Synology DiskStation DS923+ 4-Bay NAS Enclosure, Bundle with 4x WD Red Plus 12TB 3.5" SATA III Internal NAS Hard Drive

SKU: SYDS9234N12B MFR: SYDS9234N12B
Earn VIP Reward Points

PACKAGE INCLUDES:

  • Synology DiskStation DS923+ 4-Bay NAS Enclosure, AMD Ryzen R1600 CPU, Diskless
    Synology DiskStation DS923+ 4-Bay NAS Enclosure, AMD Ryzen R1600 CPU, Diskless
  • +
  • Seagate IronWolf SATA III 3.5" Internal NAS Hard Drive 12TB Single
    Seagate IronWolf SATA III 3.5" Internal NAS Hard Drive 12TB Single

    Qty: 4

  • +
  • Show more

Key Features

  • This Synology DiskStation NAS bundle offers 48TB storage for all your important files.
  • Ensure top-tier data security with advanced encryption and RAID configurations on this NAS.
  • Experience fast performance with the Ryzen processor, perfect for demanding applications.
  • Set up your personal cloud easily with our intuitive interface and remote access features.
  • Scale your storage as needed; this NAS enclosure supports expansion units for future growth.
  • Stream media seamlessly with DLNA compliance, making it a perfect media server for your home.
See More Product Details
Free Expedited Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$209.99

3 Year

$299.99

4 Year

$359.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?BARBARA B : research and experience

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Synology DS923+ & WD Red Plus Specifications

Hardware: CPU

Hardware: CPU

Jump to...
  • CPU Model

    AMD Ryzen R1600

  • CPU Quantity

    1

  • CPU Architecture

    64-bit

  • CPU Frequency

    2-core 2.6 (base) / 3.1 (turbo) GHz

  • Hardware Encryption Engine (AES-NI)

    Yes

Hardware: Memory

Jump to...
  • System Memory

    4GB DDR4 ECC SODIMM

  • Memory Module Pre-installed

    4GB (4GB x 1)

  • Total Memory Slots

    2

  • Maximum Memory Capacity

    32GB (16GB x 2)

Hardware: Storage

Jump to...
  • Drive Bays

    4

  • Maximum Drive Bays with Expansion Unit

    9 (DX517 x 1)

  • M.2 Drive Slots

    2 (NVMe)

  • Compatible Drive Type

    3.5" SATA HDD
    2.5" SATA SSD
    M.2 2280 NVMe SSD

  • Hot Swappable Drive

    Yes

Hardware: External Ports

Jump to...
  • RJ-45 1GbE LAN Port

    2 (with Link Aggregation / Failover support)

  • USB 3.2 Gen 1 Port

    2

  • eSATA Port

    1

Hardware: PCIe

Jump to...
  • PCIe Expansion

    1 x Gen3 x2 network upgrade slot

Hardware: File System

Jump to...
  • Internal Drives

    Btrfs
    EXT4

  • External Drives

    Btrfs
    EXT4
    EXT3
    FAT
    NTFS
    HFS+
    exFAT

Hardware: Others

Jump to...
  • System Fan

    2 pcs 92 x 92mm

  • Fan Speed Mode

    Full-Speed Mode
    Cool Mode
    Quiet Mode

  • Brightness Adjustable

    Yes (Front LED Indicators)

  • Power Recovery

    Yes

  • Noise Level

    22.9 dB(A)

  • Scheduled Power On / Off

    Yes

  • Wake on LAN / WAN

    Yes

  • Power Supply Unit / Adapter

    100 W

  • AC Input Power Voltage

    100V to 240V AC

  • Power Frequency

    50/60 Hz, Single Phase

  • Power Consumption

    35.51 W (Access)
    11.52 W (HDD Hibernation)

  • British Thermal Unit

    121.09 BTU/hr (Access)
    39.28 BTU/hr (HDD Hibernation)

Hardware: Temperature

Jump to...
  • Operating Temperature

    32 Degree F to 104 Degree F (0 Degree C to 40 Degree C)

  • Storage Temperature

    -5 Degree F to 140 Degree F (-20 Degree C to 60 Degree C)

  • Relative Humidity

    5% to 95% RH

Hardware: Certification

Jump to...
  • Certification

    FCC
    CE
    BSMI
    VCCI
    RCM
    UKCA
    EAC
    CCC
    KC

Hardware: Environment

Jump to...
  • Environment

    RoHS Compliant

Hardware: Appearance

Jump to...
  • Dimensions (H x W x D)

    6.53 x 7.83 x 8.77" (166 x 199 x 223mm)

  • Weight

    4.93 lbs (2.24kg)

