Synology RackStation RS2423+ 12-Bay 2U Rackmount NAS Enclosure, Diskless

SKU: SYRS242312RS MFR: RS2423+
Earn VIP Reward Points

Key Features

  • This Synology RackStation NAS supports up to 24 drives for massive data storage.
  • Ensure data security with RAID configurations, protecting against drive failures.
  • Experience fast performance with the AMD Ryzen CPU, ideal for demanding tasks.
  • Set up your NAS easily with Synology's intuitive DiskStation Manager (DSM) OS.
  • Rely on Synology's brand for a reliable NAS solution with a 3-year warranty.
  • Access your files remotely and securely with Synology's QuickConnect service.
See More Product Details
Free Expedited Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$289.99

3 Year

$449.99

4 Year

$549.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Synology RackStation RS2423+ Specifications

Hardware: CPU

Hardware: CPU

Jump to...
  • CPU Model

    AMD Ryzen V1780B

  • CPU Quantity

    1

  • CPU Architecture

    64-bit

  • CPU Frequency

    4-core 3.35 (base) / 3.6 (turbo) GHz

  • Hardware Encryption Engine (AES-NI)

    Yes

Hardware: Memory

Jump to...
  • System Memory

    8GB DDR4 ECC UDIMM

  • Memory Module Pre-installed

    8GB (8GB x 1)

  • Total Memory Slots

    2

  • Maximum Memory Capacity

    32GB (16GB x 2)

Hardware: Storage

Jump to...
  • Drive Bays

    12

  • Maximum Drive Bays with Expansion Unit

    24 (RX1223RP x 1)

  • Compatible Drive Type

    3.5" SATA HDD
    2.5" SATA SSD

  • Hot Swappable Drive

    Yes

Hardware: External Ports

Jump to...
  • RJ-45 1GbE LAN Port

    2 (with Link Aggregation / Failover support)

  • RJ-45 10GbE LAN Port

    1

  • USB 3.2 Gen 1 Port

    2

  • Expansion Port

    1

Hardware: PCIe

Jump to...
  • PCIe Expansion

    1 x Gen3 x8 slot (x4 link)

Hardware: File System

Jump to...
  • Internal Drives

    Btrfs
    EXT4

  • External Drives

    Btrfs
    EXT4
    EXT3
    FAT
    NTFS
    HFS+
    exFAT

Hardware: Others

Jump to...
  • System Fan

    3 pcs 60 x 60mm

  • Fan Speed Mode

    Full-Speed Mode
    Cool Mode
    Quiet Mode

  • Easy Replacement System Fan

    Yes

  • Power Recovery

    Yes

  • Noise Level

    52.3 dB(A)

  • Scheduled Power On / Off

    Yes

  • Wake on LAN / WAN

    Yes

  • Power Supply Unit / Adapter

    500 W

  • AC Input Power Voltage

    100 V to 240 V AC

  • Power Frequency

    50/60 Hz, Single Phase

  • Power Consumption

    119.95 W (Access) 46.21 W (HDD Hibernation)

  • British Thermal Unit

    409.56 BTU/hr (Access) 157.78 BTU/hr (HDD Hibernation)

Hardware: Temperature

Jump to...
  • Operating Temperature

    32 Degree F to 95 Degree F (0 Degree C to 35 Degree C)

  • Storage Temperature

    -5 Degree F to 140 Degree F (-20 Degree C to 60 Degree C)

  • Relative Humidity

    5% to 95% RH

Hardware: Certification

Jump to...
  • Certification

    FCC
    CE
    BSMI
    VCCI
    RCM
    UKCA
    EAC
    CCC
    KC
    UL

Hardware: Environment

Jump to...
  • Environment

    RoHS Compliant

Hardware: Appearance

Jump to...
  • Form Factor (RU)

    2U

  • Rack Installation Support

    4-post 19" rack (Synology Rail Kit - RKS-02)

  • Dimensions (H x W x D)

    3.46 x 18.97 x 21.73" (88 x 482 x 552mm)

  • Weight

    25.35 lbs (11.5kg)

Software: Storage Management

Jump to...
  • Maximum Single Volume Size

    200TB (32GB memory required)
    108TB

  • Maximum Internal Volume Number

    64

  • SSD Read / Write Cache (White Paper)

    Yes

  • SSD TRIM

    Yes

  • Supported RAID Type

    Synology Hybrid RAID
    Basic
    JBOD
    RAID 0
    RAID 1
    RAID 5
    RAID 6
    RAID 10

