Synology High Density HD6500 60-Bay 4U Rackmount NAS Enclosure with 2x 480GB SATA SSD

SKU: SYHD65001B MFR: HD6500
Earn VIP Reward Points

Key Features

  • Maximize your data storage with this 60-bay Synology NAS enclosure, built for high-density environments.
  • Experience fast performance with dual Intel Xeon CPUs & 64GB ECC memory in this robust NAS server.
  • Ensure data security with advanced RAID options and snapshot replication on this Synology HD6500 NAS.
  • Scale your storage effortlessly; supports up to 300 drives using RX6022sas expansion units on this NAS.
  • Enjoy remote access and manage your files securely from anywhere with Synology's intuitive interface.
  • Streamline your workflow with 10GbE connectivity, perfect for large file transfers on this NAS system.
See More Product Details

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Shopper : Why Did You Choose This?Daniel H : need big storage, you have best price

Reviews about this item

Review Summary

Synology High Density HD6500 Specifications

Hardware: CPU

Hardware: CPU

Jump to...
  • CPU Model

    Intel Xeon Silver 4210R

  • CPU Quantity

    2

  • CPU Architecture

    64-bit

  • CPU Frequency

    10-core 2.4 (base) / 3.2 (turbo) GHz

  • Hardware Encryption Engine (AES-NI)

    Yes

Hardware: Memory

Jump to...
  • System Memory

    64GB DDR4 ECC RDIMM

  • Memory Module Pre-installed

    64GB (32GB x 2)

  • Total Memory Slots

    16

  • Maximum Memory Capacity

    512GB (32GB x 16)

Hardware: Storage

Jump to...
  • Drive Bays

    60

  • Maximum Drive Bays with Expansion Unit

    300 (RX6022sas x 4)

  • SAS multipathing

    Yes

  • Compatible Drive Type

    3.5" SAS HDD
    2.5" SATA SSD
    Installed: 960 GB (2x 480 GB SSD)

  • Hot Swappable Drive

    Yes

Hardware: External Ports

Jump to...
  • RJ-45 1GbE LAN Port

    2 (with Link Aggregation / Failover support)

  • RJ-45 10GbE LAN Port

    2 (with Link Aggregation / Failover support)

  • Out-of-Band Management LAN Port

    1

  • Max. number of LAN ports

    15

  • USB 3.2 Gen 1 Port

    2

  • Expansion Port

    2

Hardware: PCIe

Jump to...
  • PCIe Expansion

    2x Gen3 x16 slot (x16 link)
    2x Gen3 x8 slots (x8 link)

Hardware: File System

Jump to...
  • Internal Drives

    Btrfs

  • External Drives

    Btrfs
    EXT4
    EXT3
    FAT
    NTFS
    HFS+
    exFAT

Hardware: Others

Jump to...
  • System Fan

    4 pcs 80 x 80mm

  • Fan Speed Mode

    Full-Speed Mode
    Cool Mode
    Quiet Mode

  • Easy Replacement System Fan

    Yes

  • Power Recovery

    Yes

  • Noise Level

    60.8 dB(A)

  • Scheduled Power On / Off

    Yes

  • Wake on LAN / WAN

    Yes

  • Power Supply Unit / Adapter

    1600 W

  • Redundant Power Supply

    Yes

  • AC Input Power Voltage

    200V to 240V AC

  • Power Frequency

    50/60 Hz, Single Phase

  • Power Consumption

    1025.2 W (Access)
    418 W (HDD Hibernation)

  • British Thermal Unit

    3495.93 BTU/hr (Access)
    1425.38 BTU/hr (HDD Hibernation)

Hardware: Temperature

Jump to...
  • Operating Temperature

    32 Degree F to 95 Degree F (0 Degree C to 35 Degree C)

  • Storage Temperature

    -5 Degree F to 140 Degree F (-20 Degree C to 60 Degree C)

  • Relative Humidity

    5% to 95% RH

Hardware: Certification

Jump to...
  • Certification

    FCC
    CE
    BSMI
    VCCI
    RCM
    UKCA
    EAC
    KC
    UL

Hardware: Environment

Jump to...
  • Environment

    RoHS Compliant

Hardware: Appearance

Jump to...
  • Form Factor (RU)

