Switchcraft True 75 Ohms HD BNC Connector for Belden 1694A/95A
See all Switchcraft items

Switchcraft True 75 Ohms HD Cable Mount BNC Connector with 3 Pieces Crimp for Belden 1694A/95A, Draka 1.0/4.8AF

SKU: SWHP75BNC7X
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Switchcraft : Picture 1 regular
Switchcraft 75 Ohm BNC Female Feedthru Isolated Jack with 4-40 Screws, Black
$21.72$9.19
Switchcraft : Picture 1 regular
Switchcraft 75 Ohm BNC Female Feedthru Isolated Jack with 4-40 Screws, Nickel
$18.65
Switchcraft : Picture 1 regular
Switchcraft True 75 Ohms HD BNC Connector with 3 Pieces Crimp for Belden 1695A
$3.05$2.90
See More Recommendations
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the gold-plated center pins in the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector?

The gold-plated center pins in the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector enhance the connector's lifespan and ensure optimal signal transmission for a seamless audio and video experience.

What cable types is the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector compatible with?

The Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector is specifically engineered for Belden 1694A/95A and Draka 1.0/4.8AF, making it suitable for a wide range of cable types.

What standards does the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector meet?

The Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector is designed to meet SDI-SMPTE standards, ensuring its compatibility with professional video equipment.

What does the 3GHz rating of the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector mean?

The 3GHz rating of the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector indicates its ability to handle high-definition signals with ease.

Who is the manufacturer of the Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector?

The Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector is manufactured by Switchcraft, a reputable brand known for producing high-quality connectors.

Reviews about this item

Review Summary

Switchcraft True 75 Ohms HD BNC Connector for Belden 1694A/95A Specifications

  • RoHS

    Yes

  • Characteristic Impedance

    75 Ohms

  • Voltage Rating

    500 Volts RMS

  • Return Loss

    Less than -25 db at 3 GHz

  • Insulation Resistance

    5000 MegaOhms min

  • Lifecycles

    500 min

  • Center Contact Retention

    Minimum: 6lbs (2.72kg)

  • Coupling Mechanism

    Minimum: 100lbs (45.35kg)

  • Force to Engage

    Maximum: 2.5lbs (1.13kg)

  • Thermal Shock

    -65 deg. C to 165 deg. C (-85 deg. F to 329 deg. F)

  • Moisture Resistance

    Mil Std 202

  • Corrosion

    Mil Std 202

  • Flammability

    UL 94-VO

  • Vibration

    Mil Std 202

  • Solvent Resistance

    Mil Std 202

  • Body/Bayonet

    Nickel-plated copper alloy

  • Center Conductor

    50 mi gold-plated copper alloy

  • Cable Type

    Belden 1417B, 1855A, 1864A/65A
    Gepco VDM230, VDM250
    RGB230/250
    Comm/Scope 7537, 7538

About Switchcraft True 75 Ohms HD BNC Connector for Belden 1694A/95A

The Switchcraft True HP75BNC7x 75 Ohms HD Cable Mount BNC Connector is rated at 3GHz. It is specially developed for for Belden 1694A/95A. It has gold-plated center pins for increased life. It is used for wide range of cable types. The Switchcraft HP75BNC7x is outstanding electrical performance. It is rugged nickel-plated and machined shells. The Switchcraft HP75BNC7x is made to mate up in such a way to maintain signal integrity from device to antenna.
