Tilta Full Camera Cage Power Kit for Canon R6 V, Black

Introducing the Camera Cage for Canon R6 V Power Kit. The foundation of this kit is the Full Camera Cage which features multiple mounting options include 1/4"-20 and 3/8"-16 threads with locating points, as well as a NATO rail and cold shoe receiver, which allow users to attach various accessories microphones, lights, monitors, and more.

A detachable dual-directional Arca-Swiss bottom plate enables fast mounting and easy positional adjustments on DJI standard Arca-Swiss Receivers, perfect for gimbals and tripods, improving setup speed and overall efficiency.

Precision-engineered to avoid obstructing camera ports and functionality, the cage maintains an ergonomic form factor while maintaining a secure connection to the camera body via three points of contact. The modular design allows the full cage to be disassembled into a Half Cage when needed. This provides a few less mounting options, but reduces the total weight of the system, ideal for filmmakers using gimbals or moving quickly while shooting.

The cage supports comfortable vertical configurations by allowing users to attach handles via 1/4"-20 threads, perfect for two-handed builds that improve control when shooting in a portrait orientation. The bottom of the cage features a white label area for writing the camera body and the included cable clamp allows users to secure connected cables and ensures stable signal transmission for HDMI cables.

Included in this kit is the Adjustable ARCA Receiver and Mini PD Battery Plate which provides a unique and lightweight option to mount a battery plate without traditional baseplates and 15mm rods. The Receiver can extend to move the battery plate closer or farther from the camera body while a swivel hinge also allows users to adjust the angle of their battery relative to their camera body.

The battery plate allows users to extend the operating time of their camera and accessories via larger capacity V-Mount batteries and features multiple power output options such as a 60W PD USB-C, a P-Tap, and a 2-Pin Lemo connection.

Unique to this plate are the integrated strap slots which allows users to connect an included security strap to their V-Mount battery which limits the possibility of accidental disconnection. The battery plate also features 1/4"-20 and M4 threads on the top, allowing the unit to be easily mounted in unique ways via additional adapters or articulating arms. P-Tap/2 Pin Lemo Ports provide 20V/3A.

Full Mounting Options, Creative Freedom
Equipped with multiple 1/4"-20 and 3/8"-16 threads with locating points, cold shoe mounts, and NATO rails.

Full Cage
Provides complete protection and excellent grip ergonomics. Offers more mounting positions for accessories.

Bi-Directional Arca-Swiss, Quick Camera Mounting
Bottom features a removable Arca-Swiss quick release plate with 1/4"-20 threads and locating pins. Mount to a gimbal or tripod quickly. Ideal for users who frequently switch between shooting setups and styles frequently. Compatible natively with DJI and standard Arca-Swiss accessories on the market.

Three Points Of Contact Zero Play, Solid As One
Effectively reduces camera body shifting and loosening in cage.

Unobstructed Access
Precise design keeps all original camera controls fully accessible. Professional expansion with the original shooting experience.

Dual-Grip, Enhanced Vertical Shooting
A two-handed grip improves ergonomics and stability, making vertical shooting truly efficient and practical.

Reserved Label Area For Quick Reference
Features a dedicated area for labeling the camera body serial number. Verify information instantly without removing the cage.

- Mini PD V Mount Battery Plate -
Introducing the Tilta Mini PD V Mount Battery Plate. This battery plate allows users to extend the operating time of their camera and accessories via larger capacity V-Mount batteries. This plate features multiple power output options such as a 60W PD USB-C, a P-Tap, and a 2-Pin Lemo connection.

Unique to this plate are the integrated strap slots which allows users to connect an included security strap to their V-Mount battery. This limits the possibility of accidental disconnection, which is especially useful when rigging the camera to support systems such as car mounts.

Included with the battery plate is a dual rod adapter which makes the unit easy to integrate into systems that utilize 15mm LWS rods. The battery plate also features 1/4"-20 and M4 threads on the top, allowing the unit to be easily mounted in unique ways via additional adapters or articulating arms. P-Tap/2 Pin Lemo Ports provide 20V/3A.

Versatile Power Solution For Your Camera
Extend your camera and accessories operating time with options of USB-C, P-Tap, and 2-pin LEMO.

Includes Straps To Secure The Battery
It comes with two strap slots, allowing the installation of security straps without affecting the battery installation or access to ports.

Additional Mounting Points For Convenient Installation
The battery plate features 1/4"-20 and M4 threads on the top, allowing connection to various adapters.

Works With 15mm LWS Rod Mount
It can be mounted to a dual rod adapter, allowing installation on rods.

Features
• Extended Power for Cameras and Accessories via Higher Capacity V-Mount Batteries
• Power Outputs Include P-Tap, USB-C and 2-Pin Lemo Connections
• Security Strap Features a Unique Way to Further Secure V-Mount Batteries
• Mounting Points on the Top of the Plate Improve Specialty Rigging Possibilities
• Rod Adapter Compatible with Dual 15mm LWS Rods

- 100W Right Angle USB-C Power Cable (35cm) -
Introducing 100W Right Angle USB-C Power Cable (35cm), a compact USB-C power cable designed for high-power camera and mobile rigs. Supporting up to 100W USB-C Power Delivery, the right-angle connector reduces port strain and keeps cable routing clean in tight setups. The 35cm length is ideal for cages, battery plates, and compact power builds.

Features
• 100W USB-C PD for powering cameras and accessories
• Right-Angle USB-C Connector minimizes strain and saves space
• 35cm Short Cable keeps rigs clean and clutter-free
• Durable, Flexible Design for on-set use

- Adjustable ARCA Receiver -
The Adjustable ARCA Receiver is a unique and lightweight option to mount a battery plate to a camera without traditional baseplates and 15mm rods. Once attached via a DJI standard ARCA Quick Release Plate or compatible camera cage, the Receiver can extend to move the battery plate closer or farther from the camera body. A swivel hinge also allows users to adjust the angle of their battery relative to their camera body.

V-Mount Connection
With Power Output Ports for Accessories.

Fast Transitions
Quick release and attachment with Arca-Swiss compatibility.

Flexible Form, Compact Design
180 Degree foldable hinge for easy storage.

Balanced Center of Gravity
Stable shooting for long sessions.

Fully Compatible Connectivity
Perfect for various devices and systems.

Precise Balance Control
Fine-tune your camera's balance with a 37mm adjustable sliding plate, featuring a secure locking lever for stable and precise positioning.

Upgrade Your Tilta Battery Plate
Pair it with the compatible models: Mini PD V-Mount Battery Plate, Mini V-Mount Battery Plate, Pocket V-Mount Battery Plate.

Compatible With Mainstream Mirrorless and DSLR Cameras
Sony/Panasonic/Leica/Canon/Nikon/Fujifilm (With Tilta Camera Cage or Standard Arca Plate).

Lightweight Mounting
Does not require a Baseplate or 15mm Rods - Easy installation. A new option for compact shooting or quick transitions.