Software: Storage Management

Jump to...
  • Maximum Single Volume Size

    108TB

  • Maximum Internal Volume Number

    64

  • M.2 SSD Storage Pool Support

    Yes

  • SSD Read / Write Cache (White Paper)

    Yes

  • SSD TRIM

    Yes

  • Supported RAID Type

    Synology Hybrid RAID
    Basic
    JBOD
    RAID 0
    RAID 1
    RAID 5
    RAID 6
    RAID 10

  • RAID Migration

    Basic to RAID 1
    Basic to RAID 5
    RAID 1 to RAID 5
    RAID 5 to RAID 6

  • Volume Expansion with Larger HDDs

    Synology Hybrid RAID
    RAID 1
    RAID 5
    RAID 6
    RAID 10

  • Volume Expansion by Adding a HDD

    Synology Hybrid RAID
    JBOD
    RAID 5
    RAID 6 (with Expansion Unit)

  • Global Hot Spare Supported RAID Type

    Synology Hybrid RAID
    RAID 1
    RAID 5
    RAID 6 (with Expansion Unit)
    RAID 10 (with Expansion Unit)

Software: File Services

Jump to...
  • File Protocol

    SMB/AFP/NFS/FTP/WebDAV

  • Max. Concurrent SMB/AFP/FTP Connections

    1000
    2000 (with RAM expansion)

  • Windows ACL Integration

    Yes

  • NFS Kerberos Authentication

    Yes

Software: Account & Shared Folder

Jump to...
  • Maximum Local User Accounts

    2048

  • Maximum Local Groups

    256

  • Maximum Shared Folder

    512

  • Maximum Shared Folder Sync Tasks

    16

Software: Hybrid Share

Jump to...
  • Hybrid Share Folder Number

    10

Software: Hyper Backup

Jump to...
  • Folder and Package Backup

    Yes

  • Entire System Backup

    Yes

Software: High Availability

Jump to...
  • Synology High Availability

    Yes

Software: Log Center

Jump to...
  • Syslog Events per Second

    800

Software: Virtualization

Jump to...
  • VMware ESXi 6.5 and VAAI

    Yes

  • Windows Server 2022

    Yes

  • Citrix Ready

    Yes

  • OpenStack

    Yes

Software: General

Jump to...
  • Networking Protocols

    SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

  • Supported Browsers

    Google Chrome
    Firefox
    Microsoft Edge
    Safari

  • Supported Language

    English, Deutsch, French, Italian, Espanol, Danish, Norwegian, Swedish, Nederlands, Russian, Polish, Hungarian, Brazilian Portuguese, European Portuguese, Turkish, Czech, Thai, Japanese, Korean, Traditional Chinese, Simplified Chinese

Software: Add-on Packages

Jump to...
  • Antivirus by McAfee (Trial)

    Yes

  • Central Management System

    Yes

Software: Synology Chat

Jump to...
  • Suggested Concurrent Users

    100

Software: Document Viewer

Jump to...
  • Document Viewer

    Yes

Software: Download Station

Jump to...
  • Maximum Concurrent Download Tasks

    80

Software: SAN Manager

Jump to...
  • Maximum iSCSI Target Number

    128

  • Maximum LUN

    256

  • LUN Clone/Snapshot, Windows ODX

    Yes

Software: MailPlus / MailPlus Server

Jump to...
  • Free Email Accounts

    5 (Additional accounts require purchase of licenses)

  • Suggested Maximum Users

    500

  • Suggested Concurrent Users

    100

  • Maximum Server Performance

    1,224,000 emails per day, approx. 37GB

Software: Media Server

Jump to...
  • DLNA Compliance

    Yes

Software: Synology Photos

Jump to...
  • Facial Recognition

    Yes

  • Object Recognition

    Yes

Software: Snapshot Replication

Jump to...
  • Maximum Snapshots per Shared Folder

    1024

  • Maximum of System Snapshots

    65536

Software: Surveillance Station

Jump to...
  • Default Licenses

    2 (Additional cameras require purchase of licenses)

  • Maximum IP Cameras and Total FPS (H.264)

    720p: 40 channels, 1200 FPS
    1080p: 40 channels, 1050 FPS
    3M: 40 channels, 600 FPS
    5M: 30 channels, 360 FPS
    4K: 20 channels, 200 FPS

  • Maximum IP Cameras and Total FPS (H.265)

    720p: 40 channels, 1200 FPS
    1080p: 40 channels, 1200 FPS
    3M: 40 channels, 1000 FPS
    5M: 40 channels, 600 FPS
    4K: 30 channels, 300 FPS

Software: Synology Drive

Jump to...
  • Recommended Number

    Concurrent Sync Clients: 350 (the number of connections that can be maintained when the recommended number of hosted files was reached)

  • Recommended Number of Hosted Files

    5,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)

