Teradek Bolt 6 XT MAX 12G-SDI/HDMI Wireless Transmitter and 10K Receiver Kit, Gold Mount

Bolt 6 XT is a wireless video transmission system that supports up to 4Kp60 10-bit 422 HDR video over 12G-SDI. Bolt 6 uses Teradek's patented Zero-Delay silicon chip to send wireless video over 5GHz and 6GHz radio frequencies. This kit includes a Bolt 6 XT TX and a Bolt 6 XT 10K RX.

Bolt 6 XT 10K RX is a zero-delay video receiver, offering a remarkable wireless range of up to 10,000 feet (3 kilometers). Its enhanced directional antenna is specifically designed for superior RF performance, minimizing interference by focusing signal reception and benefiting from robust internal shielding. Its all-in-one enclosure design not only boosts range and reliability in challenging RF environments, but it also eliminates the hassle of external antenna cables. This results in a much cleaner setup, expediting deployment from its case onto a c-stand. To maximize range, enable Broadcast Mode on the Bolt 6 XT TX.

Control your setup with ease using the Bolt App, which simplifies device pairing, allows fine-tuned frequency adjustments, and includes a built-in spectrum analyzer for advanced RF diagnostics. This kit is compatible with additional Bolt 6 and Bolt 4K receivers.

- Bolt 6 XT MAX Transmitter -
Bolt 6 XT TX is a wireless video transmitter that supports up to 4K60 10-bit 422 HDR video over SDI. Bolt 6 uses Teradek's patented Zero-Delay silicon chip to send wireless video over 5GHz and 6GHz radio frequencies. Bolt 6 XT TX can be configured for up to 5,000 ft when using the optional Array Antenna and Broadcast Mode.

The Transmitter is cross-compatible with the entire Bolt 4K Series - including Bolt 4K, Bolt 4K LT, and the Bolt 4K Monitor Modules - giving you the option to expand your workflow requirements. Link up to 6 receivers to one transmitter, or unlimited receivers when used in Broadcast Mode.

MAX model include both V Antennas and H (horizontal) antennas. H Antennas are designed to maximize signal robustness in the most challenging RF environments.

Features
• Up to 4K30 10-bit 422 HDR Video with Zero-Delay
• 5GHz and 6GHz Auto or Manual Frequency Selection
• 6GHz is available in the US, EU, Canada, Japan, and Australia/New Zealand

- Bolt 6 XT 10K Receiver -
Bolt 6 XT 10K RX is a zero-delay video receiver, offering a remarkable wireless range of up to 10,000 feet (3 kilometers) over 5 or 6GHz frequencies. Compatible with both Bolt 6 and Bolt 4K transmitters, it integrates seamlessly into any existing Bolt 4K or Bolt 6 system.

Delivering visually lossless 4Kp60 4:2:2 video via two 12G-SDI outputs, the Bolt 6 XT 10K RX ensures professional-grade image quality. Its enhanced directional antenna is specifically designed for superior RF performance, minimizing interference by focusing signal reception and benefiting from robust internal shielding.

Its all-in-one enclosure design not only boosts range and reliability in challenging RF environments but it also eliminates the hassle of external antenna cables. This results in a much cleaner setup, expediting deployment from its case onto a c-stand. To maximize range, enable Broadcast Mode on both Bolt 6 XT or LT TX.

Control your setup with ease using the Bolt App, which simplifies device pairing, allows fine-tuned frequency adjustments, and includes a built-in spectrum analyzer for advanced RF diagnostics.

Features
• Supports up to 4Kp60 10-bit 4:2:2 HDR
• Fully integrated, directional panel antenna
• 2x 12G-SDI and 1x HDMI outputs
