Teradek Bolt 999 Bolt 10K HD-SDI/HDMI Wireless Receiver with Gold Mount
See all Teradek items

Teradek Bolt 999 Bolt 10K HD-SDI/HDMI Wireless Receiver with Gold Mount

SKU: TE100999G

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Teradek Bolt 10K Specifications

Video

Video

Jump to...

  • Video Outputs

    1x SD/HD/3G-SDI (75 Ohm BNC)
    1x HDMI Type-A receptacle

  • SDI Ancillary Data Support

    Supports metadata, timecode and start/stop flags

  • Color Sampling

    SDI: YCbCr 4:2:2, 10-bit (8-bit when format conversion is enabled)
    HDMI: RGB 4:4:4, 8-bit

  • Delay Tx To Rx

    <0.001sec (without format conversion)

Supported Resolutions

Jump to...

  • Supported Resolutions

    1080p 23.98/24/25/29.97/30/50/59.94/60
    1080psf23.98/24/25/29.97/30
    1080i50/59.94/60
    720p50/59.94/60
    480p59.94/576p50 (via HDMI ports only)
    480i (NTSC)/576i (PAL)

Video Processing

Jump to...

  • Video Compression

    Visually lossless

  • Test Pattern Generator Support

    Yes

  • Color Correction

    CDL/1024 1D LUT (supports 10-bit color)
    33x33x33 3D LUT (supports 10-bit color)

Audio Processing

Jump to...

  • Audio Compression

    48kHz 24-bit PCM

Construction

Jump to...

  • Construction

    ABS Plastic and CNC Aluminum 6061-T6

Mountability

Jump to...

  • Mountability

    Gold Mount Battery Plate in Back
    Multiple mounting options with 3/8" holes

Interfaces

Jump to...

  • HTTP

    No

  • Configuration Interfaces

    OLED Screen with Menu Joystick Navigation

  • Desktop App

    Feature-rich Bolt Manager Application for OSX & Windows

  • USB Interface Functionality

    Upgrade via Mini-USB

Network

Jump to...

  • Wireless

    Non-DFS Frequencies: US: 5.19 - 5.23 GHz and 5.755 - 5.795 GHz
    EU & JP: 5.19 - 5.23 GHz
    DFS Frequencies: US: 5.27 - 5.31 GHz and 5.51 - 5.67 GHz
    EU & JP: 5.51 - 5.69 GHz

  • RF Channel Selection

    Auto and Configurable Channel selection

  • Encryption

    AES-128

  • RF Power

    17dbm EIRP(with one 2dbi TX antenna)

  • Range

    Up to 10,000 ft line of sight

  • Noise Rejection

    Can coexist with Wi-Fi and 5GHz cordless phones

Power

Jump to...

  • Power Input

    2-Pin Connector 6-28 VDC or Gold Mount Battery

  • Battery

    No

  • Nominal Power Consumption

    8.5 Watts (Measured at 1080p60)

Environmental

Jump to...

  • Operating Temperature

    0 to 50 deg. C (32 to 122 deg. F)

General

Jump to...

  • Dimensions

    9.29 x 9.29 x 2.61" (23.60 x 23.60 x 6.63cm)

  • Weight

    41.6 oz (1179.34g)

Other

Jump to...

  • UPC Code

    818264022641

About Teradek Bolt 10K

Bolt 10K is an ultra high-performance, zero-delay video receiver with a range of 10,000 feet. The RX is compatible with Bolt 3000 transmitters and functions seamlessly alongside 3000 receivers, Sidekick II and the 703 Bolt. Bolt 10K receivers support 1080p60 4:2:2 video and with a newly-designed chassis, hassle-free Tx/Rx pairing, robust range and visually lossless HD quality make this our strongest unit we've ever built.

Teradek Bolt 10K Features

  • Super long range (10,000') receiver for Bolt 3000 TX
  • Works alongside Bolt 3000, 703 Bolt and Sidekick II receivers
  • Fully integrated panel antenna
  • Built-in Gold mount battery plate
  • 3G-SDI and HDMI outputs

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Teradek Bolt 999 Bolt 10K HD-SDI/HDMI Wireless Receiver (Gold Mount)
  • 10 " SDI Cable
  • 18 " HDMI Cable
  • 3' USB Cable
  • Power Supply
  • Light Stand Adapter
  • Hard Case
  • Teradek 1 Year Warranty