    4U

  • Rack Installation Support

    4-post 19" rack (Synology Rail Kit - RKS-03)

  • Dimensions (H x W x D)

    6.92 x 18.97 x 40.15" (176 x 482 x 1020mm)

  • Weight

    83.55 lbs (37.9kg)

Software: Storage Management

Jump to...
  • Maximum Single Volume Size

    1PB (for RAID 6 groups only)
    200TB

  • Maximum Internal Volume Number

    256

  • SSD Read / Write Cache (White Paper)

    Yes

  • RAID Group

    Yes

  • Supported RAID Type

    Basic
    JBOD
    RAID 0
    RAID 1
    RAID 5
    RAID 6
    RAID 10

  • RAID Migration

    Basic to RAID 1
    Basic to RAID 5
    RAID 1 to RAID 5
    RAID 5 to RAID 6

  • Volume Expansion with Larger HDDs

    RAID 1
    RAID 5
    RAID 6
    RAID 10

  • Volume Expansion by Adding a HDD

    JBOD
    RAID 5
    RAID 6

  • Global Hot Spare Supported RAID Type

    RAID 1
    RAID 5
    RAID 6
    RAID 10

Software: File Services

Jump to...
  • File Protocol

    SMB/AFP/NFS/FTP/WebDAV

  • Max. Concurrent SMB/AFP/FTP Connections

    10000
    10000 (with RAM expansion)

  • Windows ACL Integration

    Yes

  • NFS Kerberos Authentication

    Yes

Software: Account & Shared Folder

Jump to...
  • Maximum Local User Accounts

    16000

  • Maximum Local Groups

    512

  • Maximum Shared Folder

    512

  • Maximum Shared Folder Sync Tasks

    32

Software: Hybrid Share

Jump to...
  • Hybrid Share Folder Number

    30

Software: Hyper Backup

Jump to...
  • Folder and Package Backup

    Yes

  • Entire System Backup

    Yes

Software: High Availability

Jump to...
  • Synology High Availability

    Yes

Software: Log Center

Jump to...
  • Syslog Events per Second

    6000

Software: Virtualization

Jump to...
  • VMware ESXi 7.0 and VAAI

    Yes

  • Windows Server 2016

    Yes

  • Windows Server 2019

    Yes

  • Windows Server 2022

    Yes

  • Citrix Ready

    Yes

  • OpenStack

    Yes

Software: General

Jump to...
  • Networking Protocols

    SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fiber Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

  • Supported Browsers

    Google Chrome
    Firefox
    Microsoft Edge
    Safari

  • Supported Language

    English, Deutsch, French, Italian, Espanol, Danish, Norwegian, Swedish, Nederlands, Russian, Polish, Hungarian, Brazilian Portuguese, European Portuguese, Turkish, Czech, Thai, Japanese, Korean, Traditional Chinese, Simplified Chinese

Software: Add-on Packages

Jump to...
  • Antivirus by McAfee (Trial)

    Yes

  • Central Management System

    Yes

Software: Synology Chat

Jump to...
  • Suggested Concurrent Users

    500

Software: Document Viewer

Jump to...
  • Document Viewer

    Yes

Software: SAN Manager

Jump to...
  • Maximum iSCSI Target Number

    256

  • Maximum LUN

    512

  • LUN Clone/Snapshot, Windows ODX

    Yes

Software: MailPlus / MailPlus Server

Jump to...
  • Free Email Accounts

    5 (Additional accounts require purchase of licenses)

  • Suggested Maximum Users

    20000

  • Suggested Concurrent Users

    4000

  • Maximum Server Performance

    3,523,133 emails per day, approx. 103.7GB

Software: Snapshot Replication

Jump to...
  • Maximum Snapshots per Shared Folder

    1024

  • Maximum of System Snapshots

    65536

Software: Surveillance Station

Jump to...
  • Default Licenses

    2 (Additional cameras require purchase of licenses)

  • Maximum IP Cameras and Total FPS (H.264)

    720p: 500 channels, 15000 FPS
    1080p: 450 channels, 4500 FPS
    3M: 200 channels, 4500 FPS
    5M: 180 channels, 2700 FPS
    4K: 150 channels, 1650 FPS

  • Maximum IP Cameras and Total FPS (H.265)

