The SAT5200 SSDs are designed to handle intensive 24/7 enterprise workloads such as multimedia post-production, online transaction processing (OLTP) databases, and virtualization deployments.
The SAT5200 SSD supports end-to-end data protection, ensuring data integrity over the entire transfer path. It also features a power loss protection circuit design and dedicated capacitors to flush data-in-flight into NAND flash in the event of a power loss.
The SAT5200 SSD offers advanced lifetime analytics with full integration with Synology DiskStation Manager (DSM). This allows for real-time monitoring of actual workloads for each drive.
Yes, the SAT5200 drives are purpose-built for Synology systems and are thoroughly tested for compatibility following each engineering change.
The SAT5200 SSD undergoes intensive I/O stress, power cycling, and temperature trials to ensure that it meets the strictest standards for quality and reliability.
Review Summary
2024-09-09T08:06:09
This product was exactly what we wanted. Thanks
CAITLYN O.
3.84TB, 1.92TB
2.5"
SATA 6 Gb/s
530 MB/s
500 MB/s
98,000 IOPS
60,000 IOPS
3.84TB: >7,000 TB
1.92TB: >3,500 TB
1,500,000 hours
<1 sector per 10 bits read
Yes
5 V ( +/- 5%)
3.84TB: 2.6 W
1.92TB: 2.5 W
3.84TB: 3.4 W
1.92TB: 3.3 W
3.84TB: 1.5 W
1.92TB: 1.4 W
32 Degree F to 158 Degree F (0 Degree C to 70 Degree C)
-40 Degree F to 185 Degree F (-40 Degree C to 85 Degree C)
FCC, CE, EAC, BSMI, VCCI, KC, RoHS, UKCA
0.27 x 2.75 x 3.93" (7 x 69.85 x 100mm)
846504006168
Exactly what we wanted!
By CAITLYN O.
This product was exactly what we wanted. Thanks
SSDs with Enterprise-Grade Endurance and Reliability
Synology SAT5200 Series SSDs offer consistent I/O performance, low latency, and enterprise tier endurance. These drives are built to handle mixed and intensive 24/7 enterprise workloads while offering a seamless storage experience on Synology systems. SAT5200 SSDs feature advanced lifetime analytics.
Stable Performance for Demanding Workloads
Engineered for demanding workloads such as multimedia post-production, online transaction processing (OLTP) databases, and virtualization deployments, Synology SAT5200 SSDs improve the performance and responsiveness of I/O intensive applications. They allow firms to modernize their existing storage infrastructure and boost performance at a competitive per-unit cost.
Enterprise-Grade Endurance and Data Protection
Synology SAT5200 SSDs are built to withstand 24/7 intensive and mixed workloads in all-flash storage and cache applications with an enterprise endurance of over 10,000 TBW. SAT5200 SSDs support end-to-end data protection to safeguard data integrity over the entire transfer path. Power loss protection circuit design prevents data corruption. Dedicated capacitors provide power to flush data-in-flight into NAND flash in a power loss event and firmware is designed to enable a correct restart on the next power-up.
Real-World Workload Analytics
Full integration with Synology DiskStation Manager (DSM) allows Synology systems to provide lifetime analytics based on actual workloads for each SAT5200 drive. Timely notifications allow you to plan further ahead for uninterrupted system performance and longevity.
Purpose-Built for Synology Systems
Synology SAT5200 drives are thoroughly tested for compatibility with our systems following each engineering change, while firmware and component changes are strictly managed. Firmware updates can be installed through Synology DSM at a touch of a button. Intensive I/O stress, power cycling, and temperature trials ensure that all products meet our strictest standards for quality and reliability.
