StarTech 1 Port Industrial RS-232/422/485 Serial to IP Ethernet Device Server, 2x 10/100Mbps Ports

The NETRS232485 Serial Device Server lets you remotely manage an industrial RS232/422/485 serial deviceover a local or wide area network (LAN/WAN), with redundant power inputs and dual 10/100Mbps Ethernetports.To minimize downtime, this intuitive dual Ethernet serial over IP solution maintains connection to your criticalequipment by automatically switching to its secondary LAN port within 10 milliseconds of a network failure ordisruption.

• Redundant dual Ethernet ports with < 10ms recovery time
• Up to 460.8 Kbps baud rate
• IP-30 industrial casing and extended operating temperature range
• Redundant power input via 12-48V DC terminal block or optional 12V DC power adapter
• Supports RS232, RS422 and RS485 serial protocols
• Supports ICMP, IP, TCP, UDP, DHCP, BOOTP, ARP/RARP, DNS, SNMP MIB II
• SSL, SSH and HTTPS data encryption and security protocols
• Wall or DIN rail mountable
• Configurable via software utility or web browser
• 8KV air and 4KV contact ESD (Electrostatic Discharge) Protection
• Simultaneous connection with up to five host devices

Ideal for industrial environments, the serial to Ethernet device server accepts wide-range 12-48V DC powerinput via a terminal block or an optional DC jack, enabling you to add redundant power with a secondary adapter(e.g. 12V DC 1.5A Power Adapter SKU: IM12D1500P - sold separately), keeping the device server functional inthe event of power surges or failures.This device server supports baud rates up to 460.8Kbps which provides a smooth, high-speed connection toyour serial devices.

The device server also offers support for HTTPS, SSH and SSL to ensure securecommunication, while integrating remote Telnet configuration and support for IP, HTTP, ICMP, DHCP, TCP andUDP protocols. You can customize the serial device server to suit your application with versatile browser-basedor virtual com port software configuration.Ensuring performance in harsh environments, this serial device server offers 8KV air and 4KV contact ESD(Electrostatic Discharge) Protection and features a rugged, IP-30 case design that is both DIN rail and wallmountable,with an extended operating temperature range (-40deg.C to 70deg.C).Backed by a 5-year StarTech warranty and free lifetime technical support.

Applications
• Factory or warehouse environments subject to harsh conditions and large temperature variances
• Industrial locations where critical equipment requires backup power and LAN connections
• Manufacturing (CNC machinery, process control equipment, serial printers)
• Security (UPS control, access key panels, video cameras, card readers)
• Environmental control (lighting, temperature, clocks)
• POS (credit/debit card readers, receipt printers, cash registers, scales)

Advantage
• Maintain serial connectivity during disruptions with redundant power and network inputs
• Suitable for harsh environments and extended temperatures with a rugged, metal enclosure
• Mount on DIN rails or on a surface with the attached mounting brackets
