Switchcraft Rackmounted 8 Input 3-Way Dual Isolated Audio Splitter, >390 Ohms Input Impedance, 10Hz - 20KHz Frequency Response

SKU: SWRMAS8 MFR: RMAS8
Earn VIP Reward Points

Key Features

  • Ensure pristine audio signal distribution with this 8-input rackmounted splitter.
  • Achieve superior sound quality with a frequency response of 10Hz-20kHz in your audio setup.
  • Enjoy versatile connectivity using XLR and DB-25 interfaces on this robust audio splitter.
  • Isolate and split audio signals effectively, reducing noise with >108dB CMRR performance.
  • Experience minimal signal loss with low impedance outputs on this durable audio splitter.
  • Rely on consistent performance with <0.0015% THD+Noise, ensuring top-tier audio clarity.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$179.99

3 Year

$249.99

5 Year

$489.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Switchcraft Rackmounted 8 Input 3-Way Dual Isolated Audio Splitter Specifications

  • Frequency Response

    10Hz-20kHz +/-0.5dB, ref 1kHz

  • Total Harmonic Distortion + Noise

    < 0.0015% at 1kHz, +20dBu Input, 22kHz Bandwidth
    < 0.07% at 20kHz, -20dBu Input, 22kHz Bandwidth

  • Maximum Input Level

    +4dBu at 20Hz with 1% THD+Noise

  • Input Impedance

    > 390Ohms at 1kHz

  • Output Impedance

    < 200 Ohms at 1kHz

  • Common Mode Rejection Ratio (CMRR)

    >108dB at 60Hz

  • Deviation from Linear Phase

    <2deg. at 20Hz
    <1deg. at 1kHz
    <24deg. at 20kHz

  • Crosstalk

    <-95dB 20Hz-20KHz, Channel to channel

  • Voltage Gain

    Direct Output: -2.8dB +/-1dB
    Direct Output (Pad on): -1.0dB +/-1dB
    Isolated Outputs: -4.0dB +/-1dB
    Isolated Outputs (Pad On): -44.3dB +/-1dB

  • Pad Attenuation

    40.3dB +/-1dB

  • RoHS Compliant

    Yes

  • UPC Code

    85359200715

About Switchcraft Rackmounted 8 Input 3-Way Dual Isolated Audio Splitter

Because professional audio quality matters, the Switchcraft RMAS8 is more than just a Rackmounted 8 Input 3-Way Dual Isolated Audio Splitter. This high-quality, durable device is meticulously engineered to handle both mic and line level audio signals, thanks to the line level pad on each of its eight input channels.

Designed for versatility and reliability, this audio splitter features ground lift switches on each of its 16 transformer isolated outputs. These switches play a crucial role in eliminating ground loops, ensuring a clean, uninterrupted audio signal.

Moreover, the Switchcraft RMAS8 is equipped with a set of eight direct (non-isolated) outputs. These outputs provide a secure and permanent connection to phantom power supplies, further enhancing its functionality in professional audio and video setups.

With an impressive frequency response range of 10Hz to 20KHz and an input impedance of over 390 Ohms, this audio splitter is designed to deliver superior audio performance. Whether you're in a recording studio, a live event, or a broadcast environment, the Switchcraft RMAS8 is the professional choice for managing multiple audio sources.

Switchcraft Rackmounted 8 Input 3-Way Dual Isolated Audio Splitter Features

  • Designed for mobile / live sound
  • Line level pad on each input
  • Ground lift on each isolated output
  • XLR and DB25 I/O

Key Features

  • Ensure pristine audio signal distribution with this 8-input rackmounted splitter.
  • Achieve superior sound quality with a frequency response of 10Hz-20kHz in your audio setup.
  • Enjoy versatile connectivity using XLR and DB-25 interfaces on this robust audio splitter.
  • Isolate and split audio signals effectively, reducing noise with >108dB CMRR performance.
  • Experience minimal signal loss with low impedance outputs on this durable audio splitter.
  • Rely on consistent performance with <0.0015% THD+Noise, ensuring top-tier audio clarity.

What's in the box:

  • Switchcraft Rackmounted 8 Input 3-Way Dual Isolated Audio Splitter
  • Switchcraft Lifetime Limited Warranty
