StarTech 2.5" Dual-Bay USB 3.1 to SATA III 10Gbps External Enclosure with RAID
StarTech External Enclosure: Picture 1 thumbnail
StarTech External Enclosure: Picture 2 thumbnail
StarTech External Enclosure: Picture 3 thumbnail
StarTech External Enclosure: Picture 4 thumbnail
StarTech External Enclosure: Picture 5 thumbnail
See all StarTech items

StarTech 2.5" Dual-Bay USB 3.1 to SATA III 10Gbps External Enclosure with RAID

SKU: STS252BU313R MFR: S252BU313R
(5)Ask a Question
$130.99
Earn VIP Reward Points

Key Features

  • Experience rapid data transfers with this dual-bay enclosure, up to 10 Gbps via USB 3.1.
  • Safeguard your data using RAID 0/1 modes for mirrored or striped drive configurations.
  • This 2.5" SATA III enclosure supports up to 2TB drives, perfect for backups and archives.
  • Enjoy broad compatibility; this enclosure is OS independent, no drivers are needed!
  • Compact aluminum enclosure with fan ensures your drives stay cool, prolonging their life.
  • Easily set up your dual hard drives with included tools and enjoy a 2-year StarTech warranty.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$7.99

2 Year

$12.99

3 Year

$21.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2023-01-14T19:00:00

Rated 1 out of 5

Loosing data between PC's

I have been using S3520BU33ER for many years between home and work as common drive. I bought a S252BU313R and fitted 2TB hard drives. If I work at home and then take the hard drive to work the next day, the files created at home show but will not open and then promptly disappear. They cannot be seen on my home or work PC-gone. I even bought a new DELL for home, thinking it might be the PC, and the same thing happens. I have lost all confidence in the product. Is it hardware, firmware, TRIM?

Peeps

2022-12-06T19:00:00

Rated 1 out of 5

Not a great experience so far...

Shipped with either wrong power supply, or they changed the plug on the body of the unit and didn't notify the people adding the power supply to change the plug. Either way....unit not usable. Replacement on the way.

501Merritt

2021-07-22T20:00:00

Rated 2 out of 5

Worked great for a lil bit

Bought this a few months ago, almost a year and it worked great. Now it does not show up when I plug it in no matter what I do with it. (Windows 10, Windows 11). At first every time I plugged it in my mouse cursor would creep all over the screen. As soon as I unplugged this device my cursor would go back to normal. THERE ARE NO DRIVERS THAT I CAN FIND!

derikdark

2018-05-01T20:00:00

Rated 5 out of 5

Super fast Data Transfers, True USB 3.1 raid drive

Using XPS 8930, 2xSSDs in Raid 0, large files; Write all day long at 500MB/sec, read 700MB/sec the limited only by the desktop. Excellent external Raid enclosure for two SATA drives.

StevenA2

2018-03-23T20:00:00

Rated 1 out of 5

Slow on USB 3.0

Should be getting close to 1Gbps with 2x SSD drives Raid 0, only getting around 250Mbps transfer speeds on USB 3.0. Disappointing!

Microking4u

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

StarTech External Enclosure Specifications

  • Bus Type

    USB 3.1 Gen 2

  • Chipset ID

    ASMedia - ASM1352R

  • Compatible Drive Types (Type and Rate)

    SATA

  • Drive Installation

    Fixed

  • Drive Size

    2.5" / 63.50mm

  • Fan Bearing Type

    Sleeve Bearing

  • Fan

    Yes

  • Fans

    1 - 30mm

  • Interface

    USB 3.1 Gen 2

  • Number of Drives

    2

  • Max Drive Capacity

    2TB

  • Maximum Data Transfer Rate

    10 Gbps

  • RAID

    Yes

  • Supported RAID Modes

    RAID 0 (Striped Disks)
    RAID 1 (Mirrored Disks)
    BIG (Spanning or Concatenation)
    JBOD - (Just a Bunch of Disks)

  • Type and Rate

    USB 3.1 Gen 2 - 10 Gbit/s

  • Drive Connectors

    2x SATA Data & Power Combo (7+15 pin)

  • Host Connectors

    1x USB 3.1 USB Type Micro-B (10 pin; Gen 2; 10 Gbps)

