StarTech 1 Port PoE RS232 Serial Ethernet Device Server

SKU: STTRS2321POE MFR: NETRS2321POE
(9)Ask a Question
$142.99
Earn VIP Reward Points

Key Features

  • Easily convert RS232 serial devices to Ethernet with this reliable device server.
  • Utilize Power-over-Ethernet (PoE) for flexible placement & reduced cabling costs.
  • Achieve real-time data transfer with a maximum data rate of up to 115.2Kbps.
  • Enjoy broad compatibility with Windows Vista, XP, and 2000 operating systems.
  • Ensure stable performance with a robust design and a MTBF of 233,403 hours.
  • Simplify integration using supported protocols: UDP, IP, TCP, HTTP, DHCP, ARP-Ping.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$9.99

2 Year

$14.99

3 Year

$23.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2022-09-18T20:00:00

Rated 5 out of 5

Best RS232 over IP in the Business !!!

I have used and tried several SERIAL over IP Ethernet devices and Startech RS2321P Coupled with their Setup software and VCOM virtual comport software for Windows makes this Hands Down best Available for the price ,, Fast, easy setup and configuration, had this up and running within 5 minutes, no lie, ,, if you need a RS232 Serial connection in the field that you can access with your tools from your office well this is it ,, the easiest and quickest on the market !! Thank you Startech you've helped us out again !!

TechGuy_Steven

2020-09-21T20:00:00

Rated 1 out of 5

Nothing in setup changes the arguments for serial.

I have this setup to a US Robotics modem, and use Putty to telnet to port 100 of the serial server. The Web-UI has the baud rate locked at 115200-8N1. However, the modem keeps reporting the speed being locked at 9600, no matter what baud rate I put in the WebUI. I mean, I can deal with 9600, but still, I'd expect the WebUI to change the argument if it's an option.

acadiel

2020-09-10T20:00:00

Rated 1 out of 5

Very Disappointed

I bought this device because the locations I'll be using in have a POE port but not a power receptacle. There's no excuse for why other very similar devices are supported by Windows 10, but not this device. I had to buy 3rd party software to use this device in my application. Once I found software that can work with this device, it does exactly what I needed it to do.

FrankB

2019-11-10T19:00:00

Rated 5 out of 5

Works really well

I had an issue with the first adapter, I could not update the firmware. But customer support was beyond excellent, and a new adapter was shipped to me. The adapter works right out of the box, and setup was easy and straight forward.

LA9AKA

2019-10-21T20:00:00

Rated 5 out of 5

Easy to use and install

Worked out of the box connecting it to an alarm system.

ryan2019

2017-10-19T20:00:00

Rated 1 out of 5

Does not support win7/10

Just bought it, needed a poe rs232. This fit the bill, made the wrong assumption that it would be supported on newer OS Needless to say, I am not happy at my laziness.

Stealthsingh

2017-07-26T20:00:00

Rated 1 out of 5

Device not seen by Startech DS-Tool software

We use a StarTech NETRS42348PD device with their DS-Tool software (V1.2) and expected that this device would be seen by that software. It is not, and as such is of no use to us because we run Windows 7 or higher. This oversite should be corrected by StarTech.

Stephen

2016-07-07T20:00:00

Rated 1 out of 5

Doesn't work with today's operating systems.

Can't use with Windows 7 or 10. Only works with older, unsupported operating systems.

Chris P.

2016-04-20T20:00:00

Rated 4 out of 5

Over all device works well.

This worked well for us. The instruction could be better. But if you have setup IP addresses before the web tool is very easy to use.

John02

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

StarTech Device Server Specifications

  • Industry Standards

    IEEE 802.3af Power-over-Ethernet

  • Data Bits

    6, 7, 8

  • Maximum Data Transfer Rate

    115.2Kbps

  • MTBF

    233,403 Hours

  • Stop Bits

    1, 2

  • Supported Protocols

    UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping

  • Connector Type(s)

    1 - DB-9 (9 pin; D-Sub) Male
    1 - RJ-45 Female

  • OS Compatibility

    Windows Vista (32), XP (32), 2000

  • Patents and Licenses

    This list might not be all inclusive.
    United States Patent No. 5,406,260 (expired)
    United States Patent No. 6,650,622
    United States Patent No. 7,457,250
    United States Patent No. 8,155,012
    United States Patent No. 8,902,760
    United States Patent No. 8,942,107
    United States Patent No. 9,019,838
    United States Patent No. 9,049,019
    United States Patent Application No. 14/695,456
    United States Patent Application No. 14/726,940

