (US)42, 76(KR)
BTU (Max): 412.6
Sleep mode: less than 0.5W
Off mode: 0
32 to 104 Degree F (0 to 40 Degree C)
10.0 % - 80.0 %
MIPS 24K
L1: 16KB/16KB L2: 128KB
650MHz
512MB
179MB
Samsung Proprietary OS (VDLinux)
cUL - UL : cUL60950-1
FCC Part 15, Subpart B Class A
7.87 x 7.87" (200 x 200mm)
Top: 0.68" (17.4mm)
Bottom: 0.7" (18.5mm)
Side: 0.84" (21.5mm)
44.04 x 25.59 x 2.92" (1118.8 x 650.0 x 74.2mm)
22.48 lbs (10.2kg)
8806088997582
A reliable, affordable display that supports 16-hour-per-day functionality
Features:
Amplify Business Messaging
The DCJ series combines FHD resolution, 300nit brightness, and 16/7 reliability to boost engagement and relay timely information with superior content presentation.
Load and Share with Ease
The embedded MagicInfo Lite Player allows users to conveniently load and play a wide range of content types. Simply plug in a USB device to the built-in port or access the internal memory to display the desired content on the screen.
Simplify Content Scheduling
Utilize the MagicINFO Lite solution to remotely manage content and monitor the DCJ series over a network through the MagicINFO Server. Conveniently access device information, content playback schedules and more without being in front of the displays.
Diversify Connectivity Preferences
With a versatile interface including USB, DVI, HDMI, RS-232C and RJ45, easily connect and use a wide array of devices with the display.
Key Features:
Light LFD with Built-in MagicInfo Lite
H/W: Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2)
S/W: Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play (DDC2B), Built In MagicInfo Lite, Firmware Update by Network
