This item is no longer available.
Review Summary
Intel CeleronJ1900 Quad-Core SoC
4GB DDR3
8GBMemory Compatibility List
RJ-45x2 : 10/100/1000 BASE-TX Auto MDI/MDI-X
WOL supported (eth0)
USB 3.0 host port x3 (Front x1,Back x2)(A Type)
USB 2.0 host port x2 (Back x2)(A Type)
Power LED: White
WAN/LAN1 LED: White
LAN LED: White
USB LED: Activity/Failure: White/Red
System LED: Activity/Failure: White/Red
LCM display
4 buttons (ENTER, ESC, UP, DOWN)
HDMI port (back x1)
Supported
5 x SATA for internal
200W Internal Power Supply
Thermal sensor on processor temperature
System FAN speed controlled by temperature
Battery-backed up system clock
Auto power on after shutdown due to power loss
Adjustable frequency alarm
Power button
LCM button
Temperature: 0deg. C to 40deg. C (Operation)
-40deg. C to 70deg. C (Non-operation)
Humidity: 0 - 80 % R.H. (Non-condensing)
5bays Tower Metal Chassis
CE/FCC/C-Tick/VCCI/BSMI
RoHS
WEEE
RAID 0, 1, 5, 6, 10 and JBOD
Supported
Supported
Supported
Supported
Supported
AES256bit
Available spin-down on idle setting
Supported
Supported
Supported
Supports volume-based roaming to other Thecus NAS.(OS7 64bit)
Supported
Supported
Fixed IP address, dynamic IP address
TCP/IP/AppleTalk
SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
Load balance, Failover, 802.3ad, Balance-XOR, Balance-TLB, Balance-ALB, Broadcast
IPV6 & IPV4
Supported
Supported
Supported
Supported
Supported
Supported
Supported
Monitoring CPU, memory, temperature, fan, network utilization and protocols access user count
Send syslog to assigned location
Act as syslog server to receive log info from other systems
Windows XP and after
Windows Server 2003 and after
UNIX/Linux
Mac OS X
Built-in FTP server with bandwidth control
Built-in secure FTP server with bandwidth control
Users can download and upload files with TFTP programs
Bit Torrent download (via Transmission module)
NZB download (via NZB module)
Supported
Supports USB printers
Supports a wide range of IPP printers
Client can manage print tasks (list/delete) via web user interface
Acronis True Image (OEM version)
Acronis True Image (OEM version)
Supported
Supported
Supported
Supported
Supported
Supports Microsoft/Mac OS X/Linux initiators and Thecus NAS targets
Supported
Supported
Supported
Supported
Supported
Supported
Supported
EXT4/XFS/Btrfs
Supports AAC, MP3 w/ID3 tag and WAV
Supports uPnP AV streaming protocol(via Module)
Supports built-in user accounts
Supports built-in user groups
Supported
Supported
Supports Black & White list/IP Filter
Supported
Supported
Supported
Supported (via module)
Supported (via module)
Supported
Journaling File System
Unicode Support
"Read", "write", or "deny" privileges to individual users or groups in folders and sub-folders
Supported (exclude Btrfs)
Supported (Btrfs only)
Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish, Portuguese
MS Windows Setup Wizard
Supports Windows XP and after
Mac OS X Setup Wizard
Sends system messages via email to the system administrator
Mail or FB account to register
System information trap out
Uploading, downloading and streaming multimedia
Uploading, downloading and streaming multimedia and webcam via P2P connection
Supports Intel Security (via module)
Can extend for 5 additional iSCSI volumes from other Thecus NAS
Supported
Supported (via module)
Supported (via module)
Supported
Supported
Supports via Motion Eye
Supported through USB interface
X-Window via HDMI output
Acronis Software
9.06 x 7.48 x 9.45" (23.01 x 19.00 x 24.00cm)
5.09kg (11.22lbs)
884956004356
Thecus today announced the launch of its newest 5-bay NAS, the N5810 that offers optimized performance with an advanced set of features for both home and business users. The N5810 features an Intel Celeron processor J1900 Quad Core 2.0 GHz SoC and 4 GB of DDR3 RAM that can be expanded to 8GB for further performance optimization. "The N5810 provides an ideal solution for home and business users who require an economical, high performance storage solution that can offer an expansive set of features to satisfy the needs of a wide range of user segments," said Florence Shih, CEO at Thecus Technology Corp. "With advanced data protection and security mechanisms as well as convenient scalability, the N5810 is designed to meet the evolving demands of data storage.