Software: Synology Office

Jump to...
  • Suggested Maximum Users

    3000

  • Suggested Concurrent Users

    1200

Software: Video Station

Jump to...
  • Video Station

    Yes

Software: Virtual Machine Manager

Jump to...
  • Recommended Virtual Machine Instances

    4

  • Recommended Virtual DSM Number

    4 (including 1 Free License) (Licenses required)

Software: VPN Server

Jump to...
  • Maximum Connections

    40

  • UPC Codes

    192223244900, 763649136348, 846504004454

About Synology DS923+ & WD Red Plus

With the DiskStation DS923+ 4-Bay NAS Enclosure, you can elevate your data management capabilities, making it an ideal storage solution for small businesses and home offices. This versatile smart storage system allows you to consolidate your growing digital data, handling demanding application workloads and a greater number of concurrent users with ease.

Experience enhanced speed with the DS923+, which offers faster file indexing in Synology Drive and photo organization in Synology Photos. It also enables quicker concurrent file transfers, with Synology Drive offering 24% faster file indexing, Synology Photos providing 25% faster photo indexing, and multiple file transfers delivering 32% faster random write.

The DS923+ is designed to accelerate your workloads and reduce transfer times. It supports up to 592/562 MB/s read/write speeds, up to 10GbE networking, and includes 2 x M.2 NVMe cache & storage pool for further performance enhancement.

If you're struggling with data scattered across external drives and public cloud accounts, the DS923+ offers a solution. It allows you to consolidate your data with over 50 TB across 4 bays. If you need more space, you can expand with DX517 for over 120 TB of storage.

The DS923+ is not just about storage; it's also about data management. It allows you to store, share, and protect all your documents, photos, and other files. You can back up applications and devices, and protect your physical assets with professional video surveillance.

With Synology's private cloud solution, you can effortlessly deploy your own personal cloud. This simplifies file access and consolidates your data management, making file sharing and collaboration easier.

The DS923+ also offers professional photo management, allowing you to efficiently back up and organize photos and videos. It automatically organizes your content into albums and creates secure share links for sharing files with family, friends, or clients.

The DS923+ supports site-to-site file syncing, allowing collaborators to sync individual files or folders between Synology devices, whether at home, another office, or across the world. This combines convenient access with 100% data ownership.

With the DS923+, you can reduce your on-site storage footprint and benefit from data center network speeds with hybrid cloud technology. Set up Hybrid Share Folders to efficiently store cold data in the cloud, while keeping frequently accessed files cached locally on your DS923+ and accessible at LAN speeds.

The DS923+ offers multi-layered backup solutions, allowing you to back up files, folders, physical devices, VMs, and SaaS applications. It also includes built-in technologies to protect your NAS.

Transform your Synology device into a full-featured video management system for a wide range of compatible IP cameras with the DS923+. It offers centralized video management, support for over 8,300 IP camera models, and remote monitoring and playback of footage.

The DS923+ is backed by Synology drives, offering high sustained performance and reliability with enterprise-grade drives with built-in data protection designed for Synology systems.

Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system with the DS923+. It offers convenient management of your fleet of Synology NAS from a centralized console, shields your Synology NAS from sophisticated threats with industry-leading security solutions, and provides seamless transition between clustered servers in the event of a server failure.

The DS923+ is an ideal storage solution for content creators, bringing speed, simplicity, and security to all your creative projects. It follows the 3-2-1 backup strategy and keeps your data safe with Synology's backup packages, minimizing the threat posed by increasingly sophisticated ransomware and other malware.

Synology DS923+ & WD Red Plus Features

  • Stunningly compact: Powerful functionality in a tiny package, with room for 10GbE and dual NVMe drives
  • Consolidate and share: Flexibly store and organize 50TB of data, then share with anyone
  • Keep your data safe: Hardware and software engineered to protect your data - trusted by millions

Product Documents

User Manual

Key Features

  • This Synology DiskStation NAS bundle offers 48TB storage for all your important files.
  • Ensure top-tier data security with advanced encryption and RAID configurations on this NAS.
  • Experience fast performance with the Ryzen processor, perfect for demanding applications.
  • Set up your personal cloud easily with our intuitive interface and remote access features.
  • Scale your storage as needed; this NAS enclosure supports expansion units for future growth.
  • Stream media seamlessly with DLNA compliance, making it a perfect media server for your home.

What's in the box:

  • Synology DiskStation DS923+ 4-Bay NAS Enclosure
  • Accessory Pack
  • AC Power Adapter
  • AC Power Cord
  • 2x RJ-45 LAN Cable
  • User Manual
  • Synology 3 Year Limited Warranty
  • Bundle Includes:
  • 4x IronWolf 12TB SATA III 3.5" Internal NAS Hard Drive
