TRENDnet 10/100/1000Mbps PCI Express Adapter Specifications

  • Standards

    IEEE 802.3 10Base-T Ethernet
    IEEE 802.3u 100Base-TX Fast Ethernet
    IEEE 802.3ab 1000Base-T Gigabit
    IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p
    Ethernet: UTP Cat. 3, 4, 5, EIA/TIA-568 100-ohm STP
    Fast Ethernet: UTP Cat. 5, EIA/TIA-568 100-ohm STP
    Gigabit: UTP Cat. 5, 5E, 6 EIA/TIA-568 100-ohm STP

  • Protocol

    SNMP v1

  • Interface

    Port PCI Express / Gigabit Ethernet

  • Power Consumption

    2.3 watts (max)

  • Diagnostic LED

    Link, activity

  • Supported OS

    Windows 2000/2000 Server/XP(32/64-bit)/2003 Server/Vista (32/64-bit)/Win 7 (32/64-bit)
    Novel NetWare Server 5.x / 6.x
    Linux Kernel 2.4.x / 2.6.x

  • Data Rate

    Ethernet: 10Mbps/20Mbps (half/full-duplex)
    Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
    Gigabit: 2000Mbps (full-duplex)

  • Operating Temperature

    0deg.C - 45deg.C (32deg.F - 113deg.F)

  • Storage Temperature

    -10deg.C - 70deg.C (14deg.F - 158deg.F)

  • Humidity

    5%-95% (non-condensing)

  • Dimensions

    109x83mm (4.29x3.26")

  • Weight

    80g (2.82oz)

  • UPC Code

    710931610109

About TRENDnet 10/100/1000Mbps PCI Express Adapter

The TRENDnet 10/100/1000Mbps PCI Express Adapter is a high performance network adapter that supports advanced management and power savings functionality for system administrators. Full-Duplex technology generates data rates of up to 2Gbps over a motherboard's high-speed PCI Express Bus architecture. Jumbo Frame support further optimizes throughput performance. Supports SNMP v1, Pre-Boot Execution Environment (PXE) 2.1, Remote Program Load (RPL) and Wake-on-LAN (WOL). Optimize network performance with VLAN tagging and Layer 2 Priority Tagging. Optimizes power consumption with advanced Configuration Power Management Interface 2.0 (ACPI) technology.

TRENDnet 10/100/1000Mbps PCI Express Adapter Features

  • 1 x 10/100/1000Mbps Auto-MDIX WAN port
  • PCI Express 1.0a compliant
  • Incorporates Advanced Configuration Power Management Interface (ACPI) 2.0
  • Wake-On-LAN (WOL)
  • TCP segmentation / large send offload
  • IEEE 802.1Q VLAN tagging and IEEE 802.1p Layer 2 priority tagging
  • IEEE 802.3x full-duplex Flow Control
  • Microsoft NDIS5 (IP, TCP, UDP) checksum off-load
  • SNMP v1 supported
  • Preboot eXecution Environment (PXE) 2.1 and Remote Program Load (RPL)
  • Jumbo Frames up to 7K
  • Intuitive cable diagnostic utility

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • PCI Express 1.0a compliant
  • Wake-On-LAN (WOL)
  • TCP segmentation / large send offload
  • IEEE 802.3x full-duplex Flow Control
  • SNMP v1 supported
  • Preboot eXecution Environment (PXE) 2.1 & Remote Program Load (RPL)

What's in the box:

  • TRENDnet 10/100/1000Mbps PCI Express Adapter
  • Multi-Language Quick Installation Guide
  • CD-ROM(Drivers & User's Guide)
  • TRENDnet 3 Year Limited Warranty