Faster Transfers: 2 LAN Ports for Link Aggregation
99% Virus Prevention: Bundled with Free Intel Security
System Redundancy: Uninterrupted Accessibility with Thecus System Failover
Multiple File Systems:EXT4/XFS/Btrfs
Optimal Performance: Embedded with Intel Celeron J1900 Quad Core CPU
Flexible Expansion: Stackable for up to 5 additional iSCSI volumes with other Thecus NAS
Complete Client Side Protection: Bundled with Free Acronis Software
Easy Customization: Over 700 Apps available in the Thecus App Center
The N5810 is an advanced yet affordable network storage solution, providing up to 213 mb/s read and 186 write speeds with 2 Gigabit LAN ports. The N5810 supports 7 modes of link aggregation and System Failover creating data, network and system redundancy, minimizing disruptions in workflow and increasing operational efficiency.
Addressing the growing demands for efficient storage in business environments, the N5810 comes with essential business applications including support for VMware, Citrix and Microsoft Hyper-V; cross-platform support for MAC, Windows and Linux/UNIX users; Windows AP and LDAP for user authorization; bundled Acronis and Intel Security; and a complete backup solution including Snapshot using Btrfs for point-in-time backups, real-time remote replication and cloud backup to Elephant Drive, Dropbox, Amazon S3.
The N5810 runs on the intuitive, easy-to-use Thecus OS5 operating system. The re-tooled software includes VPN Server for secure remote access and Disk Clone and Wipe for convenient data management. Users will also be able to enjoy a comprehensive set of entertainment features facilitated by HDMI output and Kodi for multimedia playback and mobile access with the powerful Thecus mobile app, T-OnTheGo.
Running on the newly-designed, enhanced ThecusOS 7.0
The N5810 runs on the newly designed ThecusOS 7.0 offering an easy to use, intuitive user interface. Introducing several new features including Photo Station, Thecus App Center, User Profile, ThecusOS 7.0 delivers significant improvements in design, performance and user experience. (OS7.0 phase-in on new production from 2016/03/15.)
Uninterrupted Accessibility with Thecus System Failover
The Thecus System Failover feature is a fault tolerance process that creates mirrored data volumes. With at least two Thecus NAS available, data is copied by schedule and all changes are mirrored between the two NAS. While the second NAS is not visible, it communicates with the primary NAS. In the event of a power or network failure, a scheduled maintenance or other unforeseen circumstances, System Failover automatically redirects operations to the secondary Thecus NAS, which then acts as the primary NAS.
Secure Remote Access with Virtual Private Network (VPN)
A VPN Server allows users to remotely access a secure network. with VPNs, businesses will be able to utilize a cost-effective, scalable and secured network infrastructure for its client base.
Thecus RAID Protection
IT administrators can aggregate multiple RAID groups into a large storage pool to flexibly utilize their entire storage capacity as a whole, all the while improving data redundancy protected with data redundancy and allowing better data protection against multiple disks failure concurrently for large capacity environment. Thecus OS also allows for the creation of multiple volumes in the Storage Pool, improving customizability for various applications in typical business environments with diverse workgroups.
AES 256-bit RAID Volume Encryption
Thecus's AES 256-bit RAID volume encryption tool allows users to fully encrypt their entire RAID volume, defending essential data even in instances of theft.
Fault Tolerance up to RAID 10
When it comes to data management, Thecus NAS truly let you have it your way. Create multiple RAID volumes each supporting different RAID modes including RAID 0, 1, 5, 6, 10 and JBOD for your own balance of performance and data protection.
