Teradek Bolt 6 LT 750 3G-SDI/HDMI Wireless Receiver with Internal Antennas, Gold Mount, 750' Range

SKU: TE102264G MFR: 10-2264-G
Earn VIP Reward Points

Key Features

  • Experience reliable connection with this Teradek Bolt 6 LT 750 wireless receiver.
  • Achieve long range, up to 750', for flexible, on-location video transmission setups.
  • Enjoy low latency, visually lossless video for seamless, real-time monitoring.
  • This wireless receiver supports up to 1080p60 for high-quality image clarity.
  • Simple to use with auto RF channel selection for quick, hassle-free setup.
  • Affordable price point for professional-grade wireless video without breaking the bank.
See More Product Details

Product Options

Ships from Manufacturer?
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$99.99

3 Year

$159.99

4 Year

$191.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2024-07-13T16:26:04

Rated 1 out of 5

Teradek now doesn't include a hard case

I am astonished that Teradek no longer includes a hard case even though I just paid almost $3k for it. That is just crazy.

KEITH G.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Teradek Bolt 6 LT w/Int Antenna Specifications

Video
  • Video Outputs

    3G-SDI SMPTE 424M standard/75 Ohm (BNC x 1), 1x HDMI 1.4b Type-A receptacle

  • Sdi Ancillary Data Support

    Supports reading metadata, timecode, and start/stop flags from most camera manufacturers.

  • Color Sampling

    SDI: YCbCr 4:2:2, 10-bit/ HDMI: RGB/YCbCr 4:4:4 8-bit, 4:2:2 10-bit

  • Delay Tx to Rx

    <0.001sec

  • Output Video Scaling

    No (4Kp30 signals are output on HDMI, but scaled to 1080p30 and output over SDI. 4Kp60 signals received from Bolt 6 XT devices are scaled to 1080p60 and output over both HDMI and SDI outputs)

Supported Resolutions

Jump to...
  • Supported Resolutions

    4Kp23.98/24/25/29.97/30 (HDMI only)
    1080p23.98/24/25/29.97/30/50/59.94/60
    1080psf23.98/24/25/29.97/30
    1080i50/59.94/60
    720p50/59.94/60

Video Processing

Jump to...
  • Video Compression

    Visually Lossless

  • Test Pattern Generator Support

    Yes

  • Spectrum Analyzer

    Yes

  • Color Correction

    None

Outputs

Jump to...
  • Audio Output

    Embedded SDI/HDMI Audio Input (2 Channel)

Interfaces

Jump to...
  • Configuration Interfaces

    OSD with Menu, Joystick Navigation

  • Switches

    On/Off Switch

  • Mobile App

    Bolt App

  • Desktop App

    Bolt Manager application for OSX & Windows

  • USB Interface Functionality

    Upgrade via Micro-USB

  • Bluetooth

    2.4 GHz

Network

Jump to...
  • Antennas

    4x Internal 2dBi Antennas

  • Wireless

    DFS Frequencies: 5.270 - 5.670 GHz Non-DFS Frequencies: 5.190 - 5.230 GHz, 5.755 - 5.795 GHz, and 5.945 - 6.425GHz

  • Rf Channel Selection

    Auto, Manual

  • Encryption

    AES-256, RSA-1024 key exchange

  • Rf Power

    21 dbm EIRP

  • Range

    Up to 750' (228.6m), line of sight

  • Unicast Multicast

    Can connect one Transmitter to up to 6 Receivers

  • Noise Rejection

    Can coexist with WiFi and 5GHz cordless phones
    Can operate up to 6 sets in same location

  • Interoperability Compatibility

    Can receive wireless video to all ranges of Bolt 4K XT and Bolt 4K LT receivers (limited by shortest range device)

  • Power Input

    2-Pin Circular locking Connector 6-28 VDC

  • Battery

    None, optional Gold or V mount battery plate

  • Nominal Power Consumption

    11 Watts

Environmental

Jump to...
  • Operating Temperature

    0-104 degree F (0-40 degree C)

