2RU Chassis, with convertible configuration for standard 19" rackmount or set-top box with feet included
Microsoft Windows 10 Enterprise IoT LTSC 64-bit
4 HDMI ports (Gear Capture)
1 TB (-20 hrs of HD video)
Telestream Wirecast Pro
NewBlue Titler Live Complete for creating rich, animated title designs
Telestream Switch Player to play, inspect and make corrections to video
Processor - Intel Core XEON E-2176G 12M Six Core 3.7GHz/4.7GHz Turbo
Intel UHD Graphics 630
Memory - 16GB DDR4 Dual Channel Memory
System Drive - M.2 NVMe System Drive
Storage Drive(s) - High speed SATA 6Gb/s SSD
Video Ingest - Four (model 310/320) or five (model 420) channel professional camera inputs with HDMI or SDI
Intel USB 3.1 with USB Type-C
115dB SNR HD Audio with Built-in Rear Audio Amplifier
Dual Intel GbE LAN RJ45
PS/2 Keyboard/Mouse Port
USB 3.0 Ports - 4 rear/2 front
Display outputs - DVI-D, dual HDMI, dual DP
Yes
AC input, auto-sensing, suitable for most countries worldwide
Input Range: 90 - 264Vac (RMS), Full Range Input
Frequency: 47 - 63Hz
Input Current: Max 6A (RMS) at 115Vac, 3A (RMS) at 230Va
16.55 x 9.85 x 2.25" (42.03 x 25.01 x 5.71cm)
2.0 U rackmount height
Live video production simplified!
Wirecast Gear gives you an easy to use, fully configured live video streaming production system. Because we've already done all the work, there is no need to build your own system! Start streaming in minutes with an end-to-end system configured specifically for your needs. With Wirecast Pro included alongside Gear's custom-designed hardware, it's a live event production switcher, live news production system, Facebook Live switcher and YouTube Live switcher - all in one box.
Each model of Wirecast Gear comes with Xeon Server architecture, up to five HD-SDI or four HDMI professional camera inputs and all the live video streaming production features of Wirecast Pro, the Stock Media Library, NewBlue Titler Live Complete, and Switch Player, all in a compact, powerful hardware system.
Wirecast Gear offers a unique blend of performance, ease of use and affordability. Just plug in your cameras and start producing and streaming your professional events with the industry-leading turnkey video production system.
A fully configured, end-to-end live video production solution
Capture
With a durable and portable rack mounted design, Wirecast Gear is the perfect hardware for your permanent studio or for use on location. HDMI or SDI inputs, server-grade components and industry-leading XLR/TRS combo audio inputs make ingesting media into your Wirecast Gear unit both reliable and easy
Production
With Wirecast Pro, the integrated Stock Media Library, Switch Player and NewBlue Titler Live Complete preloaded into all Gear units, producing your live streams has never been more professional, polished or powerful. Create beautiful titles, draw from over 500,000+ unique media assets, and pull it all together with Wirecast Pro to create the perfect broadcast for your viewers, no matter the destination.
Streaming
Encoding live streams can take a toll on a computer's CPU, but not on Wirecast Gear. With hardware accelerated encoding, Xeon server architecture, a dedicated NVIDIA QUADRO graphics card, multiple simultaneous encodes and 3rd party thermal testing, Wirecast Gear is ready for even the most demanding broadcasting schedules and workflows.
Get your live video streaming production system now:
With 4 HDMI capture ports for your consumer cameras, professional XLR/TRS combo audio inputs and full 60 FPS workflow capabilities, there is no better way to get your streams up and running. The 310 is perfect whether you are broadcasting from your church, high school, concert venue or more!
