StarTech 16 Port RS232 Multiplexer Rackmount FTDI USB to Serial COM Adapter Hub

SKU: STCUSB23216F MFR: ICUSB23216F
Earn VIP Reward Points

Key Features

  • Expand your connectivity with this 16-port USB to Serial adapter hub, perfect for multiple RS232 devices.
  • This FTDI USB to Serial adapter ensures high performance with data transfer rates up to 480 Mbps.
  • Our rackmount RS232 multiplexer supports a wide OS compatibility, including Windows, Mac, and Linux.
  • Enjoy reliable connections with a durable steel enclosure, designed for longevity and robust performance.
  • Simplify your setup using this serial COM adapter, featuring easy-to-read LED indicators for data status.
  • Each serial port supports versatile configurations, including adjustable baud rates and parity options.
See More Product Details
Temporarily On Backorder?Expected Availability: 09/2025Request assistance or get notified
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$79.99

3 Year

$109.99

4 Year

$129.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Learn
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2024-12-19T19:00:00

Rated 3 out of 5

ST4300USB3

To be completely honest in my review, I bought a ST4300USB from Amazon this month and after working with Tech Support it was determined defective. I returned it and received another and that one also would not connect. Sent it back for a refund. I also bought one back in June 2024 and after a few months it stopped connecting. I worked with Tech Support with that one as well and determined it was defective. Because of the return policy with Amazon, I contacted StarTech for a replacement. My confidence level wasn't high, I connected it and it worked just fine. I have had (3) total that did not work, possibly a better Quality Control on these units would turn out a quality product. I like the Hub when it works, but working through the issues and returning defective units may not be the best for customer service. Hopefully this latest Hub I received will continue working properly. Thank you for sending a replacement quickly.

PHCleve

2024-04-23T19:05:10

Rated 5 out of 5

Performs as advertised

Several years ago, we purchased an externally-powered Star Tech seven port Hub from Adorama. It has performed without any issues, connecting multiple devices to one of our desktop computers. We required port expansion on two more computers and based on our Star Tech experience, purchased two more that depend on USB-provided power and have four ports. The connecting cable is long enough for accessible placement. The number of connected devices is lower than on the original Hub. The Hubs are well-made, and connecting devices is simple. They are working very well; easy to install and so far, no issues.

ROBERT M.

2023-08-11T20:00:00

Rated 5 out of 5

astronomy

worked great right out of the box to link Gemini 2 system, auto focus motor and a guide camera to my laptop for my telescope. Very happy with this product.

Firstlight

2023-06-17T20:00:00

Rated 4 out of 5

Good for a laptop/notebook, not for a desktop.

I purchased it with the intention of plugging it into my desktop computer's front panel port and mounting it on the top of my case, but the cable is too short for this purpose... I'm sure it's great for a laptop or notebook!!

Cookie589

2023-02-19T19:00:00

Rated 1 out of 5

Dead out of the box

Dead out of the box. MacBook Pro can't see any external drives connected via this hub.

DONTBYSTARTECH

2023-02-14T19:00:00

Rated 1 out of 5

Dead on arrival

Received a unit that doesn't work. When I press the power button the leds flash for a brief moment and then it's completely dead. Checked the power brick, it puts out about 11V (i guess it's within range) so I guess it's something in the hub itself that is broken. Also dissapointingly there is a sticker on it inside saying that the dedicated charging ports don't output higher power when it's connected to a computer, only when the computer is turned off, otherwise it will just charge with the usual power a USB port has (very vague, probably means 0.5A)

dutzu

2022-09-09T20:00:00

Rated 5 out of 5

Works Perfectly

I use this hub continuously and during several years, it works perfectly for me. I can charge a mobile phone with the USB ports, maybe not super-fast but it charges nonetheless. It has a power supply but that´s only necessary if charging something, to just plug in standard mouse and keyboard peripherals it´s not necessary, so you can travel without it. I am very satisfied with all StarTech products including this one.

KevinBCN

2022-06-27T20:00:00

Rated 1 out of 5

Thought this would be great, but...

