Review Summary
Multi-zone foreground music and paging
Boardrooms, offices and courtrooms
Business music systems
Airports, convention centers and hotels
Auxiliary systems in houses of worship
Lounges and bars
Cruise ships
65 Hz - 30 kHz
53 Hz - 40 kHz
92 dB (1 W = 4 V for 16 Ohms)
90 degrees conical
Average: 90 W
Programme: 180 W
Peak: 360 W
180W at 16 Ohms
16 Ohms
Average: 111 dB
Peak: 117 dB
70 V: 60 W / 30 W / 15 W / 7.5 W / OFF & low impedance operation
100 V: 60 W / 30 W / 15 W / OFF & low impedance operation
1x 8" (20.32cm) Dual Concentric driver, using Omnimagnet technology
1.75" (4.45cm) voice coil, treated multi fiber paper pulp cone
1" (2.54cm) PEI dome
ABS
Weather-resistant zinc nickel-plated steel grille
Removable locking connector with screw terminals
Rotary switch
Excluding bracket: 407.5 x 260.0 x 259.7mm (16.04 x 10.24 x 10.22")
Including bracket: 409.8 x 260.0 x 306.3mm (16.13 x 10.24 x 12.06")
7.82kg (17.24 lbs)
The AMS 8DC is a full bandwidth 360-Watt high sensitivity loudspeaker that utilizes our all-new proprietary 8" Dual Concentric point-source driver with Omni magnet technology on a Torus Ogive Waveguide to deliver wide and consistent broadband directivity with enhanced intelligibility - plus the linear response of our legendary studio monitors. The AMS 8DC is ideally suited for stereo or mono background/foreground music applications in theme parks, hotels, restaurants and bars, retail stores, as well as corporate AV, residential developments and houses of worship. AMS 8DC loudspeakers provide a seamless sound signature within a multi-zoned environment that benefits from both ceiling and wall mounted Tannoy loudspeakers.
Weather-Resistant Enclosure
The elegantly styled semi matt black molded enclosure blends beautifully into any decor. Additionally the AMS 8DC's design and performance has achieving an IP65 rating, making it an exceptional choice for both indoor and outdoor environments such as indoor swimming pools, saunas or work areas with unusually high levels of dust or moisture and outdoor applications where weather conditions are moderate.
Attractive and Easy to Install
The highly durable and heat resistant ABS enclosure features a black painted finish and comes with an aesthetically pleasing grille. Installation is quick and easy thanks to the included color-matched yoke mounting bracket - and an optional VARIBALL multi-angle bracket is available separately. An included weatherproof cable gland protects the Phoenix input and link output connectors, as well as the integral low-insertion loss 60 W transformer with convenient tap switching.
LAB GRUPPEN Ready
AMS 8DC is optimized for use with LAB GRUPPEN LUCIA amplifiers, which accommodate up to 8 AMS Series loudspeakers per channel.
