Antec 95mm CPU Cooler Fan with Heatsink for Socket LGA1156/1155 with PWM

SKU: STFAN1156PWM

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Antec Cooler Fan Specifications

  • Compatibility

    Socket LGA1156/1155 CPU

  • Fan Bearing Type

    Ever Lubricate Bearing

  • Dimensions

    Fan: 95 x 95 x 25mm / 3.74 x 3.74 x 0.98"
    Heatsink: 95 x 95 x 20mm / 3.74 x 3.74 x 0.79"

  • Heatsink Type

    Aluminum

  • Number of Conductors

    4

  • Air Flow Rate

    65.61 (max) CFM

  • Fan RPM

    1000 - 3000 RPM

  • MTBF

    40000 Hours

  • Noise Level

    <33 dBA

  • Connector Types

    1 - Molex (4 pin; PWM) Female

  • System and Cable Requirements

    Socket LGA1156/LGA1155 motherboard

  • Input Current

    350 mA

  • Input Voltage

    12 DC

  • Certifications

    RoHS Compliant
    CE
    UL

  • Humidity

    0 - 65% RH

  • Operating Temperature

    -10 to 70 deg. C / 14 to 158 deg. F

  • Storage Temperature

    -20 to 70 deg. C / -4 to 158 deg. F

  • Dimensions (H x L x W)

    2.2 x 3.7 x 9.6" / 5.59 x 9.40 x 24.38cm

  • Weight

    9.6oz / 272.16g

  • UPC Code

    065030845380

About Antec Cooler Fan

The FAN1156PWM CPU Cooler with PWM Cooling Fan for Socket LGA1156/1155 systems provides reliable and efficient cooling for compatible Intel Core i3/i5/i7 CPUs. With Pulse Width Modulation (PWM) technology, the fan speed can be dynamically controlled by the motherboard, so the fan runs at a speed that suits the operating conditions - lowering power consumption and fan noise when the system is idle and delivering maximum cooling under full load conditions. Backed by a StarTech 2-year warranty and free lifetime technical support.

• 4-pin Pulse Width Modulation (PWM) motherboard connector
• 95mm Ever Lubricate Bearing fan design
• Aluminum heatsink construction

Advantage
PWM control allows for dynamically variable fan speeds for maximum efficiency
• 95mm Ever Lubricate bearing fan for increased reliability and lifespan compared to traditional sleeve-bearing designs
• Backed by a StarTech 2-year warranty and free lifetime technical support

Applications
Computer systems where the cooling fan does not need to run at full speed all the time, for lower power consumption and noise
• Replace a noisy or failed CPU cooler for an LGA1156/1155 system
• Install an energy-efficient CPU cooler for a build/upgrade for the following system CPUs:

• LGA1156: Core i3 530approx.560, Core i5 650approx.760, 655K, 750S, Core i7 860approx.880, 860S, 870S, 875K
• LGA1155: Core i3 2100, 21020, 2100T, Core i5 2300approx.2500, 2390T, 2400S, 2500K, 25000S, 2500T, Core i7 2600, 2600K, 2600S

What's in the box:

  • StarTech 95mm CPU Cooler Fan with Heatsink
  • Packet of Thermal Compound
  • Backing Plate
  • StarTech 2 Year Warranty