  • RAID Migration

    Basic to RAID 1
    Basic to RAID 5
    RAID 1 to RAID 5
    RAID 5 to RAID 6

  • Volume Expansion with Larger HDDs

    Synology Hybrid RAID
    RAID 1
    RAID 5
    RAID 6
    RAID 10

  • Volume Expansion by Adding a HDD

    Synology Hybrid RAID
    JBOD
    RAID 5
    RAID 6

  • Global Hot Spare Supported RAID Type

    Synology Hybrid RAID
    RAID 1
    RAID 5
    RAID 6
    RAID 10

Software: File Services

Jump to...
  • File Protocol

    SMB/AFP/NFS/FTP/WebDAV

  • Max. Concurrent SMB/AFP/FTP Connections

    2000
    2000 (with RAM expansion)

  • Windows ACL Integration

    Yes

  • NFS Kerberos Authentication

    Yes

Software: Account & Shared Folder

Jump to...
  • Maximum Local User Accounts

    2048

  • Maximum Local Groups

    256

  • Maximum Shared Folder

    512

  • Maximum Shared Folder Sync Tasks

    32

Software: Hybrid Share

Jump to...
  • Hybrid Share Folder Number

    10

Software: Hyper Backup

Jump to...
  • Folder and Package Backup

    Yes

  • Entire System Backup

    Yes

Software: High Availability

Jump to...
  • Synology High Availability

    Yes

Software: Log Center

Jump to...
  • Syslog Events per Second

    1000

Software: Virtualization

Jump to...
  • VMware ESXi 6.5 and VAAI

    Yes

  • Windows Server 2022

    Yes

  • Citrix Ready

    Yes

  • OpenStack

    Yes

Software: General

Jump to...
  • Networking Protocols

    SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

  • Supported Browsers

    Google Chrome
    Firefox
    Microsoft Edge
    Safari

  • Supported Language

    English, Deutsch, French, Italian, Espanol, Danish, Norwegian, Swedish, Nederlands, Russian, Polish, Hungarian, Brazilian Portuguese, European Portuguese, Turkish, Czech, Thai, Japanese, Korean, Traditional Chinese, Simplified Chinese

Software: Add-on Packages

Jump to...
  • Antivirus by McAfee (Trial)

    Yes

  • Central Management System

    Yes

Software: Synology Chat

Jump to...
  • Suggested Concurrent Users

    150

Software: Document Viewer

Jump to...
  • Document Viewer

    Yes

Software: Download Station

Jump to...
  • Maximum Concurrent Download Tasks

    80

Software: SAN Manager

Jump to...
  • Maximum iSCSI Target Number

    128

  • Maximum LUN

    256

  • LUN Clone/Snapshot, Windows ODX

    Yes

Software: MailPlus / MailPlus Server

Jump to...
  • Free Email Accounts

    5 (Additional accounts require purchase of licenses)

  • Suggested Maximum Users

    750

  • Suggested Concurrent Users

    150

  • Maximum Server Performance

    1,484,000 emails per day, approx. 45GB

Software: Media Server

Jump to...
  • DLNA Compliance

    Yes

Software: Synology Photos

Jump to...
  • Facial Recognition

    Yes

  • Object Recognition

    Yes

Software: Snapshot Replication

Jump to...
  • Maximum Snapshots per Shared Folder

    1024

  • Maximum of System Snapshots

    65536

Software: Surveillance Station

Jump to...
  • Default Licenses

    2 (Additional cameras require purchase of licenses)

  • Maximum IP Cameras and Total FPS (H.264)

    720p: 75 channels, 2250 FPS
    1080p: 75 channels, 2100 FPS
    3M: 75 channels, 1500 FPS
    5M: 75 channels, 900 FPS
    4K: 55 channels, 550 FPS

  • Maximum IP Cameras and Total FPS (H.265)

    720p: 75 channels, 2250 FPS
    1080p: 75 channels, 2250 FPS
    3M: 75 channels, 2250 FPS
    5M: 75 channels, 1500 FPS
    4K: 75 channels, 900 FPS

Software: Synology Drive

Jump to...
  • Recommended Number

    Concurrent Sync Clients: 600 (the number of connections that can be maintained when the recommended number of hosted files was reached)

  • Recommended Number of Hosted Files

    50,000,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)

Software: Synology Office

Jump to...
  • Suggested Maximum Users

    4500

  • Suggested Concurrent Users

    1800

Software: Video Station

Jump to...
  • Video Station

    Yes

Software: Virtual Machine Manager

Jump to...
  • Recommended Virtual Machine Instances

    8

  • Recommended Virtual DSM Number

    8 (including 1 Free License) (Licenses required)