    720p: 650 channels, 19500 FPS
    1080p: 600 channels, 6000 FPS
    3M: 500 channels, 5000 FPS
    5M: 200 channels, 4600 FPS
    4K: 150 channels, 3900 FPS

Software: Synology Drive

Jump to...
  • Recommended Number

    Concurrent Sync Clients: 2,000 (the number of connections that can be maintained when the recommended number of hosted files was reached)

  • Recommended Number of Hosted Files

    100,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)

Software: Synology Office

Jump to...
  • Suggested Maximum Users

    17500

  • Suggested Concurrent Users

    7000

Software: Virtual Machine Manager

Jump to...
  • Recommended Virtual Machine Instances

    40

  • Recommended Virtual DSM Number

    40 (including 1 Free License) (Licenses required)

Software: VPN Server

Jump to...
  • Maximum Connections

    60

  • UPC Code

    846504003648

About Synology High Density HD6500

Why settle for less when you can have the High Density HD6500 60-Bay 4U Rackmount NAS Enclosure with 2x 480GB SATA SSD This reliable and durable storage solution from Synology, a reputable brand in the network-attached storage industry, offers an impressive 960GB capacity, making it a spacious and high-performance choice for both small to medium-sized businesses and personal use.

The HD6500 is not just a storage device; it's a scalable high-density server designed for multi-petabyte applications. With 60 drive bays in a 4U rackmount enclosure and the ability to support up to 300 drives after expansion, it's an ideal solution for large-scale storage applications such as full system backups, video post-production, and extensive surveillance deployments.

Designed for high reliability, the HD6500 ensures that your mission-critical data and services remain accessible, even in the face of disaster. Its out-of-band (OOB) management feature simplifies troubleshooting by allowing remote management of powered-down devices and access to critical logs through a dedicated interface.

The HD6500 also boasts a dual power supply system to reduce the risk of power disruptions affecting data and service availability. Its high-reliability expansion architecture with redundant SAS links ensures that single points of failure do not affect other expansion units, thereby ensuring higher data and service availability.

This user-friendly NAS enclosure supports a wide variety of networking interfaces, protocols, and configurations. It comes with three Gigabit Ethernet and two 10GbE RJ-45 ports for high transfer speeds right out of the box. You can also add extra 10GbE SFP+/RJ-45, 25GbE SFP28, or Fiber Channel ports in varying configurations using the four expansion slots.

With the HD6500, you can consolidate your data storage, host massive file servers, and even set up a private cloud for file sharing. Its Synology Drive feature enables remote data access, synchronization, on-demand file restoration, and backup via desktop and mobile applications. You can also sync data between different platforms and devices, and manage data access privileges with access control lists (ACL) through Active Directory/LDAP integration.

In summary, the High Density HD6500 60-Bay 4U Rackmount NAS Enclosure with 2x 480GB SATA SSD is a reliable, durable, high-performance, spacious, and user-friendly storage solution that offers a host of features designed to meet your storage needs.

Synology High Density HD6500 Features

  • CPU: 2x 10-core Intel Xeon Silver
  • Throughput: Over 6,688/6,662MB/s sequential read/write
  • Memory: 64GB DDR4 ECC, expandable to 512GB
  • Scalability: Expand to 300 drives with four RX6022sas expansion units

Product Documents

User Manual

Key Features

  • Maximize your data storage with this 60-bay Synology NAS enclosure, built for high-density environments.
  • Experience fast performance with dual Intel Xeon CPUs & 64GB ECC memory in this robust NAS server.
  • Ensure data security with advanced RAID options and snapshot replication on this Synology HD6500 NAS.
  • Scale your storage effortlessly; supports up to 300 drives using RX6022sas expansion units on this NAS.
  • Enjoy remote access and manage your files securely from anywhere with Synology's intuitive interface.
  • Streamline your workflow with 10GbE connectivity, perfect for large file transfers on this NAS system.

What's in the box:

  • Synology High Density HD6500 60-Bay 4U Rackmount NAS Enclosure
  • 2x 480GB SATA SSD
  • Sliding Rail Set (RKS-03)
  • Accessory Pack
  • 2x AC Power Cord
  • User Manual
  • Synology 5 Year Limited Warranty
