IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-TX
IEEE 802.1p QoS, IEEE 802.3az Energy-Efficient Ethernet, IEEE 802.3ad Link Aggregation
IP30 (Enclosure)
RJ45 (Gigabit Ethernet)
5
Yes
128 KB
10/100/1000 Mbps
Half-duplex back-pressure and IEEE802.3x full-duplex
Yes
9K max.
328' / 100m
2 Gbps (Full-Duplex)
Store-and-Forward
5x RJ-45 Female
1x Terminal Block (6 Wire) Female
OS Independent; No additional drivers or software required
1x P1 (Power) indicator
1x P2 (Power) indicator
1x ALM (Alarm) indicator
5x Link / Act
5x Speed indicator
12 to 58 DC
3.63W Max.
Terminal Block
5 to 95% RH (Non-Condensing)
-40 to 75 deg. C / -40 to 167 deg. F
-40 to 85 deg. C / -40 to 185 deg. F
Steel
RoHS Compliant
CE
FC
1.1 x 4.4 x 3.5" / 27.94 x 111.76 x 88.9mm
11.6oz / 328.86g
065030859318
Be empowered with the IES51000 5-Port Industrial Ethernet Switch, a high-speed, reliable, and efficient networking solution designed for demanding industrial environments. This durable switch boasts 5 Gigabit Ethernet ports housed in a compact, IP30-rated metal enclosure, making it perfectly suited for challenging conditions found on factory floors, in warehouses, or within large junction boxes.
Experience seamless connectivity with minimal configuration. This user-friendly, unmanaged industrial network switch supports 10/100/1000 Mbps transfer speeds, full/half-duplex auto-negotiation, jumbo frames, and autoMDI/MDIX. These features collectively eliminate the need for troubleshooting mismatched speed and duplex settings, ensuring a smooth and efficient networking experience.
The IES51000 switch is equipped with five 10/100/1000 Mbps unmanaged RJ45 Ethernet ports, providing ample bandwidth for high-demand applications. Its IP30-rated DIN rail and wall-mountable metal enclosure ensures durability and flexibility in installation.
For uninterrupted operation, the switch features wide-range redundant power via two 12-58V DC terminal block inputs, complete with an alarm relay. This ensures seamless operation even in the event of power dips or failures, minimizing unnecessary downtime. When used with two power sources, the switch supports alarm relay contacts that can be wired to your existing alarm circuit, providing instant notification when a power disruption occurs.
Designed for optimal performance in harsh environments, the switch can be DIN Rail or wall-mounted. Its compact, IP30-rated enclosure withstands an extended operating temperature range (-40deg.C to 75deg.C).
Ideal for industrial applications such as warehouses and junction boxes without temperature control, the IES51000 switch is also suitable for enhancing Gigabit Ethernet on factory or manufacturing floors, and for integrating small workgroups into an existing network. Its robust design and redundant power inputs ensure seamless performance even in harsh industrial conditions, while its flexible installation options allow you to position the switch exactly where you need it.
Note: This product is backed by a StarTech 2-year warranty and free lifetime technical support.
