SWIT Electronics S-2240 12W Bi-Color SMD On-Camera LED Light with S-7004D Panasonic CGA and VW-VBD Battery Plate

60pcs Surface Mounted LEDs

Area light, soft and glareless
S-2240 is an on-camera LED news light, with surface mounted LED technology, includes 60pcs ultra bright SMD LEDs, suitable for wide area on-camera lighting. The provided diffuser cover generates an equally spread, glareless area light for close interview and professional film lighting.

Super wide beam angle

LED 120 deg. ; Half-declined at 68deg
The SMD LED of S-2240 has 120 deg. wide beam angle and generates an equally spread, wider area light comparing to traditional DIP LED bulbs.
Take center illuminance as 100% brightness, when declined to 50% at the edge, the "half-declined" beam angle can still reach to 68 deg. , which means the light is equally spread onto the whole environment, instead of just concentrated at center.

Bi-color temperature

3200K-5600K continuously adjustable
Every SMD LED of S-2240 is packaged with 5600K and 3200K LEDs and the output color temperature can be continuously adjustable between 3200K and 5600K. The bi-color SMD LED is more reliable and has better consistency on color temperature.

High Color Reveal Ability

CRI Ra>=92; TLCI>=97
CRI (Color Rendering Index) is a measure of the ability of a light source to reveal the colors of various objects faithfully in comparison with a natural light source. And TLCI (Television Lighting Consistency Index) is special for the color reveal ability by camera sensor. Max value 100. The normal LED light has 80-85 CRI or TLCI, while S-2240 offers the super high CRI at 92 and TLCI at 97 and will not lose the object original colors.

Magnetic Diffuser Cover

With organic light diffusion agent
S-2240 provides a diffuser cover, to be attached on the front of LEDs by magnet. The diffuser cover adopts the PC material with organic light diffusion agent, which increased the transmission of light and provides a soft, glareless and comfortable lighting effect.

6-17V DC Input

Various DV plates / D-tap cable
S-2240 accepts 6-17V wide voltage input, so you can get DC power from V-mount / Gold mount batteries or DV batteries. S-2240 also supports SWIT S-7004 series snap-on type DV battery plates to install.

S-7004D Snap-on Panasonic CGA/VBD DV Battery Mount
S-7004D adopts the Panasonic CGA and VBD type DV battery plate, compatible with Panasonic CGA-D54/D28, VW-VBD58 series DV batteries and SWIT S-8D62/S-8D58 DV battery. The structure and power pins ensure a stable and reliable connection.

• Panasonic CGA/VBD DV battery adaptor plate
• SWIT S-8D62 and S-8D58 fit
• Panasonic CGA-D54/D28 and VW-VBD58 fit
• Snap-on type installation
• Fit for SWIT monitors and lightings

Snap-on Type Installation
S-7004D is snap-on designed, can be installed on SWIT on-camera monitors and lightings conveniently and quickly releasable, interchangeable with other types of S-7004 with different DV battery adapting.

Compatible Monitors and Lightings
S-7004D can be fixed onto the following SWIT items:
• LCD monitors: S-1071F, S-1071H, S-1071C, S-1071C+; S-1092F, S-1092H, S-1090F, S-1090H, S-1090C; S-1051H
• LED lighting S-2040
