Turbosound Siena TSP118B-AN 18" Powered Subwoofer with KLARK TEKNIK DSP Technology and ULTRANET Networking, 3400W Peak Power

SKU: TBTSP118BAN

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Turbosound Siena TSP118B-AN Specifications

  • Frequency response

    35Hz 90Hz +/-3dB
    32Hz 100Hz -10dB

  • Nominal dispersion

    Half Space

  • Maximum SPL

    134dB peak

  • Crossover type

    Active

  • Transducers

    1x 18" / 457.20mm LF driver

  • Limiter

    Independent LF, peak and rms

  • Limiter

    Independent LF, peak and rms

  • Maximum output power

    3000W

  • Type

    Class-D

  • Protection

    Short circuit, thermal

  • Protection

    Short circuit, thermal

  • Input/link

    1x Combo Jack/XLR, 1x XLR

  • Sensitivity

    +4 dBu or +14 dBu software switchable

  • Input impedance

    40 kOhms balanced

  • Maximum input level

    +22 dBu

  • Ultranet input/link

    2x RJ45

  • Mains Supply

    Neutrik powerCON 20A

  • DSP Control

    Rotary push-encoder and level control
    Buttons for process, setup, exit, enter

  • Factory EQ presets

    Positioning, Sound mode FBQ

  • Display

    LCD 128 x 32, blue, backlit

  • Delay

    0 - 300 ms

  • Equalization

    High and low shelving EQ
    2x parametric EQ

  • Presets

    20 total presets, 19 user-definable

  • Crossover

    High Pass L-R 24 dB/oct

  • Ultranet Network: Digital processing

    A/D conversion: 24-bit, 44.1/48 kHz sample rate
    Converter type: 24-bit, delta-sigma

  • Ultranet Digital Network: System

    Signal 16 channels
    Latency: < 0.9 ms
    Frequency response: 20Hz to 20kHz (+0 / -3dB)
    Dynamic range: typical 92dB

  • Ultranet Digital Network: Cabling

    Cables: Shielded CAT5
    Cable length: Max. 246' / 74.98m recommended

  • Power consumption

    180W at 1/8 max power

  • Voltages

    120 V, 60Hz (T 15 A H 250 V)

  • Construction

    18 mm (3/4") birch plywood

  • Grille

    Powder coated perforated steel

  • Dimensions (H x W x D)

    693 x 523 x 725mm / 27.28 x 20.59 x 28.54"

  • Weight

    46.3kg / 102.07lbs

  • UPC Code

    748252151643

About Turbosound Siena TSP118B-AN

The Siena 3,000 Watt TSP118B-ANis a powered 18" front loaded, bass reflex subwoofer enclosure that is optimally tuned for extended low frequency response. Designed to work individually without a controller, the TSP118B-AN provides very high output FOH performance and is ideally suited for a wide range of music and live sound reinforcement applications.

• Front loaded powered subwoofer for portable PA applications
• 3,000 Watt power featuring KLARK TEKNIK Class-D technology
• KLARK TEKNIK Digital Signal Processing for total system control
• ULTRANET digital audio networking connects to mixers and other sources
• 18" low frequency driver with inside/outside wound coil for high power handling
• Fully featured user interface with LCD display for ease of navigation
• PC remote control software downloadable at Turbosound.com
• Low distortion bass reflex port design
• 18 mm (3/4") birch plywood enclosure with hard wearing semi matt black paint finish
• Rugged powder coated perforated steel mesh grille
• 35 mm pole mount to support satellite speaker
• Durable handles for easy lifting and carrying
• Mains input on Neutrik powerCON connectors
• Designed and engineered in England

Custom-Engineered Drivers
Turbosound is recognized the world over for designing and building some of the most iconic loudspeakers and subwoofers. They take meticulous care and pride in maintaining that reputation by utilizing only drivers designed specifically for each application it's what sets them apart from the competition. The TSP118B-AN features a powerful 18" low frequency driver that utilizes a special inside/outside wound voice coil for higher magnetic density, better heat dissipation, high power handling capacity and improved efficiency. For its size and operating bandwidth, theTSP118B-AN delivers extremely high output that is virtually distortion-free for world-class low frequency performance that will stand the test of time.

Turbosound Siena TSP118B-AN Features

  • Ultranet Network: Digital processing A/D conversion: 24-bit, 44.1/48 kHz sample rate
    Converter type: 24-bit, delta-sigma
  • Ultranet Digital Network: System Signal 16 channels
    Latency: < 0.9 ms
    Frequency response: 20Hz to 20kHz (+0 / -3dB)
    Dynamic range: typical 92dB
  • Ultranet Digital Network: Cabling Cables: Shielded CAT5
    Cable length: Max. 246' / 74.98m recommended

What's in the box:

  • Turbosound Siena TSP118B-AN 18 " Powered Subwoofer
  • Turbosound 3 Year Warranty
