Switchcraft 2x24 Point 1/4" Long Frame Audio with Solder Lug Input/Output and Cable Tie Bar, Non-Normalled

SKU: SWMT48NNX MFR: MT48NNX
Earn VIP Reward Points

Key Features

  • Achieve superior audio connectivity with this Switchcraft 2x24 point audio snake.
  • Experience crystal-clear sound quality using durable, nickel-plated steel jacks.
  • Simplify your setup with this non-normalled patchbay, ideal for complex audio routing.
  • Enjoy long-lasting performance with gold alloy welded contacts for reliable connections.
  • Easily manage your audio signals with the convenient cable tie bar included.
  • Optimize your rack space; this 1.75" unit is perfect for professional audio setups.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Switchcraft 2x24 Point 1/4" Long Frame Audio with Solder Lug, Non-Normalled Specifications

  • Material

    Jacks:
    Frame: Stamped nickel-plated steel
    Bushing: Nickel-plated brass
    Tip, Ring and Shunt Springs: Nickel silver with welded contacts
    Assembly Screws: Nickel-plated steel
    Welded Contacts: Gold alloy
    Panel:
    Front Panel: Thermoplastic
    Frame: C.R.S. black epoxy painted
    Designation Strips: Black polycarbonate 94V-0
    Designation Strip Covers: Clear polycarbonate

  • Resistance

    Contact: 30 mOhms maximum initial
    Insulation Resistance: 10,000 megaOhms maximum

  • Dielectric Withstanding Voltage

    500V at 60 Hz AC

  • Working Voltage

    140 VDC maximum

  • Current Rating

    100 milliamps

  • Normalling

    Non-Normalled

  • Number of Positions

    48

  • Dimensions

    Height: 1 Rack Unit 1.75" (4.44cm)
    Depth: 5.3" (13.46cm)

About Switchcraft 2x24 Point 1/4" Long Frame Audio with Solder Lug, Non-Normalled

Become the master of your audio setup with the Switchcraft 2x24 Point 1/4" Long Frame Audio with Solder Lug and Cable Tie Bar, Non-Normalled. This high-quality audio patchbay is engineered to meet stringent military specifications, ensuring robustness and versatility that stands out in the market.

The Switchcraft 2x24 Point 1/4" Long Frame Audio Patchbay features multiple normalling configurations, providing you with the flexibility to customize your audio routing to suit your specific needs. The pre-tinned and offset solder lugs ensure a secure and reliable connection, enhancing the overall audio performance.

In addition, this audio patchbay is equipped with a cable tie bar, which aids in cable management and maintains a neat and organized setup. The changeable designation strips allow for easy identification and quick adjustments, making your audio management more efficient.

The heavy-duty 1/4" long frame jacks are designed to withstand frequent use, making this patchbay a durable choice for any audio professional. Whether you're a sound engineer, a music producer, or an audio enthusiast, the Switchcraft 2x24 Point 1/4" Long Frame Audio with Solder Lug and Cable Tie Bar, Non-Normalled is a reliable tool to optimize your audio setup.

Switchcraft 2x24 Point 1/4" Long Frame Audio with Solder Lug, Non-Normalled Features

  • Military-specification audio patchbay for robust and versatile performance
  • Multiple normalling configurations for customizable audio routing
  • Pre-tinned and offset solder lugs for secure and reliable connection
  • Includes cable tie bar for efficient cable management
  • Changeable designation strips for easy identification and adjustments
  • Heavy-duty 1/4" long frame jacks for durable and frequent use

Key Features

  • Achieve superior audio connectivity with this Switchcraft 2x24 point audio snake.
  • Experience crystal-clear sound quality using durable, nickel-plated steel jacks.
  • Simplify your setup with this non-normalled patchbay, ideal for complex audio routing.
  • Enjoy long-lasting performance with gold alloy welded contacts for reliable connections.
  • Easily manage your audio signals with the convenient cable tie bar included.
  • Optimize your rack space; this 1.75" unit is perfect for professional audio setups.

What's in the box:

  • Switchcraft 2x24 Point 1/4 " Long Frame Audio with Solder Lug
  • Switchcraft Lifetime Limited Warranty
