Switchcraft 2x24 Point Long Frame With Solder Lug Input/Output and Cable Tray, 1RU, Normals Strapped

SKU: SWMT48K1NSX MFR: MT48K1NSX
Earn VIP Reward Points

Key Features

  • Optimize your audio signal flow with this Switchcraft 48-point patch bay.
  • Durable steel frame ensures long-lasting performance for professional audio setups.
  • Easily manage connections with solder lug I/O, perfect for studio environments.
  • Normals strapped configuration simplifies signal routing for efficient workflows.
  • High-quality jacks provide superior sound quality and reliable connectivity.
  • 1RU design saves rack space, ideal for compact studios and live sound rigs.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 1RU, Normals Strapped Specifications

  • Material 1

    Jacks:
    Frame: Steel, nickel-plated
    Bushing: Brass, nickel-plated
    Springs: Nickel silver solder lugs
    Ground Terminal: Nickel silver, solder lugs
    Switching Contacts: Welded, gold alloy
    Insulation: Phenolic spacers, rigid PVC tubing through stack
    Screws: Steel, nickel-plated

  • Material 2

    Panels:
    Jack Panel: Thermoplastic
    Cable Support Bracket: 5/16" diameter black epoxy painted steel rod
    Screws (designation strip): Steel, black zinc-plated
    Screws (mounting jack): Steel, nickel plated
    Kwik-change Designation Strip: Extruded aluminum, black anodized
    Marking Strip: White plastic, matte finish
    Marking Strip Cover: Clear, extruded plastic

  • Resistance

    Contact: 30 mOhms maximum initial
    Insulation Resistance: 10,000 megaOhms maximum

  • Dielectric Withstanding Voltage

    500V at 60 Hz AC

  • Working Voltage

    140 VDC maximum

  • Current Rating

    100 milliamps

  • Number of Jacks

    48

  • Normalling

    Normals Strapped

  • Dimensions

    Height: 1 Rack Unit 1.75" (4.44cm)
    Depth: 8.8" (22.35cm)

About Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 1RU, Normals Strapped

Explore the exceptional quality and functionality of the Switchcraft 2x24 Point Long Frame with Solder Lug Input/Output and Cable Tray. This 1RU, Normals Strapped device is a top-tier choice for professionals seeking reliable and efficient electronics equipment.

Designed with a semi-enclosed metal chassis, this unit offers superior protection for the jacks, ensuring longevity and durability. The robust construction of the Switchcraft Long Frame Patchbay not only safeguards the internal components but also provides a streamlined installation and modification process.

The 2x24 Point Long Frame features solder lug input/output, a specification that enhances connectivity and signal transmission. This feature ensures that your equipment delivers optimal performance at all times.

The included cable tray is a practical addition, providing an organized solution for cable management. This helps to maintain a clutter-free workspace and reduces the risk of cable damage.

The 1RU size of this device makes it a compact and space-efficient choice, ideal for setups where space is at a premium. The Normals Strapped feature further enhances its functionality, offering flexibility and convenience in various applications.

Incorporating the Switchcraft 2x24 Point Long Frame with Solder Lug Input/Output and Cable Tray into your setup ensures a professional-grade, high-performing, and durable solution for your electronics needs.

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 1RU, Normals Strapped Features

  • High-quality 2x24 Point Long Frame with Solder Lug Input/Output
  • Semi-enclosed metal chassis for superior jack protection
  • Streamlined for easy installation and modification
  • Cable tray included for organized cable management
  • Compact 1RU size, ideal for space-efficient setups
  • Normals Strapped feature for enhanced functionality and flexibility

Key Features

  • Optimize your audio signal flow with this Switchcraft 48-point patch bay.
  • Durable steel frame ensures long-lasting performance for professional audio setups.
  • Easily manage connections with solder lug I/O, perfect for studio environments.
  • Normals strapped configuration simplifies signal routing for efficient workflows.
  • High-quality jacks provide superior sound quality and reliable connectivity.
  • 1RU design saves rack space, ideal for compact studios and live sound rigs.

What's in the box:

  • Switchcraft 48Point Long Frame Solder Lug with Cable Tray
  • Switchcraft Lifetime Limited Warranty
