Switchcraft 2x24 Point Long Frame With Solder Lug Input/Output and Cable Tray, 2RU, Non-Normalled

SKU: SWMT48K3NNX MFR: MT48K3NNX
Earn VIP Reward Points

Key Features

  • Optimize your audio connectivity with this robust Switchcraft 48-point patch bay.
  • Achieve superior sound quality using the gold alloy contacts for pristine audio signals.
  • Built for durability, the nickel-plated steel frame ensures long-lasting performance in any setup.
  • Simplify cable management with the integrated cable tray for a cleaner, organized studio.
  • Experience reliable connectivity; each jack offers only 30 mOhms maximum contact resistance.
  • This non-normalled patch bay is perfect for custom routing and advanced audio configurations.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Add Adorama Protect:

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What makes the Switchcraft 2x24 Point Long Frame Patchbay suitable for professional audio setups?

The Switchcraft 2x24 Point Long Frame Patchbay is designed with high-quality components and a robust metal chassis, ensuring stable connections and durability for professional audio environments.

Can the metal chassis on the Switchcraft patchbay be removed?

Yes, the semi-enclosed metal chassis is designed to be easily removed, facilitating convenient access for installation and modification of the patchbay.

What does 'Non-Normalled' mean in the context of this patchbay?

Non-Normalled refers to the configuration of the patchbay where there is no default routing of signals between the upper and lower rows of jacks. This allows for more flexible and customizable signal routing.

Is the Switchcraft 2x24 Point Long Frame Patchbay compatible with standard rack units?

Yes, the patchbay is designed in a 2RU form factor, making it compatible with standard rack units commonly used in audio setups.

What type of connections can be made with the Solder Lug Input/Output?

Solder Lug Input/Output allows for soldering cables directly to the patchbay, ensuring robust and long-lasting audio connections suitable for professional applications.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 2RU, Non-Normalled Specifications

  • Material 1

    Jacks:
    Frame: Steel, nickel-plated
    Bushing: Brass, nickel-plated
    Springs: Nickel silver solder lugs
    Ground Terminal: Nickel silver, solder lugs
    Switching Contacts: Welded, gold alloy
    Insulation: Phenolic spacers, rigid PVC tubing through stack
    Screws: Steel, nickel-plated

  • Material 2

    Panels:
    Jack Panel: Thermoplastic
    Cable Support Bracket: 5/16" diameter black epoxy painted steel rod
    Screws (designation strip): Steel, black zinc-plated
    Screws (mounting jack): Steel, nickel plated
    Kwik-change Designation Strip: Extruded aluminum, black anodized
    Marking Strip: White plastic, matte finish
    Marking Strip Cover: Clear, extruded plastic

  • Resistance

    Contact: 30 mOhms maximum initial
    Insulation Resistance: 10,000 megaOhms maximum

  • Dielectric Withstanding Voltage

    500V at 60 Hz AC

  • Working Voltage

    140 VDC maximum

  • Current Rating

    100 milliamps

  • Number of Jacks

    48

  • Normalling

    Non-Normalled

  • Dimensions

    Height: 2 Rack Units 3.5" (8.89cm)
    Depth: 8.8" (22.35cm)

About Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 2RU, Non-Normalled

If you're in the market for a reliable and durable audio equipment solution, consider the Switchcraft 2x24 Point Long Frame with Solder Lug Input/Output and Cable Tray. This 2RU, Non-Normalled model is expertly designed to meet the high standards of professional audio setups.

This product features the superior quality associated with Long Frame patchbays, ensuring optimal performance for your audio connections. The Switchcraft Long Frame is renowned for its robustness and reliability, making it a preferred choice for audio professionals worldwide.

The 2x24 Point Long Frame comes with a Solder Lug Input/Output, providing a secure and stable connection for your audio equipment. This feature ensures that your audio signals are transmitted with minimal loss, maintaining the integrity of your sound.

One of the standout features of this product is its semi-enclosed metal chassis. This protective casing safeguards the jacks from potential damage, extending the lifespan of your equipment. Moreover, the chassis can be easily removed, offering convenience during installation and modification processes.

The 2RU, Non-Normalled specification of this model indicates its compatibility with standard rack units, making it a versatile addition to your audio setup. Whether you're setting up a home studio or a professional recording environment, the Switchcraft 2x24 Point Long Frame with Solder Lug Input/Output and Cable Tray is a sound investment for your audio needs.

Switchcraft 48Point Long Frame Solder Lug with Cable Tray, 2RU, Non-Normalled Features

  • High-quality 2x24 Point Long Frame Patchbay for professional audio setups
  • Solder Lug Input/Output for stable and secure audio connections
  • Semi-enclosed metal chassis offering protection and easy access
  • 2RU, Non-Normalled design fits standard rack units seamlessly
  • Designed for durability and reliability in recording and broadcast environments
  • Streamlined installation and modification with removable chassis features

Key Features

  • Optimize your audio connectivity with this robust Switchcraft 48-point patch bay.
  • Achieve superior sound quality using the gold alloy contacts for pristine audio signals.
  • Built for durability, the nickel-plated steel frame ensures long-lasting performance in any setup.
  • Simplify cable management with the integrated cable tray for a cleaner, organized studio.
  • Experience reliable connectivity; each jack offers only 30 mOhms maximum contact resistance.
  • This non-normalled patch bay is perfect for custom routing and advanced audio configurations.

What's in the box:

  • Switchcraft 48Point Long Frame Solder Lug with Cable Tray
  • Switchcraft Lifetime Limited Warranty