  • LED Indicators

    3 - Heartbeat, Link/Activity, 10/100 Mbps

  • Center Tip Polarity

    Positive

  • Input Current

    0.3 A

  • Input Voltage

    110 - 240 AC

  • Output Current

    0.1A

  • Output Voltage

    12 DC

  • Plug Type

    M

  • Power Source

    AC Adapter Included

  • Humidity

    5-95% RH

  • Operating Temperature

    0 to 55 deg. C / 32 to 131 deg. F

  • Storage Temperature

    -20 to 85 deg. C / -4 to 185 deg. F

  • Enclosure Type

    Aluminum

  • Certifications

    RoHS Complaint
    CE
    FC

  • Dimensions (H x L x W)

    1 x 4.2 x 2.6" / 2.54 x 10.67 x 6.6cm

  • Weight

    16.9oz / 479.11g

  • UPC Code

    065030834162

About StarTech Device Server

FEATURED REVIEWS

Works really well

By LA9AKA

I had an issue with the first adapter, I could not update the firmware. But customer support was beyond excellent, and a new adapter was shipped to me. The adapter works right out of the box, and setup was easy and straight forward.

Best RS232 over IP in the Business !!!

By TechGuy_Steven

I have used and tried several SERIAL over IP Ethernet devices and Startech RS2321P Coupled with their Setup software and VCOM virtual comport software for Windows makes this Hands Down best Available for the price ,, Fast, easy setup and configuration, had this up and running within 5 minutes, no lie, ,, if you need a RS232 Serial connection in the field that you can access with your tools from your office well this is it ,, the easiest and quickest on the market !! Thank you Startech you've...

View full Review

The NETRS2321POE 1 Port RS232 Serial Ethernet Device Server - PoE (Power over Ethernet) is an innovative solution that allows seamless integration of your RS232 devices into your TCP/IP Ethernet WAN/LAN. This device gives you the convenience of accessing your RS232 devices as if they were right beside you, even when you're connecting over the Internet.

Designed with versatility in mind, this Serial Device Server functions harmoniously with your integrated and add-on serial ports, as if they were directly installed in your computer. It's an ideal choice for a variety of applications, including industrial automation, security, Point of Sale, or any long-range serial application, ensuring reliable performance in any environment.

One of the standout features of this Ethernet/serial device server is its support for PoE (Power over Ethernet). When connected to a PoE compliant device, it eliminates the need for an external power supply and outlet. This feature simplifies the positioning of the device server as per your needs.

The NETRS2321POE 1 Port RS232 Serial Ethernet Device Server supports standard Ethernet or Power over Ethernet (POE) and a variety of protocols including UDP, IP, TCP, ICMP, HTTP, DHCP, and ARP-Ping. It's wall-mountable for easy installation and features an integrated 10/100Mbps RJ45 LAN port. With data transfer rates of up to 115.2 Kbps per port, it ensures efficient communication between your devices.

The device server supports Auto Crossover (MDI/MDI-X) and is compatible with Windows 2000, XP 32bit, and Vista 32bit. The PoE support provides the flexibility to position your serial device where it's most needed, even when a power outlet is not available. The IP-based connection to your serial devices allows for remote administration from anywhere, even over the Internet.

Whether you're in manufacturing, security, environmental control, POS, healthcare, or hospitality, the NETRS2321POE 1 Port RS232 Serial Ethernet Device Server is a reliable solution for connecting and managing your RS232 devices.

StarTech Device Server Features

  • PoE (Power over Ethernet) support for convenient placement and power supply
  • Seamless integration with TCP/IP Ethernet WAN/LAN for remote access
  • Supports multiple protocols including UDP, IP, TCP, ICMP, HTTP, DHCP, and ARP-Ping
  • Wall-mountable design with an integrated 10/100Mbps RJ45 LAN port
  • High data transfer rates of up to 115.2 Kbps per port
  • Compatibility with Windows 2000, XP 32bit, and Vista 32bit for broad usage

Warranty Information

This product has a limited warranty of 24 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Easily convert RS232 serial devices to Ethernet with this reliable device server.
  • Utilize Power-over-Ethernet (PoE) for flexible placement & reduced cabling costs.
  • Achieve real-time data transfer with a maximum data rate of up to 115.2Kbps.
  • Enjoy broad compatibility with Windows Vista, XP, and 2000 operating systems.
  • Ensure stable performance with a robust design and a MTBF of 233,403 hours.
  • Simplify integration using supported protocols: UDP, IP, TCP, HTTP, DHCP, ARP-Ping.

What's in the box:

  • StarTech 1 Port RS232 Serial Ethernet Device Server
  • Universal Power Adapter (NA/UK/EU)
  • Driver CD
  • Instruction Manual
  • StarTech 2 Year Warranty