My company included this with all my other devices, laptop, monitor, wireless keyboard, wireless mouse, wireless headset. Fantastic idea since only 2 USB ports on my laptop and 3 wireless devices provided, worked fine at first but, after 2 months, kept getting the chime that something was not working, moved it to the second USB port, fine then one month later, today, same chime, plugged my two usb connectors into the laptop and working fine, so, obviously something is up with this hub.

djshizzl

2022-02-17T19:00:00

Rated 1 out of 5

hub died after a week

Worked fine for a week then stopped sending data and only power. Checked all connected cables and devices and they all work fine. Nothing in manual to suggest how to reset the unit. When will computer companies make something that actually works??

drbazh

2021-11-25T19:00:00

Rated 5 out of 5

Works Perfectly

This part works perfectly. It provide stable connections to critical components at our working observatory. Highly recommended.

WellsFRAS

2021-10-10T20:00:00

Rated 1 out of 5

No good. If it was heavier could be a boat anchor.

Got this 2 weeks ago and it does not work. Have tried it on 3 different Windows10 laptops and it is not detected. Went to the Startech website to download drivers and in the download drivers section there is only the same PDF manual that came with this device. There should be a section for a negative rating as I am negative $40 with nothing to show.

jjki

2021-10-06T20:00:00

Rated 4 out of 5

Mostly great

I also use this hub in my observatory, and I actually have two of them. One of my hubs frequently needs the power to be cycled on and off with the USB connection to my computer unplugged and then reconnected to work on many occasions. I am not sure what is causing this, and I wonder whether it possible to accomplish this remotely via code.

ArthurS

2021-07-27T20:00:00

Rated 4 out of 5

Driver for Windows 10

This adapter works still under Windows 10, you have to install the driver (Rev2 - TUSB3410) manually from the list. It is not signed, but it works!

hale

2021-06-27T20:00:00

Rated 5 out of 5

startech 3.0 4 port

the startech 3.0 gen 1 4 port usb has been working consistently well. flash drives from usb 2.0, usb 3.0 gen 1 and usb 3.1 gen 1 extreme have all worked well with the port replicator and as intended. system backup times, using usb 3.1 extreme have gone from 1 1/2 hours (usb 2.0 down to 20 minutes. formatting of external drives have also worked well with reduced time to full format.

dell c.

2021-06-21T20:00:00

Rated 2 out of 5

Not working

When I plug it into my Lenovo M720 Tower I get a USB Port Failure. How do I fix this?

ghfan1963

2021-05-05T20:00:00

Rated 1 out of 5

Not so good

It recognizes the drives in Devices & Printers but you cannot access them in My Computer

NateTheGrate

2021-04-27T20:00:00

Rated 1 out of 5

would not use

I bought this a while ago and it's great up until you have to charge your device so if you're a businessman I would go for something better unless u wanna charge your device very often. Personally, I haven't had any issues besides the fact I can't charge it and I have to unplug the USB hub in order to charge my device.

Hunter

2020-12-02T19:00:00

Rated 5 out of 5

Awesome little USB 3.0 Hub!

I needed a device to expand my single, easy to reach USB 3.0 SS Port on my desk that is built into my LG 32" monitor. We use Startech at work for many applications, so it was a "no brainer" for my management to approve this purchase for home usage. I appreciate being able to keep my Galaxy Tab fully charged, and also be able to charge my Galaxy S based Android phone at the same time! This is just the charging ports I am talking about! I also have 4 SuperSpeed USB 3.0 ports for connecting my 2 external hard drives, and also drive my 128GB USB 3.0 Memory Stick, and have a port left over. Copying external drive to external drive easily sustains an average of 65MB/s or so, so big files move across the wires quickly. I love the build quality as well!

dc_IV

2020-10-01T20:00:00

Rated 4 out of 5

HOW CAN YOU TURN OFF ANNOYING LEDs

Agree with other reviews but those Led lights are just too much. How can you turn them off.

GTKR

2020-09-05T20:00:00

Rated 1 out of 5

Unknown voltage

It uses a nonstandard voltage and that voltage is written nowhere on the unit. So I plugged in a 12v power adapter and it broke. I don't know who thought it would be a good idea to use a barrel plug and not write the voltage.

sajo

2020-09-04T20:00:00

Rated 5 out of 5

updated review

I previously wrote a review stating it never worked properly. Since then, I disconnected and moved it to a different set up. It seems to be working just great now. I'm happy with the product and hope that continues!

