Tilta Full Camera Cage Pro Kit for Canon R6 V, Black

Introducing the Camera Cage for Canon R6 V Pro Kit. The foundation of this kit is the Full Camera Cage which features multiple mounting options include 1/4"-20 and 3/8"-16 threads with locating points, as well as a NATO rail and cold shoe receiver, which allow users to attach various accessories microphones, lights, monitors, and more.

A detachable dual-directional Arca-Swiss bottom plate enables fast mounting and easy positional adjustments on DJI standard Arca-Swiss Receivers, perfect for gimbals and tripods, improving setup speed and overall efficiency.

Precision-engineered to avoid obstructing camera ports and functionality, the cage maintains an ergonomic form factor while maintaining a secure connection to the camera body via three points of contact. The modular design allows the full cage to be disassembled into a Half Cage when needed. This provides a few less mounting options, but reduces the total weight of the system, ideal for filmmakers using gimbals or moving quickly while shooting.

The cage supports comfortable vertical configurations by allowing users to attach handles via 1/4"-20 threads, perfect for two-handed builds that improve control when shooting in a portrait orientation. The bottom of the cage features a white label area for writing the camera body and the included cable clamp allows users to secure connected cables and ensures stable signal transmission for HDMI cables.

Included in this kit is the Xeno Top Handle, which connects to the Top Plate via a NATO Clamp and improves handling via an elegant design with increased clearance. This handle features multiple mounting options for additional accessories including 1/4"-20 threads and a Cold Shoe Receiver, perfect for mounting an external monitor.

The Arca Height Adjustable 15mm LWS Baseplate allows users to adjust the height of their camera in relation to their rods which helps maintain the LWS 85mm standard between rods and the center of their sensor, in order to ensure compatibility with a range of various accessories and camera bodies.

Also included is the Xeno Side Handle which utilizes a NATO connection to mount to the left side of the cage and features an adjustable height of 40mm. Non-slip silicone provides a textured grip that improves stability and mounting points such as a Cold Shoe Receiver and a 1/4"-20 thread with locating points accommodate additional accessories.

Full Mounting Options, Creative Freedom
Equipped with multiple 1/4"-20 and 3/8"-16 threads with locating points, cold shoe mounts, and NATO rails.

Full Cage
Provides complete protection and excellent grip ergonomics. Offers more mounting positions for accessories.

Bi-Directional Arca-Swiss, Quick Camera Mounting
Bottom features a removable Arca-Swiss quick release plate with 1/4"-20 threads and locating pins. Mount to a gimbal or tripod quickly. Ideal for users who frequently switch between shooting setups and styles frequently. Compatible natively with DJI and standard Arca-Swiss accessories on the market.

Three Points Of Contact Zero Play, Solid As One
Effectively reduces camera body shifting and loosening in cage.

Unobstructed Access
Precise design keeps all original camera controls fully accessible. Professional expansion with the original shooting experience.

Dual-Grip, Enhanced Vertical Shooting
A two-handed grip improves ergonomics and stability, making vertical shooting truly efficient and practical.

Reserved Label Area For Quick Reference
Features a dedicated area for labeling the camera body serial number. Verify information instantly without removing the cage.

- Xeno Top Handle (NATO) -
The Xeno Top Handle features several different mounting options allowing it to be mounted to a variety of camera cages and systems. The handle itself features a large silicone padded grip which makes operating or handling more comfortable and secure. The handle features numerous mounting points for additional accessories such as 1/4"-20 and 3/8"-16 threads with locating points. The handle also features a Cold Shoe Receiver with a Safety Release Pin as well as an Arri Standard Locating Thread.

Features
• Multiple Mount Options Compatible for Variety of Rigs
• Mount Accessories via Cold Shoe, 1/4"-20 and 3/8"-16 Threads with Locating Points
• Silicone Grip Creates a More Secure Handheld Operating Experience
• Extended Grip Provides Comfortable Handling via Updated Design with Improved Clearance
• Durable Aluminum Alloy and Silicone Construction

- Arca Height Adjustable 15mm LWS Baseplate -
Introducing the Arca Height Adjustable 15mm LWS Baseplate. This 15mm Baseplate allows users to utilize 15mm rods in order to mount various accessories such as matte boxes or follow focus systems. Unique to this unit is the adjustable height design which allows users to adjust the height of their camera in relation to their rods.

This means that users can maintain the LWS 85mm standard between their rods and the center of their sensor in order to ensure compatibility with a range of various accessories and camera bodies. The distance from the center of the rods to the Arca receiver ranges from 18mm to 38mm and is compatible with DJI standard Arca plates.

The bottom of the baseplate is compatible with Tilta Standard Dovetails and also features 1/4"-20 threads for mounting to tripods and other support systems. We recommend using this baseplate with camera systems that are under 10lbs.

Designed To Accommodate Different Heights
The adjustable height design is compatible with most mirrorless camera bases or full/half cages, adhering to the LWS 85mm standard, and is perfect for professional users.

Flexible Range
The distance from the center of the rods to the Arca receiver ranges from 18mm to 38mm.

Arca Quick Release
Compatible with DJI standard Arca plate, Tilta standard dovetail plate, and 15mm rods.

Quick Lock Design
Easy to ensure the security of your equipment.

Features
• Height Adjustable Design Ensures Perfect LWS Alignment with Various Accessories
• Arca Receiver Compatible with DJI Standard ARCA Plates and Many Tilta Camera Cages
• 15mm Rod Support Accommodates Rod Based Accessories Like Matte Boxes and Follow Focus Systems
• Dovetail Support Slides and Locks Securely onto Tilta Standard Dovetails
• Safety Pin Provides Additional Security for Your Camera System

-15mm Aluminum Rod -
These rods are compatible with 15mm studio and 15mm LWS baseplates and provide a way to mount accessories to your camera rig.

- Xeno Side Handle (NATO) -
Introducing the Tilta Xeno Side Handle, a new side handle inspired by the sleek and bio-mechanical design of the Xenomorph. This side handle seamlessly blends strong aesthetics with ergonomic functionality, providing a comfortable and secure grip for users to operate their camera rig from.

Designed for versatility, the Xeno Side Handle can be mounted as both a left and right side handle. With an adjustable height of 40mm, users can tailor the handle to their preferred position, ensuring improved comfort when shooting handheld for any amount of time.

The handle features non-slip silicone, which provides a textured grip that improves stability for a confident hold and features mounting points such as a Cold Shoe Receiver and a 1/4"-20 thread with locating points for additional accessories.

The built-in Allen Key ensures assembly or any adjustments are convenient for the handle or any other accessories, which is perfect for filmmakers who prioritize efficiency and flexibility. Upgrade your camera rig with the Tilta Xeno Side Handle, a perfect blend of futuristic design and practical functionality!

• New Design: Inspired by the Xenomorph, it combines biometric design with a comfortable grip
• Improved Flexibility: Compatible with both left and right sides, adjustable height of 40mm
• Comfortable Grip: Non-slip silicone with textured grip for improved friction and stability
• Integrated Tools To Prevent Loss: Magnetic attachment; Built-in Allen Key; Easy to disassemble and assemble

Features
• Multi-Functional Design Allows the Handle to Be Used as Both a Left or Right Side Handle
• Adjustable Height Allows the Handle to be Raised or Lowered 40mm Relative to the Mounting Point
• Non Slip Silicone Provides a Textured Grip for Increased Stability and Security
• Integrated Allen Key for Convenient Assembly for the Handle or Other Accessories
