Samsung QB55N 55" Class 4K UHD Commercial New Edge Smart LED Display, Cortex-A72 1.7GHz, 2.5GB DDR4, 8GB Storage, Built-in Speakers, 3840x2160

SKU: SSQB55N

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Samsung QB55N Specifications

Panel
  • Diagonal Size

    55" (139.7cm)

  • Type

    New Edge

  • Resolution

    3840 x 2160 (4K UHD)

  • Pixel Pitch (H x V)

    0.315 x 0.315mm

  • Active Display Area (H x V)

    1209.6 x 680.4mm

  • Brightness (typical)

    350 nit

  • Contrast Ratio

    4000:1

  • Viewing Angle (H/V)

    178/178

  • Response Time(G-to-G)

    8ms

  • Display Colors

    16.7M

  • Color Gamut

    72%

  • Operation Hour

    16/7

  • Haze

    2%

Display

Jump to...
  • Dynamic C/R

    MEGA

  • H-Scanning Frequency

    30 - 81kHZ

  • V-Scanning Frequency

    48 - 75HZ

  • Maximum Pixel Frequency

    594MHz

  • Speaker Type

    Built in Speaker(10W + 10W)

Connectivity

Jump to...
  • Input

    RGB: DVI-D
    Video: HDMI 2.0 (2)
    HDCP: HDCP 2.2
    Audio: Stereo Mini Jack, DVI/HDMI/Audio(Common)
    USB: USB 2.0 x 2

  • Output

    Audio: Stereo Mini Jack
    External Control: RS232C(in/out) thru stereo jack, RJ45
    External Sensor: IR

  • Type

    Internal

  • Power Supply

    AC 100 - 240 V- (+/- 10 %), 50/60 Hz

  • Power Consumption

    Max[W/h]: 143
    Typical[W/h]: 96
    Rating[W/h]: 130
    BTU(Max): 487.6
    Sleep mode: 0.5

Operation

Jump to...
  • Operating Temperature

    32 - 104 Degree F (0 - 40 Degree C)

  • Humidity

    10 % - 80 %

Internal Player

Jump to...
  • Processor

    Cortex A72 1.7GHz Quad-Core CPU

  • On-Chip Cache Memory

    L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

  • Clock Speed

    1.7GHz

  • Main Memory Interface

    2.5GB LPDDR4 1.5GHz 64bit

  • Graphics

    Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)

  • Storage (FDM)

    8GB (3.88GB Occupied by O/S, 4.12GB Available)

  • Multimedia

    Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG

  • IO Ports

    USB 2.0

  • Operating System

    Tizen 4.0 (VDLinux)

Certification

Jump to...
  • Safety

    60950-1

  • EMC

    Class A

Mechanical

Jump to...
  • VESA Mount

    7.87 x 7.87" (200 x 200mm)

  • Stand Type

    Foot Stand (Optional)

  • Bezel Width

    13.5(top, side), 17.7(bottom)

  • Dimensions

    48.76 x 28.11 x 2.32" (1238.6 X 714.2 X 59.0mm)

  • Weight

    38.3 lb (17.4kg)

  • UPC Code

    887276266350

About Samsung QB55N

Bring Creative Content Ideas to Life
As more businesses turn to UHD displays for differentiation, Samsung's QBN Series offer the ideal customer engagement forum. The displays' UHD picture quality and sleek, stylish design capture audience eyes, while seamless and consistent presentation expands message sharing possibilities.


Share Intelligent, High-Quality Content

Intelligent Picture Quality
The QBN Series displays leverage Samsung's Intelligent Picture Quality technology to elevate content delivery in any setting. This refined presentation transforms content from any source to UHD-level quality, and optimizes on-screen text and imagery with crisp edges and fine detail.


Streamline Operational Efficiency
The embedded MagicINFO Player S6, backed by the powerful TIZEN operating system, boosts the displays overall performance, allows for painless content management and ensures seamless content transition and playback.

Powerful Performance
• Graphic Performance with Quad core CPU
• UHD Content play back
• HTML5 Compatibility

Easy Development
• Tizen Studio
• Node.JS HTTP web server

Business Expandability
• Remote Management
• Signage Device Management
• Enhanced Security


Empower Secure and Remote Collaboration
Samsung's KNOX platform provides rigid three-layer protection while also securing and controlling USB and user network exchange through dedicated signage device management. With added security, businesses can facilitate remote, PC-free meetings without risk or complexity.

Maintain Continuous Display Performance
Beyond security and content management, QBN Series users can trust the displays' remote management for fast, efficient issue mitigation. Users can monitor and diagnose irregularities - both on their own and with help from Samsung's Network Operations Center - from any location.

Enjoy Convenient Display Management
The QBN Series' integrated centralized infrared receiver (IR) ensures easier and more flexible user control. Each display receives signals on individual panels via Central IR, and users can navigate the IR functionality from various locations to further augment uninterrupted performance.

Shield Content from Outside Interference
The QBN Series' durable, IP5x-validated design ensures continuous content delivery regardless of environmental conditions. As a result, transportation hubs and other arenas susceptible to dust, dirt and lighting exposure can activate and run the displays without an external enclosure.

Key Features
• UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
• H/W : Temperature Sensor, Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), IP5x, Wi-Fi
• S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)

Samsung QB55N Features

  • Revitalize customer engagement in retail and transportation settings
  • Elevate content quality through a unique combination of picture-enhancing features
  • Facilitate secure, PC-free meetings through rigid three-layer protection

Key Features

  • Revitalize customer engagement in retail and transportation settings
  • Elevate content quality through a unique combination of picture-enhancing features
  • Facilitate secure, PC-free meetings through rigid three-layer protection

What's in the box:

  • QB55N 55" Class 4K UHD Commercial New Edge Smart LED Display
  • Power Cord
  • Remote Controller
  • Batteries
  • Quick Setup Guide
  • Samsung 3 Year Limited Warranty
