Tonelux MP5A Discrete Microphone Preamplifier with Tilt Control

When audio quality and precision are paramount, the MP5A Discrete Microphone Preamplifier with Tilt Control emerges as an essential tool for professional recording environments. This high-end preamp boasts a discrete design, ensuring a pure and uncolored amplification of your microphone's signal. The front panel features a convenient Direct Input for seamless connection of instruments, while the Mic In is meticulously transformer-coupled both in and out, providing exceptional sonic integrity.

The MP5A is equipped with a 20 dB pad switch that attentively affects both the Mic and Direct inputs, allowing for the handling of high-level sources without distortion. The inclusion of a 48V Phantom Power switch enables the use of condenser microphones, expanding your recording capabilities. Additionally, the Phase or Polarity switch offers the flexibility to correct phase issues or to creatively manipulate your audio signal for the desired effect.

Control is at your fingertips with the dual-knob configuration: the larger, silver knob is dedicated to setting the mic pre gain, while the smaller, black knob, designed as a fader control, adjusts the output level without the risk of accidental gain adjustments. The 8-segment LED VU meter is a precise visual aid that follows the balanced output of the preamp, with an adjustable level range from off to +28. The Peak LED, calibrated at +14VU or +18dBu, captures and displays transient peaks with accuracy.

Internally, a jumper allows you to select whether the VU Meter reflects the Mic Pre Main Output or the Mic Pre Gain Stage signal, providing the engineer with the option to monitor the true mic pre gain or the post-fader output level. The Combo XLR/Direct input caters to high-impedance instruments, ensuring versatility across various recording scenarios.

The innovative Tilt tone control is a standout feature, offering a unique EQ adjustment that can simultaneously boost highs and cut lows, or vice versa, up to 6dB. This control works in conjunction with both the Mic and Direct inputs and includes a Tilt EQ In switch for hard wire bypass functionality.

Connectivity is further enhanced by the multed Front panel XLR, which is also linked to the rear panel XLR and the D-Sub Input, ensuring comprehensive integration with your existing setup. The Insert Return input on the V4 is designed for live recording situations without a splitter, providing a high-impedance bridging option that minimizes microphone loading.

The MP5A also includes a Pre-Fade Listen (PFL) feature, allowing you to preview the signal directly from the mic pre output, whether you're routing to an external amplifier or to the mixer/master section. This discrete microphone preamplifier with Tilt Control is not just a piece of equipment; it's an investment in the fidelity and control of your audio recordings.