Dee w.

2020-07-28T20:00:00

Rated 4 out of 5

$$$

Works good; but too pricey.

gmknowles

2020-07-12T20:00:00

Rated 1 out of 5

Worked only twice

Bought about 3 or 4 years ago so it's out of warranty. Only worked once, now that I try to use it again it will work only if I press hard the serial connectors so probably the soldering is defective.

paul0207

2020-04-09T20:00:00

Rated 3 out of 5

Never-Shuts-Off USB Hub

The 4 Port Black SuperSpeed USB 3.0 Hub works well; however, when the computer is shut down, the hub stays on, and other devices attached to it do not shut down. Because of this these attached devices' hard drives continue to spin, thus wearing them out. I have another hub that although it is plugged in to an AC receptacle, it shuts down allowing anything attached to it to shut down as well.

chezmich

2020-03-10T20:00:00

Rated 4 out of 5

Works good, but some failed

Got 10 for a project and after a couple days two started having an issue where 5 of the 10 ports stopped working. Removing and reapplying power re-enables the ports but eventually the same 5 ports stop working.

55ffpw

2020-03-06T19:00:00

Rated 4 out of 5

Works well

I bought this item about three years ago and have it connected to my desktop PC to provide additional USB ports for data transfer and charging purposes. I have had no problems and it works as advertised.

Owrlover

2020-02-20T19:00:00

Rated 4 out of 5

great quality, DIN mount bracket not included

I've been using these for years quite happily, they are far above and beyond the build quality of typical USB hubs, and running them from 24v DC is perfect for my offgrid house. I switch terabytes of USB drives on and off on demand using one of these hubs. I recently bought a second one, and the DIN rail mounting bracket was not included. I don't know where to find a mounting bracket, and had hoped to DIN mount it.

joeyh

2020-01-29T19:00:00

Rated 1 out of 5

It was used & scratched up

I got last year and I should have sent it back. It worked at first, then stopped and prts work when they want too. I tried it on thre laptops. Doesn't work properly. Wasted my money!

ddd

2020-01-16T19:00:00

Rated 4 out of 5

Works fine with Win10, but

Works as described (plug and play, but very tight ports which can make it difficult to insert devices in certain positions especially since cord is short. Probably better for laptop use. Regardless it's worth the price.

Kevin

2020-01-04T19:00:00

Rated 4 out of 5

Pretty Good

sometimes my mouse does not tract properly when I plug the USB into the StarTech USB hub. It could be an issue with the mouse.

LmBr

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

StarTech Hub Specifications

  • Bus Type

    USB 2.0

  • Chipset ID

    FTDI - FT232RL

  • Interface

    Serial

  • Port Style

    External Hub

  • Ports

    16

  • Data Bits

    7, 8

  • FIFO

    256 Bytes

  • Max Baud Rate

    921.6 Kbps

  • Maximum Data Transfer Rate

    480 Mbps

  • Parity

    Odd, Even, Mark, Space, None

  • Serial Protocol

    RS-232

  • Stop Bits

    1, 2

  • Connector Type(s)

    1 - USB B (4 pin) Female
    16 - DB-9 (9 pin; D-Sub) Male

  • OS Compatibility

    Windows 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000, 98SE, XP Embedded, CE (4.2+)
    Windows Server 2012, 2008 R2, 2003
    Mac OS 10.x (tested up to 10.11)
    Linux 2.4.x / 2.6.x

  • LED Indicators

    16 - Data Receive
    16 - Data Transmit

  • Center Tip Polarity

    Positive

  • Input Current

    0.8A

  • Input Voltage

    110 - 240 AC

  • Output Current

    2.5A

  • Output Voltage

    12 DC

  • Plug Type

    N

  • Power Source

    AC Adapter Included

  • Humidity

    5-85% RH

  • Operating Temperature

    -10 to 80 deg. C / 14 to 176 deg. F

  • Storage Temperature

    -20 to 100 deg. C / -4 to 212 deg. F

  • Enclosure Type

    Steel

  • Certifications

    RoHS Complaint
    CE
    FC

  • Dimensions (H x L x W)

