Switchcraft 2x26 Point 1/4" Long Frame Audio with Solder Lug Input/Output and Cable Tie Bar, Half Normalled

SKU: SWMT52HNX MFR: MT52HNX
Earn VIP Reward Points

Key Features

  • Optimize audio signal flow with this Switchcraft 2x26 point patch bay for clear sound.
  • Durable nickel-plated steel frame ensures longevity for reliable audio connections.
  • Easily manage your 1/4" audio connections with the half-normalled configuration.
  • Achieve pristine audio quality with gold alloy welded contacts minimizing resistance.
  • Simplify cable management using the integrated cable tie bar for a tidy setup.
  • Perfect for studio or stage, this audio patch bay ensures optimal signal routing.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Switchcraft 2x26 Point 1/4" Long Frame Audio with Solder Lug, Half Normalled Specifications

  • Material

    Jacks:
    Frame: Stamped nickel-plated steel
    Bushing: Nickel-plated brass
    Tip, Ring and Shunt Springs: Nickel silver with welded contacts
    Assembly Screws: Nickel-plated steel
    Welded Contacts: Gold alloy
    Panel:
    Front Panel: Thermoplastic
    Frame: C.R.S. black epoxy painted
    Designation Strips: Black polycarbonate 94V-0
    Designation Strip Covers: Clear polycarbonate

  • Resistance

    Contact: 30 mOhms maximum initial
    Insulation Resistance: 10,000 megaOhms maximum

  • Dielectric Withstanding Voltage

    500V at 60 Hz AC

  • Working Voltage

    140 VDC maximum

  • Current Rating

    100 milliamps

  • Normalling

    Half Normalled

  • Number of Positions

    52

  • Dimensions

    Height: 1 Rack Unit 1.75" (4.44cm)
    Depth: 5.3" (13.46cm)

About Switchcraft 2x26 Point 1/4" Long Frame Audio with Solder Lug, Half Normalled

Under the banner of professional audio equipment, the Switchcraft 2x26 Point 1/4" Long Frame Audio with Solder Lug and Cable Tie Bar, Half Normalled, stands out for its exceptional durability and versatility. Engineered to meet stringent military specifications, this high-quality patchbay is built to withstand the most demanding environments.

This model features multiple normalling configurations, providing you with the flexibility to customize your audio setup to suit your specific needs. The pre-tinned and offset solder lugs ensure a secure and reliable connection, enhancing the overall performance of your audio system.

The inclusion of a cable tie bar adds to the robustness of the design, helping to manage and secure your cables effectively. This feature not only enhances the longevity of your cables but also contributes to a cleaner and more organized setup.

The Switchcraft 2x26 Point 1/4" Long Frame Audio Patchbay also comes with changeable designation strips, allowing for easy identification and management of your connections. This user-friendly feature simplifies the process of setting up and adjusting your audio system.

Lastly, the heavy-duty 1/4" long frame jacks are designed to handle frequent plugging and unplugging, ensuring consistent performance and longevity.

In summary, the Switchcraft 2x26 Point 1/4" Long Frame Audio with Solder Lug and Cable Tie Bar, Half Normalled, is a rugged, versatile, and user-friendly solution for your professional audio needs.

Switchcraft 2x26 Point 1/4" Long Frame Audio with Solder Lug, Half Normalled Features

  • Military-grade Switchcraft 2x26 Point 1/4" Long Frame Audio Patchbay for professional audio setups
  • Multiple normalling configurations for customizable audio experiences
  • Pre-tinned and offset solder lugs for secure, reliable connections
  • Included cable tie bar for effective cable management and longevity
  • Changeable designation strips for easy identification and management of connections
  • Heavy-duty 1/4" long frame jacks designed for frequent use and consistent performance

Key Features

  • Optimize audio signal flow with this Switchcraft 2x26 point patch bay for clear sound.
  • Durable nickel-plated steel frame ensures longevity for reliable audio connections.
  • Easily manage your 1/4" audio connections with the half-normalled configuration.
  • Achieve pristine audio quality with gold alloy welded contacts minimizing resistance.
  • Simplify cable management using the integrated cable tie bar for a tidy setup.
  • Perfect for studio or stage, this audio patch bay ensures optimal signal routing.

What's in the box:

  • Switchcraft 2x26 Point 1/4 " Long Frame Audio with Solder Lug
  • Switchcraft Lifetime Limited Warranty
