Switchcraft Male Housing (No Push Latch), Nickel
See all Switchcraft items

Switchcraft E Series Male Housing (No Push Latch), Nickel

SKU: SWEMH
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the E Series Male Housing made of?

The E Series Male Housing is made of nickel-plated brass, known for its durability and resistance to corrosion and wear.

Who is the manufacturer of the E Series Male Housing?

The E Series Male Housing is manufactured by Switchcraft, a reputable brand known for producing high-quality electronic components.

What is the purpose of the quick-release inserts in the E Series Male Housing?

The quick-release inserts in the E Series Male Housing facilitate easy panel mounting and allow for straightforward gender changes with the use of a small screwdriver.

Is the E Series Male Housing suitable for all electronic devices?

The E Series Male Housing is designed to be versatile and is ideal for a variety of electronic device applications.

What makes the E Series Male Housing durable?

The E Series Male Housing's durability comes from its robust, nickel-plated brass construction, which is resistant to wear and corrosion.

Reviews about this item

Review Summary

Switchcraft Male Housing (No Push Latch), Nickel Specifications

  • Contact Resistance

    50 mOhms maximum, per pole

  • Current Rating

    15A

  • Insulation Resistance

    2 X 106 M(omega)

  • Dielectric Resistance

    1,000 V rms

  • Capacitance

    10 pF

  • Insertion/Withdrawal Forces

    7 pounds maximum/5 pounds nominal insertion; 7 pounds maximum/5 pounds nominal withdrawal

  • Life

    10,000 operations (minimum)

  • Thermal Range

    -55 to +85deg. C / -67 to 185deg. F

  • Humidity

    Meets MIL-STD-202F, method 106E

  • Thermal Shock

    Meets MIL-STD-202F, method 107D

  • Salt Spray

    Meets MIL-STD-202F, method 101D

  • Shells

    Satin-nickel

  • Inserts

    Glass-filled thermoplastic

  • Socket Contacts

    Copper alloy, silver- or gold-plated

  • Pin Contacts

    Copper alloy, silver- or gold-plated

  • Latch Release

    Nickel-plated

  • Insert Locking Cam

    Die-cast zinc

About Switchcraft Male Housing (No Push Latch), Nickel

The E Series Male Nickel Housing (No Push Latch) offers a panel mount with quick release inserts. A small screwdriver can be used to remove the inserts, allowing for easy gender changes.