Software: VPN Server

Jump to...
  • Maximum Connections

    40

  • UPC Code

    846504004898

About Synology RackStation RS2423+

Find the perfect solution for centralized data management with the RackStation RS2423+ 12-Bay 2U Rackmount NAS Enclosure. This diskless unit offers exceptional performance, delivering over 155K/79K random read/write IOPS and up to 3,500/1,700 MB/s sequential read/write throughput. It's a cost-effective solution for small to medium-sized businesses (SMBs) and branch offices, providing advanced file management and sharing capabilities.

The RS2423+ is designed for reliability, featuring one 10GbE RJ-45 port and two Gigabit RJ-45 ports. These can be bonded with Link Aggregation for automatic network failover and load balancing. For maximum service uptime, two RS2423+ units can be paired using Synology High Availability to form an active-passive server cluster.

This 2U 12-bay unit offers room for expansion, allowing you to adjust its performance, networking speed, or storage capacity to match your business needs. Boost read/write IOPS for HDD arrays with NVMe or SATA SSD cache, and improve I/O or add redundancy with 10/25GbE SFP+/SFP28 or RJ-45 networking options.

The RS2423+ provides secure and convenient cross-platform file access, sharing, and synchronization across multiple locations. With Synology Drive, you can enable efficient collaboration, providing remote data access, synchronization, on-demand file restoration, and backup via desktop and mobile applications. It supports real-time collaboration with Synology Office, allowing concurrent editing of documents, spreadsheets, and slides.

For businesses with multiple locations, the RS2423+ offers efficient multi-site synchronization. Use Hybrid Share to store large sets of data in the cloud, while streaming requested files to local NAS deployed at branch offices. With Hybrid Share-enabled folders, remote teams can access the most up-to-date files while benefiting from a reduced local storage footprint and lower bandwidth usage.

The RS2423+ also offers multi-endpoint data protection, allowing you to design an effective backup strategy to maximize data and system availability. It supports secure backups of Windows, Mac, and Linux endpoints, Synology servers, and VMware and Hyper-V virtual machines with Active Backup for Business. It also allows centralized backups of Microsoft 365 and Google Workspace data, ensuring protection against data loss and simplifying compliance with data retention policies.

For surveillance needs, the RS2423+ supports up to 50 IP cameras and offers wide device compatibility. It provides secure and private storage for footage, with industry-standard AES-256 encryption for added security. With intelligent monitoring features such as motion detection and anomaly detection, you can secure your premises effectively and efficiently.

The RackStation RS2423+ works best with Synology drives, offering high sustained performance and reliability with built-in data protection. It's compatible with a range of HDD and SSD options, including the Enterprise Series 3.5" SATA, Plus Series 3.5" SATA, Enterprise Series 2.5" SATA, and Enterprise Series M.2 NVMe.

Take advantage of the native productivity, management, and security solutions available in the web-based Synology DSM operating system. With the Central Management System, you can manage your fleet of Synology NAS from a centralized console, and shield your Synology NAS from sophisticated threats with industry-leading security solutions. In the event of a server failure, Synology High Availability ensures a seamless transition between clustered servers to minimize the impact on applications.

Synology RackStation RS2423+ Features

  • Secure storage for your business
  • Business-ready: Over 3,500/1,700 MB/s seq. read/write, built-in 10GbE, and up to 216TB raw storage before expansion
  • Flexible configuration: Add 12 extra drive bays, 1/10/25GbE ports, and SSD cache volumes whenever needed
  • Versatile applications: Back up 300 endpoints, manage 50 IP cameras, or safely sync and share files between devices and sites

Product Documents

User Manual

Key Features

  • This Synology RackStation NAS supports up to 24 drives for massive data storage.
  • Ensure data security with RAID configurations, protecting against drive failures.
  • Experience fast performance with the AMD Ryzen CPU, ideal for demanding tasks.
  • Set up your NAS easily with Synology's intuitive DiskStation Manager (DSM) OS.
  • Rely on Synology's brand for a reliable NAS solution with a 3-year warranty.
  • Access your files remotely and securely with Synology's QuickConnect service.

What's in the box:

  • Synology RackStation RS2423+ 12-Bay 2U Rackmount NAS Enclosure
  • Accessory Pack
  • AC Power Cord
  • User Manual
  • Synology 3 Year Limited Warranty
