Securitytronix 24 Port 10/100 Ethernet PoE Switch
See all Securitytronix items

Securitytronix 24 Port 10/100 Ethernet PoE Switch with 2x Gigabit RJ-45 Ports & 2x Gigabit SFP Slots

SKU: STPOE24ULRM

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Securitytronix PoE Switch Specifications

  • Power LED

    LED on: Power ON / LED off: Power off

  • LINK/ACT

    LED on: this port is Link and Active
    LED off: this port is not correct Link or inactive

  • PoE (2x to 5x)

    LED on: The PoE power device (PD) is connected and the port is supplying power successfully
    LED off: no PoE power device (PD) connected

  • Standard

    IEEE 802.3 10BASE-T Ethernet
    IEEE 802.3u 100BASE-TX Fast Ethernet
    IEEE 802.3x Full Duplex Flow Control
    IEEE 802.3 af Power over Ethernet

  • Protocol

    CSMA/CD

  • Data Transfer Rate

    Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex)
    Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex)

  • Network Cables

    10BASE-T: 2-pair UTP Cat 3, 4, 5 up to 100 meters
    100BASE-Tx: 2-pair UTP Cat 5, 5e up to 100 meters
    1000BASE-Tx: 4-pair UTP Cat 5e, 6 up to 100 meters

  • Number of Ports

    24 x 10/100Mbps auto-MDIX RJ-45 PoE-enabled ports
    2 x 10/100/1000Mbps auto-MDIX RJ-45 ports
    2 x 10/100/1000Mbps auto-MDIX SFP slots

  • PoE power on RJ-45

    Power +: ping 3 & ping 6: Power -" ping 1 & ping 2

  • AC to DC power adaptor

    Input: 100V - 240VAC, 50Hz - 60Hz
    Output: 48VDC/1.5A af

  • Power Consumption

    6.4 watts (max with no PD device connected)
    350watts (24 PoE ports af)

  • Operating Temperature

    33 to 104 deg. F (1 to 40 deg. C)

  • Storage Temperature

    -10 to 70 deg. C (14 to 158 deg. F)

  • Humidity

    Relative Humidity: 5% - 95%

  • EMI

    FCC Class B, CE Mark Class B

  • Safety

    100VAC to 240VAC power adaptor UL listed

  • RAM buffer

    2.75mb per device

  • Filtering Address Table

    4K entries per device

  • Packet

    10/100/1000Mbps Ethernet: 14,880/148,800/1,488,000pps

  • MAC address Learning

    Automatic update

  • Dimensions (WxDxH)

    430 x 256 x 66mm (16.93 x 10.08 x 2.60")

About Securitytronix PoE Switch

Power over Ethernet (PoE) integrates 48VDC power and data onto one single cable, eliminating the need to have AC power available at all equipment locations. Power and Data are integrated onto the same cable, supporting category 5/5e up to 100 Meters. PoE provides power to PoE compatible devices, such as VOIP telephones, wireless LAN access points and IP security cameras. PoE devices are readily in the market, saving up to 50% of overall installation cost by eliminating the need to install separate electrical wiring and power outlets.

Securitytronix PoE Switch Features

  • 24 x 10/100Mbps auto-negotiation Fast Ethernet RJ-45 ports with PoE function, compliant with IEEE 802.3 af specification. 2 x 10/100/1000 auto-negotiation RJ-45 ports. 2 x 10/100/1000 auto-negotiation SFP ports
  • Supports PoE IEEE802.3 af compliant Powered Device (PD)
  • Each port supports auto MDI/MDIX, so there is no need to use cross-over cables
  • Full/half duplex transfer mode for each port
  • Wire speed reception and transmission
  • Up to 4K unicast address entities per device. Self-learning and table aging
  • 2.75MBytes packet buffer
  • Two copper Gigabit RJ-45 ports, Two Gigabit SFP slots
  • Front panel Ethernet connections
  • Front panel LED indicators for link & power identification
  • Rear panel On/Off switch
  • IEEE 802.3af
  • Desktop or 19" rack mount configuration
  • Includes power supply, 48V, 350W

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Securitytronix 24 Port 10/100 Ethernet PoE Switch
  • Power Supply
  • Securitytronix 1 Year Limited Warranty
