Switchcraft HPC Round Panel Mount Receptacle, .200" Flange, Epoxy Sealed
See all Switchcraft items

Switchcraft Speakon Round Panel Mount Receptacle, .152" Dia Countersunk Mounting Holes, .200" Flange Depth, .187" Internal Faston Terminals, Epoxy Sealed

SKU: SWHPCPR42F1S

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the countersunk mounting holes in the Switchcraft Speakon Round Panel Mount Receptacle?

The .152" diameter countersunk mounting holes allow for a seamless and secure installation of the receptacle, enhancing its stability and performance.

What is the significance of the epoxy-sealed construction?

The epoxy-sealed construction of the Switchcraft Speakon Round Panel Mount Receptacle ensures its durability and reliability, protecting your audio and video equipment from potential damage.

What does the 0.200" flange depth mean for the user?

The 0.200" flange depth allows for rear mounting of the HPC Series and ensures proper mating of all cord plugs, enhancing the receptacle's versatility and compatibility with various setups.

What are the 0.187" Faston terminals used for?

The 0.187" Faston terminals can accommodate either straight or right-angle PC mount terminals, offering flexibility in installation options to cater to specific needs and preferences.

What is the function of the optional mounting post?

The optional mounting post enables the connector to snap onto the PC board for wave soldering, simplifying the installation process and ensuring a secure connection.

Reviews about this item

Review Summary

Switchcraft HPC Round Panel Mount Receptacle, .200" Flange, Epoxy Sealed Specifications

  • RoHS

    Yes

  • Number of Positions

    4

  • Termination Style

    Quick Disconnect

  • Mounting Style

    Chassis (Panel)

  • Contact Plating

    Silver

  • Contact Material

    Copper Alloy

  • Voltage Rating

    1.5 kV

  • Current Rating

    50 A

  • Faston Terminals

    0.187" (0.47cm)

  • Countersunk Mounting Holes

    Diameter: 0.152" (0.38cm)

  • Flange Depth

    0.200" (0.50cm)

About Switchcraft HPC Round Panel Mount Receptacle, .200" Flange, Epoxy Sealed

The Switchcraft Speakon Round Panel Mount Receptacle (.152" Dia Countersunk Mounting Holes, Epoxy Sealed) is updated with new silver-plated contact materials that boost the contact ratings to 50A per UL 1977 on Faston versions. It has 0.200" depth flanges that allows for rear mounting of the HPC Series and proper mating of all cord plugs. The panel mount has 0.187" Faston terminals and either straight or right angle PC mount terminals. It also has, as an option, a mounting post which allows the connector to snap onto the PC board for wave soldering.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Switchcraft Speakon Round Panel Mount Receptacle
  • Switchcraft Lifetime Limited Warranty