RAID Management
RAID level migration allows RAID volumes to be easily moved from one NAS to another. And RAID expansion allows you to increase the size of your RAID volume by the gradual replacement of older drives with larger ones.
Snapshot Your Data
With BTRFS support, Thecus NAS users can enjoy the simplicity of snapshot backups. Through BTRFS sub volumes, snapshots of data at various time points can be manually or automatically made and just as easily later restored to rollback files or folders to previous states.
Complete Data Backup Solution
Bundled with Free Acronis Backup Software
Thecus brings the best to the table with Acronis's advanced backup software. Back up all your data with One-click Protection or pick and choose only your most important files. Acronis sports a slick interface, user-friendly design and comprehensive features to keep your data safe.
Local Backup & Time Machine
PC users can utilize local backup devices while Mac users can automatically back up their entire Mac. Whenever a need arises, users can simply go back and recover files quickly and effortlessly
Real-Time Remote Replication (Rsync)
This innovative backup feature allows users to back up files instantly to their NAS, external hard drive or remote NAS. RTRR saves you time as it is able to back up data immediately and automatically.
The Cloud Done Your Way
Personal Cloud
They are a mobile society and their NAS solutions are keeping up! Incorporated into Thecus NAS is support for Thecus's T-OnTheGo smartphone app. Supporting both iOS and Android, this NAS management software enables users to access, copy, stream and edit any data between their NAS and mobile device. Your own personal cloud, available from anywhere with internet access.
Cloud Backup
The private and public clouds meet with Thecus' new DropBox, Amazon S3 and Elephant Drive cloud backup functionality! Guard your data with RAID at home and an additional level of protection in the Cloud. Just drag and drop files into the folder on your NAS and access them on any computer or mobile device with DropBox, Amazon S3 or Elephant Drive.
Remote Access via DDNS
Enable easy access to your NAS with Dynamic DNS. DDNS allows users to allocate and access their NAS files via the internet remotely. When the IP address is changed, the DDNS server will automatically adjust your address to make sure that remote access is always available. In short, DDNS provides convenient remote access to your Thecus NAS possible by utilizing domain names instead of IP digits.
Multimedia Data Center
Direct Media File Playback via HDMI Output
Transform your NAS into the ultimate multimedia hub! Thecus NAS integrated HDMI output allows you to connect your NAS directly to your TV for direct device management and multimedia playback.
Media Streaming to XBOX360/PS4 via Plex Media Server
With the Plex Media Server installed on your Thecus NAS, various devices on your network (such as your Xbox 360 and mobile devices) can connect to and stream your local and online media. The server can also automatically assemble iTunes, iPhoto and Aperture content. From your favorite videos to your mountains of music, Plex makes it easy to manage and enjoy all of your media on your Thecus NAS.
TV Streaming via Apple TV/Chromecast
Thecus NAS allow you to have your very own entertainment hub wherever you go. With TV streaming support and mobile apps, you can share all your favorite photos, music and videos.
7 Modes of Link Aggregation for Faster Transfers
Link aggregation can sustain multiple network connections and provide redundancy in case one of the links fails. Thecus NAS supports 7 modes which provide Load Balance, Failover, 802.3ad, Balance-XOR, Balance-TLB and Balance-ALB, Broadcast.
Bundled with Free Intel Security
Thecus' innovative hardware helps prevent failures. But sometimes you have to protect the NAS against itself. Adding an antivirus to the already comprehensive software bundle will provide the necessary software protection by scanning the files on your NAS and defending it against possible threats. Intel Security is the world's largest dedicated security technology company and shares Thecus' spirit of dedication and quality. By establishing a strong partnership with them, Thecus will allow users the benefit of Intel Security's powerful software on their NAS entirely for free.
Flexible Storage Allocation with iSCSI LUN and Thin-Provisioning
Get the most out of your storage space with the extreme speed of iSCSI and the efficiency of iSCSI thin provisioning. Connect through iSCSI for the fastest data transfer speeds available and make wasted disk space a thing of the past with thin provisioning's flexible storage functionality.
