Switchcraft HPC Round Panel Mount Receptacle, .200" Flange, .187" Internal Faston
See all Switchcraft items

Switchcraft Speakon Round Panel Mount Receptacle, .152" Dia Countersunk Mounting Holes, .200" Flange Depth, .187" Internal Faston Terminals

SKU: SWHPCPR42F1

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What brand is the Speakon Round Panel Mount Receptacle from?

The Speakon Round Panel Mount Receptacle is from the trusted brand, Switchcraft.

What is the diameter of the countersunk mounting holes on the Speakon Round Panel Mount Receptacle?

The Speakon Round Panel Mount Receptacle features .152" diameter countersunk mounting holes.

What is the contact rating of the Speakon Round Panel Mount Receptacle?

The Speakon Round Panel Mount Receptacle enhances the contact ratings to 50A per UL 1977 on Faston versions.

What is the flange depth of the Speakon Round Panel Mount Receptacle?

The Speakon Round Panel Mount Receptacle has a flange depth of .200".

Does the Speakon Round Panel Mount Receptacle come with a mounting post?

Yes, the Speakon Round Panel Mount Receptacle has an optional mounting post for snap-on connection to the PC board for wave soldering.

Reviews about this item

Review Summary

Switchcraft HPC Round Panel Mount Receptacle, .200" Flange, .187" Internal Faston Specifications

  • RoHS

    Yes

  • Gender

    Female

  • Number of Positions

    4

  • Termination Style

    Quick Disconnect

  • Mounting Style

    Chassis (Panel)

  • Contact Plating

    Silver

  • Contact Material

    Copper Alloy

  • Voltage Rating

    1.5 kV

  • Current Rating

    50 A

  • Faston Terminals

    0.187" (0.47cm)

  • Countersunk Mounting Holes

    Diameter: 0.152" (0.38cm)

  • Flange Depth

    0.200" (0.50cm)

About Switchcraft HPC Round Panel Mount Receptacle, .200" Flange, .187" Internal Faston

The Switchcraft Speakon Round Panel Mount Receptacle (.152" Dia Countersunk Mounting Holes) is updated with new silver-plated contact materials that boost the contact ratings to 50A per UL 1977 on Faston versions. It has 0.200" depth flanges that allows for rear mounting of the HPC Series and proper mating of all cord plugs. The panel mount has 0.187" Faston terminals and either straight or right angle PC mount terminals. It also has, as an option, a mounting post which allows the connector to snap onto the PC board for wave soldering.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Switchcraft Speakon Round Panel Mount Receptacle
  • Switchcraft Lifetime Limited Warranty