Battery

Jump to...
  • Battery Info

    Optional, Not Included

  • Battery Material

    Lithium-ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Physical

Jump to...
  • Construction

    Milled Aluminum (Chassis) and regulation-compliant PCB

  • Mountability

    Multiple mounting options with 3/8"x16 and 1/4-20" holes

  • Dimensions

    4.8 x 4.2 x 1" (122.4 x 106.2 x 27.1mm)

  • Weight

    10.7 oz (304g)

  • UPC Code

    810156140389

About Teradek Bolt 6 LT w/Int Antenna

Discover the Bolt 6 LT 750 3G-SDI/HDMI Wireless Receiver, a cutting-edge device designed to revolutionize your video transmission experience. This wireless receiver supports high-definition video formats up to 1080p60 10-bit 422 HDR over 3G-SDI, and 4K30 over HDMI, ensuring crystal clear video quality.

Powered by Teradek's patented Zero-Delay silicon chip, the Bolt 6 LT RX utilizes the 5GHz and 6GHz radio frequencies to deliver wireless video with zero latency. This technology ensures seamless and uninterrupted video transmission, making it an ideal choice for professional videography and broadcasting.

The Bolt 6 LT RX offers three line-of-sight options to cater to different transmission needs. Choose from a 750 ft., 1500 ft., or the MAX model, which can be configured for an impressive range of up to 5,000 ft when paired with the optional Array Antenna and Broadcast Mode.

This wireless receiver is designed for versatility, offering the option to upgrade your set to include Gold or V-Mount Battery plates. It is cross-compatible with the entire Bolt 4K Series, including Bolt 4K, Bolt 4K LT, and the Bolt 4K Monitor Modules, providing you with the flexibility to expand your workflow requirements as needed.

The Bolt 6 LT RX allows you to link up to 6 receivers to one transmitter, or an unlimited number of receivers when used in Broadcast Mode (available on MAX models). The 750 model includes V (vertical) Antennas, while the 1500 and MAX models come with both V Antennas and H (horizontal) antennas. These H Antennas are specifically designed to maximize signal robustness in challenging RF environments.

For those seeking a more compact and durable form factor, the 750 model of Bolt 6 LT RX can be optionally equipped with internal antennas, ensuring reliable zero-delay transmission without compromising on portability. Experience the future of video transmission with the Bolt 6 LT 750 3G-SDI/HDMI Wireless Receiver.

Teradek Bolt 6 LT w/Int Antenna Features

  • Wirelessly captures lossless HD video up to 750' away
  • Supports up to 4K30 video reception with 10-bit HDR capabilities
  • Boasts a luminous OLED display for intuitive use
  • Equipped with both HDMI and 3G-SDI outputs for versatility
  • Seamless integration with the Bolt 6 and Bolt 4K series transmitters
  • Enhanced long-range mode and metadata handling surpassing previous models
  • Robust AES-256 encryption and RSA 1024 key pairing ensures video security
  • Efficient noise rejection for interference-free transmission, regardless of surrounding wireless traffic
  • Time code and start/stop triggers transmission supported
  • Bolt Manager software and app availability for iOS and Android with Bluetooth connectivity
  • Integrated spectrum analyzer, channel selection tools, and remote configuration tools
  • Multiple mounting options with 1/4"-20 and M3 mounting threads
  • Cross-compatible with the extensive Bolt 4K Series
  • Flexible frequency adjustments in high-traffic areas using the 6GHz wireless frequency
  • Passes metadata, timecode, and start/stop flags seamlessly

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Experience reliable connection with this Teradek Bolt 6 LT 750 wireless receiver.
  • Achieve long range, up to 750', for flexible, on-location video transmission setups.
  • Enjoy low latency, visually lossless video for seamless, real-time monitoring.
  • This wireless receiver supports up to 1080p60 for high-quality image clarity.
  • Simple to use with auto RF channel selection for quick, hassle-free setup.
  • Affordable price point for professional-grade wireless video without breaking the bank.

What's in the box:

  • Teradek Bolt 6 LT 750 3G-SDI/HDMI Wireless Receiver with Internal Antennas
  • 18" 2-Pin to P-Tap Cable
  • 6' 2-Pin to AC Adapter 18W
  • 18" Ultra Thin HDMI Male to Male Cable
  • 10" SDI Cable
  • 3.2' USB-C 2.0 Male to Male Cable
  • Teradek 1 Year Limited Warranty
