StarTech 1U Adjustable Mounting Depth Vented Rack Mount Shelf

SKU: STADJSHELF MFR: ADJSHELF
$123.99
Earn VIP Reward Points

Key Features

  • Optimize your rack space with this 1U adjustable shelf, fitting various equipment depths.
  • Ensure proper airflow with the vented design, keeping your rack mount devices cool.
  • Achieve compatibility with adjustable mounting depth from 19 to 38 inches for easy setup.
  • This durable rack shelf supports up to 176.8lbs, perfect for heavy network equipment.
  • Simplify installation with included hardware; quickly mount in any standard 19" rack.
  • Manage cables effectively using this shelf as a stable platform for cable organization.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

2023-03-19T20:00:00

Rated 2 out of 5

Installation nightmare

Installing this shelf is a nightmare. You have to put the ears in the rack first and then attempt to slide the shelf in because attaching the ears first make the shelf just that much too wide to put in a standard rack. Very poor design

GloNet

2020-04-13T20:00:00

Rated 2 out of 5

19" rack compatibility is questionable

While it might be true that this shelf is compatible with all 19" racks, it certainly wasn't easy. I just finished installing this shelf into a new empty rack (a StarTech no less, 4POSTRACK25U) and installation was a nightmare. I should've read reviews first, because after it seemed like this shelf wasn't going to fit, I found a review with better instructions than the ones that came with it. The manual has you attach the ears to the shelf first and then mount it in the rack. However, the ears make it just too wide to fit into a 19" rack. Instead, as suggested in the review I found, I had better luck mounting the ears to the rack first, and then sliding the shelf in. It was still a very tight fit and required more force than seemed intended to get it into place. Now installed, the shelf seems very sturdy and will function as described. Was almost comical how much easier it was installing some ReadyRails and a server immediately afterwards. Not exactly a fair comparison, but I imagine there's room for improvement. For the price, as well as the fact I was working with a StarTech rack, I expected a much easier installation and not have to go digging around in reviews to figure out a solution. I would not recommend this shelf to anyone unless it could be acquired at a significant discount.

uhnomoli

StarTech 1U Adjustable Mounting Depth Vented Rack Mount Shelf Specifications

  • U Height

    1U

  • Weight Capacity

    176.8lbs / 79.56kg

  • Depth

    Adjustable from 19-38"

  • Maximum Mounting Depth

    38.3" / 972.82mm

  • Minimum Mounting Depth

    19.5" / 495.30mm

  • RoHS Compliant

    Yes

  • Dimensions

    (H x L x W): 1.6 x 27.6 x 17.5" / 40.64 x 701.04 x 444.50mm
    External (H x W): 1.6 x 18.9" / 40.64 x 480.06mm
    Internal (D x H x W): 27.6 x 1.6 x 17.6" / 701.04 x 40.64 x 447.04mm

  • Weight

    155.3oz / 4402.76g

  • UPC Code

    065030826358

About StarTech 1U Adjustable Mounting Depth Vented Rack Mount Shelf

A quintessential addition to any server rack or cabinet, the ADJSHELF Adjustable Mounting Depth Rack Mount Shelf is engineered to provide a robust and reliable platform for your essential computer hardware and electronic equipment. Expertly designed to be compatible with all standard 19-inch server racks and cabinets, this versatile shelf offers an adjustable mounting depth ranging from 19 inches to 38 inches, ensuring a custom fit for a variety of equipment sizes.

Crafted from high-quality cold-rolled steel, the shelf boasts exceptional durability and is capable of supporting a substantial weight capacity of up to 175 pounds (80 kilograms), making it an ideal solution for organizing mission-critical hardware. The vented shelf plate is a key feature, promoting efficient airflow to prevent overheating and maintain optimal performance of your devices.

The ADJSHELF is not only sturdy and durable but also maintains a sleek and professional appearance in any server environment. Its TAA compliance ensures it meets the requirements for GSA Schedule purchases, reflecting its adherence to stringent standards.

In terms of applications, this 1U rack mount shelf is a versatile and functional choice for adding extra storage space to any 19-inch wide server rack or cabinet. It is particularly suited for housing servers, networking devices, and other electronic components that require a secure and stable platform with the added benefit of enhanced ventilation.

The advantage of choosing the ADJSHELF lies in its adjustable and sturdy design, which allows for the safe storage of up to 175 pounds of equipment on a single 1U shelf. Its rugged steel construction is built to withstand the rigors of harsh environments, ensuring long-term reliability and performance.

In summary, the ADJSHELF Adjustable Mounting Depth Rack Mount Shelf is a superior solution for IT professionals and tech enthusiasts seeking a functional, durable, and adjustable storage option that prioritizes equipment safety and optimal airflow.

StarTech 1U Adjustable Mounting Depth Vented Rack Mount Shelf Features

  • 1U heavy duty adjustable rackmount shelf
  • Fits all standard 19" server racks
  • Adjustable mounting depth from 19.5in to 38in
  • Holds up to 80kg (175lbs)
  • SPCC 1.0mm cold-rolled steel construction

Warranty Information

This product has a limited lifetime warranty.

Key Features

  • Optimize your rack space with this 1U adjustable shelf, fitting various equipment depths.
  • Ensure proper airflow with the vented design, keeping your rack mount devices cool.
  • Achieve compatibility with adjustable mounting depth from 19 to 38 inches for easy setup.
  • This durable rack shelf supports up to 176.8lbs, perfect for heavy network equipment.
  • Simplify installation with included hardware; quickly mount in any standard 19" rack.
  • Manage cables effectively using this shelf as a stable platform for cable organization.

What's in the box:

  • StarTech 1U Adjustable Mounting Depth Vented Rack Mount Shelf
  • 2x Front Mounting Bracket
  • 2x Rear Mounting Bracket
  • 8x M5 Screw
  • 8x M5 Cage Nut
  • Instruction Manual
  • StarTech Lifetime Warranty