    1.8 x 16.9 x 4.7" / 4.57 x 42.93 x 11.94cm

  • Weight

    53.7oz / 1522.37g

  • UPC Code

    065030844789

Related Articles & Videos

Introducing AdoramaXP: Join Hosts Josh Saleh & Seth Miranda on Twitch

Introducing AdoramaXP: Join Hosts Josh Saleh & Seth Miranda on Twitch

Adorama is now on Twitch! Join hosts Josh Saleh and Seth Miranda every Sunday at twitch.tv/AdoramaXP from 12 to 4 PM EST for live streaming the latest games, best throwback titles, and gamer industry news.  "Gaming has been a pa...
Read more

About StarTech Hub

FEATURED REVIEWS

Small so it fits anywhere.

By TedL

Great little hub to add to your desktop or laptop.

Working great in my observatory

By bill1054

I was using a similar product which died after a year or two. The StarTech is installed on my telescope and has every port occupied. The 12v power was important for my application. Here's hoping this hub keeps on doing the job for a long time.

Find unparalleled connectivity and stability with the ICUSB23216F 16-Port Rack Mountable FTDI USB Serial Hub, a high-quality and efficient solution for managing multiple RS232 serial devices. This robust hub supports data transfer rates up to 921.6 Kbps, allowing for swift and reliable communication between your devices and a desktop or laptop computer through a single USB port.

Crafted with durability in mind, the ICUSB23216F features an all-metal chassis that seamlessly integrates into standard 19-inch server storage racks, ensuring a tidy and user-friendly setup in any industrial environment. The rackmount design not only saves valuable workspace but also enhances the organization and accessibility of your serial devices.

The hub's reliable performance is further underscored by its extended operating temperature range of -40°C to 85°C (-40°F to 185°F), making it a reliable choice for use in even the most demanding conditions. Whether you're operating on a factory floor or in a server room, this multiplexer remains operational and efficient.

With COM port retention, the ICUSB23216F ensures consistent device recognition by retaining assigned serial COM port values. This feature guarantees that devices will be automatically reassigned to their designated ports upon reconnection, streamlining your workflow and minimizing setup time.

The ICUSB23216F is equipped with both AC adapter and Terminal Block power options, providing flexibility in power sources to suit various installation requirements. Additionally, the hub utilizes a trusted FTDI USB to serial chipset, which facilitates easy installation across a wide array of operating systems, including Windows, Linux, and Mac OS, without the need for complicated driver installations.

This 16-port RS232 multiplexer is not only a testament to reliability but also to efficiency, as it allows the control of multiple serial devices without the need for numerous I/O cards. Its user-friendly interface and robust construction make it an ideal solution for applications in industrial automation, server room management, surveillance system control, self-service kiosks, POS systems, and bank teller workstations.

Experience the advantage of a hardened operating temperature range, high-speed data transfer, and a rack-mountable, all-metal chassis with the ICUSB23216F 16-Port Rack Mountable FTDI USB Serial Hub, your professional-grade solution for serial device management.

StarTech Hub Features

  • High-speed 16-port RS232 multiplexer for efficient management of multiple serial devices
  • Robust all-metal chassis designed for rack mounting in standard 19-inch server storage racks
  • Extended operating temperature range of -40°C to 85°C for reliable performance in harsh environments
  • Features COM port retention for consistent device recognition and streamlined workflow
  • Includes both AC adapter and Terminal Block power options for versatile installations
  • Compatible with a wide array of operating systems, including Windows, Linux, and Mac OS

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Expand your connectivity with this 16-port USB to Serial adapter hub, perfect for multiple RS232 devices.
  • This FTDI USB to Serial adapter ensures high performance with data transfer rates up to 480 Mbps.
  • Our rackmount RS232 multiplexer supports a wide OS compatibility, including Windows, Mac, and Linux.
  • Enjoy reliable connections with a durable steel enclosure, designed for longevity and robust performance.
  • Simplify your setup using this serial COM adapter, featuring easy-to-read LED indicators for data status.
  • Each serial port supports versatile configurations, including adjustable baud rates and parity options.

What's in the box:

  • StarTech 16 Port RS232 Multiplexer Rackmount FTDI USB to Serial COM Adapter Hub
  • StarTech 2 Year Warranty
