TC Electronic D22 Precision Digital Broadcast Delay with Seamless Delay Update
SKU: TC951100111
This item is no longer available.
Share:
Overview
Compare
Specs
Protection
About TC Electronic D22
Precision. Control. Reliability
D22 is all about precise and reliable delay, as broadcasted audio needs to be 100% aligned and 'in-sync'. Therefore, you may sometimes have to insert just a slight delay. It may seem like an insignificant adjustment, but in reality, it makes all the difference!
• Make It Fit - High-resolution Delay for Broadcast Master Control and Linking
• Take Total Control - Nudge and Tap Keys for Easy Front-panel Adjustments
• Flexible Format Handling - Delays Linear Audio as well as Dolby E or AC3 Streams
Unique Interface
• You can display the delay resolution in frames, sub-frames, milliseconds and sub-milliseconds (0.1 ms increments)
• The tapped delay time can be previewed before insertion or you can choose to apply delay time immediately
• You also get a 'Set and Forget' lock function if you use D22 in a 'fixed' environment.
Remote Control
• You can remote control D22 via an RS-485 connector which allows you to change the delay time or even the full setup, from a distance
• GPI (General Purpose Impulse) even gives you to external control of Tap Tempo as well as the Master Fader output.
Ultimate Hardware
• Industry-leading 24-bit AES/EBU, S/PDIF and AD/DA converters are just part of the story
• Even when bypassing D22, true 24-bit resolution is maintained, leaving the digital signal untouched
• When used in Analog setups, D22 features hardwired bypass for an uninterrupted signal flow in case of loss of power
TC Electronic D22 Features
- High-resolution digital broadcast delay unit with Seamless Delay Update lets you precisely insert delay to make your broadcast audio align perfectly with motion pictures
- Exceptional Seamless Delay Update adjusts your audio cleanly without any clicks, noise, or pitch changes
- User-friendly interface lets you easily nudge or tap your delay resolution in frames, sub-frames, milliseconds and sub-milliseconds and preview or insert it instantly
- Flexible unit allows delaying linear audio as well as Dolby E or AC3 streams
- RS-485 connector lets you change the full recall setup and delay time remotely
- GPI provides remote external control of digital fader, Tapped Delay Time and Bypass
- Industry-leading 24-bit AES/EBU, S/PDIF and AD/DA converters, with true 24-bit delay resolution maintained even when bypassing the unit
- Massive delay of up to 5200 ms per channel
- Sample rates of 44.1, 48 kHz internally and 32, 44.1 and 48 kHz externally, with sample rate conversions from 31 - 49 kHz
- Programmable setups and presets give you total recall
- Built-in, remotely-controllable Digital Output Fader
- "Set and forget" user-interface lock function for use in a fixed environment
- 3-Year Warranty Program
- Designed and engineered in Denmark