  • OS Compatibility

    OS independent; No software or drivers required

  • LED Indicators

    1x Power
    1x Read and Write-HDD1
    1x Read and Write-HDD2

  • Center Tip Polarity

    Positive

  • Input Current

    0.8

  • Input Voltage

    110 to 240 AC

  • Output Current

    2A

  • Output Voltage

    12 DC

  • Plug Type

    B

  • Humidity

    20 to 80% RH

  • Operating Temperature

    5 to 35 deg. C / 41 to 95 deg. F

  • Storage Temperature

    -20 to 50 deg. C / -4 to 122 deg. F

  • Enclosure Type

    Aluminum

  • Certifications

    RoHS Compliant
    CE
    FC

  • Dimensions (H x L x W)

    2.4 x 5.8 x 3.2" / 60.96 x 147.32 x 81.28mm

  • Weight

    13.3oz / 377.05g

  • UPC Code

    065030862028

About StarTech External Enclosure

FEATURED REVIEWS

Super fast Data Transfers, True USB 3.1 raid drive

By StevenA2

Using XPS 8930, 2xSSDs in Raid 0, large files; Write all day long at 500MB/sec, read 700MB/sec the limited only by the desktop. Excellent external Raid enclosure for two SATA drives.

Discover the power and versatility of our 2.5" Dual-Bay USB 3.1 to SATA III 10Gbps External Enclosure with RAID. This compact yet high-performance device offers a robust solution for your external data storage needs, delivering ultra-fast data transfer speeds and configurable RAID modes. It's an ideal choice for small businesses, home offices, graphic designers, engineers, and other professionals who require top-tier workstations.

This dual-bay enclosure is designed to create a high-capacity external storage solution, supporting two 2.5" SSDs/HDDs in a wide range of sizes from 5 to 12.5mm, with capacities up to and beyond 2TB. Crafted from solid aluminum, this enclosure is not only durable but also offers superior heat dissipation to keep your drives running smoothly.

Experience the speed of USB 3.1 Gen 2, which provides greater bandwidth and speed, supporting transfer rates of up to 10Gbps - twice the speed of USB 3.0 (USB 3.1 Gen 1) technology. This feature allows you to leverage the high performance of the latest SSDs and hard drives, eliminating bottlenecks in your data transfers.

Our dual-bay enclosure comes with two USB cables for maximum versatility. It includes both USB-C to Micro B and USB-A to Micro B cables, ensuring compatibility with the latest laptops and tablets equipped with a USB-C port, as well as legacy devices. Moreover, it's compatible with a Thunderbolt 3 USB-C port.

Achieve enhanced performance through RAID with our dual-bay enclosure. It supports RAID 0, 1, Big (Spanning or Concatenation), and JBOD, allowing you to maximize the performance of your SATA III SSDs for greater file transfer speeds. With multiple RAID options, you can gain increased storage size, performance, or redundancy.

This enclosure is OS independent, requiring no additional software or drivers, making it a user-friendly solution for expanding your external storage capacity. Whether you're looking to increase the storage of your laptop or PC, or need extra storage to back-up important files, our 2.5" Dual-Bay USB 3.1 to SATA III 10Gbps External Enclosure with RAID is the reliable and high-performance solution you need.

StarTech External Enclosure Features

  • High-speed 2.5" Dual-Bay USB 3.1 to SATA III Enclosure with up to 10Gbps transfer rates
  • Configurable RAID modes for optimized data redundancy and performance
  • Durable aluminum construction with fan & speed control for enhanced drive longevity
  • Compatible with USB-C, USB-A, and Thunderbolt 3 USB-C ports for versatile connectivity
  • Supports a wide range of SSD/HDD sizes with capacities exceeding 2TB
  • OS independent with UASP support for plug-and-play setup and increased SATA performance

Warranty Information

This product has a limited warranty of 24 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience rapid data transfers with this dual-bay enclosure, up to 10 Gbps via USB 3.1.
  • Safeguard your data using RAID 0/1 modes for mirrored or striped drive configurations.
  • This 2.5" SATA III enclosure supports up to 2TB drives, perfect for backups and archives.
  • Enjoy broad compatibility; this enclosure is OS independent, no drivers are needed!
  • Compact aluminum enclosure with fan ensures your drives stay cool, prolonging their life.
  • Easily set up your dual hard drives with included tools and enjoy a 2-year StarTech warranty.

What's in the box:

  • StarTech 2.5 " Dual-Bay USB 3.1 to SATA III 10Gbps External Enclosure with RAID
  • USB C to Micro B Cable
  • USB A to Micro B Cable
  • Universal Power Adapter (NA/EU/UK/AU)
  • 2x Drive Tray
  • 2x Allen Key
  • 4x Rubber Feet
  • Instruction Manual
  • StarTech 2 Year Warranty
