Switchcraft 2x24 Point Long Frame With Solder Lug Input/Output and Cable Tray, 1RU, Half Normalled

SKU: SWMT48K1HNX MFR: MT48K1HNX
Earn VIP Reward Points

Key Features

  • Optimize your audio signal flow with this 48-point patch bay for superior sound quality.
  • Enhance connectivity using this half-normalled patch bay, perfect for complex audio setups.
  • Experience durable performance with Switchcraft's steel frame, nickel-plated for lasting use.
  • Easily manage your cables with the integrated cable tray, keeping your setup organized.
  • Achieve clear audio routing with low contact resistance, ensuring optimal signal transfer.
  • Simplify your workflow using this user-friendly patch bay, designed for quick adjustments.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 1RU, Half Normalled Specifications

  • Material 1

    Jacks:
    Frame: Steel, nickel-plated
    Bushing: Brass, nickel-plated
    Springs: Nickel silver solder lugs
    Ground Terminal: Nickel silver, solder lugs
    Switching Contacts: Welded, gold alloy
    Insulation: Phenolic spacers, rigid PVC tubing through stack
    Screws: Steel, nickel-plated

  • Material 2

    Panels:
    Jack Panel: Thermoplastic
    Cable Support Bracket: 5/16" diameter black epoxy painted steel rod
    Screws (designation strip): Steel, black zinc-plated
    Screws (mounting jack): Steel, nickel plated
    Kwik-change Designation Strip: Extruded aluminum, black anodized
    Marking Strip: White plastic, matte finish
    Marking Strip Cover: Clear, extruded plastic

  • Resistance

    Contact: 30 mOhms maximum initial
    Insulation Resistance: 10,000 megaOhms maximum

  • Dielectric Withstanding Voltage

    500V at 60 Hz AC

  • Working Voltage

    140 VDC maximum

  • Current Rating

    100 milliamps

  • Number of Jacks

    48

  • Normalling

    Half Normalled

  • Dimensions

    Height: 1 Rack Unit 1.75" (4.44cm)
    Depth: 8.8" (22.35cm)

About Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 1RU, Half Normalled

When seeking a reliable and versatile solution for your professional audio and video needs, consider the Switchcraft 2x24 Point Long Frame with Solder Lug Input/Output and Cable Tray. This 1RU, half-normalled device is a testament to Switchcraft's reputation for producing high-quality, durable equipment.

Designed for a myriad of applications, this product is ideal for live events, recording studios, and other professional settings. Its 1RU height makes it perfectly suited for rack mounting or installation within other equipment enclosures, ensuring seamless integration into your existing setup.

The Switchcraft 2x24 Point Long Frame stands out with its 24 input/output points, each equipped with a solder lug connector. This feature allows for secure and efficient connections, enhancing the overall performance of your audio and video systems.

Moreover, the device includes a cable tray, a thoughtful addition that aids in the organization and routing of cables. This feature not only promotes a neat and tidy workspace but also contributes to the longevity of your cables by preventing tangling and damage.

Crafted by Switchcraft, a renowned manufacturer in the professional audio and video connectivity industry, this 2x24 Point Long Frame with Solder Lug Input/Output and Cable Tray is a robust and professional-grade solution that delivers consistent, high-quality performance.

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 1RU, Half Normalled Features

  • Professional-grade 2x24 point long frame patchbay by Switchcraft for studio and live setups
  • Half-normalled design with 1RU height for easy rack mounting
  • Durable solder lug connectors ensure reliable audio/video signal flow
  • Integrated cable tray for efficient cable management and organization
  • Versatile connectivity options suitable for a variety of professional applications
  • High-quality metal chassis construction for lasting performance and protection

Key Features

  • Optimize your audio signal flow with this 48-point patch bay for superior sound quality.
  • Enhance connectivity using this half-normalled patch bay, perfect for complex audio setups.
  • Experience durable performance with Switchcraft's steel frame, nickel-plated for lasting use.
  • Easily manage your cables with the integrated cable tray, keeping your setup organized.
  • Achieve clear audio routing with low contact resistance, ensuring optimal signal transfer.
  • Simplify your workflow using this user-friendly patch bay, designed for quick adjustments.

What's in the box:

  • Switchcraft 48Point Long Frame Solder Lug with Cable Tray
  • Switchcraft Lifetime Limited Warranty
