Switchcraft 2x24 Point Long Frame With Solder Lug Input/Output and Cable Tray, 2RU, Half Normalled

SKU: SWMT48K3HNX MFR: MT48K3HNX
Earn VIP Reward Points

Key Features

  • Optimize your audio signal flow with this Switchcraft 48-point patch bay.
  • Achieve superior sound quality using durable, nickel-plated Switchcraft jacks.
  • Simplify studio connectivity with half-normalled I/O for flexible routing.
  • Enjoy long-lasting performance with the Switchcraft's robust steel frame.
  • Easily manage cables with the integrated cable tray for a tidy setup.
  • Experience reliable audio patching with high insulation resistance (10,000 megaOhms).
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 2RU, Half Normalled Specifications

  • Material 1

    Jacks:
    Frame: Steel, nickel-plated
    Bushing: Brass, nickel-plated
    Springs: Nickel silver solder lugs
    Ground Terminal: Nickel silver, solder lugs
    Switching Contacts: Welded, gold alloy
    Insulation: Phenolic spacers, rigid PVC tubing through stack
    Screws: Steel, nickel-plated

  • Material 2

    Panels:
    Jack Panel: Thermoplastic
    Cable Support Bracket: 5/16" diameter black epoxy painted steel rod
    Screws (designation strip): Steel, black zinc-plated
    Screws (mounting jack): Steel, nickel plated
    Kwik-change Designation Strip: Extruded aluminum, black anodized
    Marking Strip: White plastic, matte finish
    Marking Strip Cover: Clear, extruded plastic

  • Resistance

    Contact: 30 mOhms maximum initial
    Insulation Resistance: 10,000 megaOhms maximum

  • Dielectric Withstanding Voltage

    500V at 60 Hz AC

  • Working Voltage

    140 VDC maximum

  • Current Rating

    100 milliamps

  • Number of Jacks

    48

  • Normalling

    Half Normalled

  • Dimensions

    Height: 2 Rack Units 3.5" (8.89cm)
    Depth: 8.8" (22.35cm)

About Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 2RU, Half Normalled

Are you looking to enhance your professional audio and video setup with a reliable and high-quality patching solution The Switchcraft 48-Point Long Frame Solder Lug with Cable Tray, 2RU, Half Normalled, is a durable and versatile addition to any studio or production environment. This robust patchbay boasts a 2x24 point configuration, providing ample connectivity for your equipment with 48 solder lug input/output points.

Crafted with precision, the Long Frame design ensures a secure and stable connection for each cable, while the half-normalled configuration offers flexibility in signal routing without the need for patch cords. The semi-enclosed metal chassis not only adds an extra layer of protection to the jacks but also facilitates hassle-free access for installation and modifications. The integrated cable tray is a thoughtful feature that aids in cable management, keeping your setup organized and tangle-free.

Designed by Switchcraft, a brand synonymous with professional-grade audio and video gear, this patchbay is built to withstand the demands of continuous use in dynamic environments. Whether you're in a recording studio, broadcast station, or on a film set, the Switchcraft 48-Point Long Frame Solder Lug with Cable Tray, 2RU, Half Normalled, is engineered to deliver reliable performance and streamline your connections with its professional-grade construction and functionality.

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 2RU, Half Normalled Features

  • 48-point long frame patchbay for professional audio/video setups
  • Half-normalled design for flexible signal routing
  • Solder lug input/output for stable cable connections
  • Durable metal chassis with easy-access design for installation
  • Integrated cable tray for efficient cable management
  • High-quality construction by reputable brand Switchcraft

Key Features

  • Optimize your audio signal flow with this Switchcraft 48-point patch bay.
  • Achieve superior sound quality using durable, nickel-plated Switchcraft jacks.
  • Simplify studio connectivity with half-normalled I/O for flexible routing.
  • Enjoy long-lasting performance with the Switchcraft's robust steel frame.
  • Easily manage cables with the integrated cable tray for a tidy setup.
  • Experience reliable audio patching with high insulation resistance (10,000 megaOhms).

What's in the box:

  • Switchcraft 48Point Long Frame Solder Lug with Cable Tray
  • Switchcraft Lifetime Limited Warranty
