TOA Electronics AV-60S-AM Single-Channel Class D Plenum Rated Micro Amplifier, 60W at 4 Ohms, Energy Star 3.0

SKU: TOAV60SAM MFR: AV-60S-AM
Earn VIP Reward Points

Key Features

  • Experience powerful audio with this 60W TOA Electronics power amplifier at 4 Ohms.
  • This Class D micro amplifier is Energy Star 3.0 certified, saving you on power consumption.
  • Enjoy versatile input options with Line 1, Line 2, and Line 3 inputs on this amplifier.
  • Easily adjust bass and treble with convenient tone controls for optimal sound quality.
  • Ensure safe operation with built-in thermal and over current protection circuits.
  • Perfect for installations, this plenum-rated amplifier meets UL2043 standards.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$39.99

2 Year

$69.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

TOA Electronics AV-60S-AM Specifications

  • Power Supply

    AC100V-240V, 50Hz/60Hz; AC inlet on rear panel

  • Power consumption

    Less than 1W: power save mode; Less than 10W at 70V
    Less than 7W at 4 Ohms: idle; Less than 85W at 70V
    Less than 110W at 4 Ohms: rated output

  • Output

    60W at 4 Ohms, 60W at 70V
    Speaker output, removable terminal block (2P)

  • Power Amplifier Type

    Class D

  • Standard

    UL2043 2008 Version, cULus Standard UL60065 7th Edition & CSA C22.2 NO.1-98, EnargyStar Version 3.0 Audio/Video specification and FCC part15 class B

  • Protection

    Thermal protection
    Over current protection

  • Input

    Line 1: -10/-20dB (selectable), 10K Ohms, transformer balanced, removable terminal block (3P)x2
    Line 2: -10/-20dB (selectable), 10K Ohms, unbalanced, 3.5mm stereo jack
    Line 3: -10/-20dB (selectable), 10K Ohms, unbalanced, RCA

  • Indication

    Power LED (green)
    Signal LED (green)
    Peak LED (red)
    Protect LED (yellow)

  • Ventilation

    Normal air ventilation Fin or Mesh to apply for UL2043

  • Frequency Response

    4 Ohms mode: 20Hz to 20KHz +/-3dB
    70V mode: 60Hz to 20KHz +/-3dB (Line1 input with transformer: 100Hz to 20KHz)

  • THD+N

    Less than 0.15%

  • Tone Control

    Bass: +/-10dB at 100Hz, Treble: +/-10dB at 10KHz

  • Controls

    Master volume control, Remote volume control, Base/Treble tone control, 70V/4ohm switch, Input sensitivity switch (Line1, Line2, Line3)

  • Temperature Range (Operation)

    -10 to 40 deg. C / 14 to 104 deg. F

  • Case

    Black metal case

  • Dimensions (W x H x D)

    5.90 x 1.73 x 6.14" / 14.99 x 4.39 x 15.60cm

  • Weight

    2.5lbs / 1.13kg

About TOA Electronics AV-60S-AM

An indispensable asset for high-quality audio in professional settings, the AV-60S-AM Single-Channel Class D Plenum Rated Micro Amplifier delivers a robust 60W of power at 4 Ohms, ensuring clear and powerful sound reinforcement for speech and general announcements. Designed with meticulous attention to detail, this compact yet potent amplifier integrates a highly efficient switching power supply circuit, contributing to its Energy Star 3.0 certification - a testament to its energy efficiency and eco-friendly operation.

Crafted for versatility and reliability, the AV-60S-AM is PLENUM rated, having been rigorously tested to UL 2043 standards, which allows for safe installation in air handling spaces without the need for an external AC adapter. This feature streamlines the setup process and ensures compliance with safety regulations, making it an ideal choice for professional environments.

The unit's Class D amplification technology not only provides high-fidelity audio performance but also operates with reduced heat generation and minimal power loss, further enhancing its suitability for continuous use in demanding settings such as boardrooms, conference rooms, and AV presentation rooms.

With its sleek design and durable construction, the AV-60S-AM is engineered to seamlessly integrate into any professional audio setup, delivering consistent, high-quality sound that meets the needs of today's dynamic audio environments. Whether it's for reinforcing presentations, facilitating communication, or amplifying announcements, this micro amplifier stands as a reliable cornerstone for your audio system.

TOA Electronics AV-60S-AM Features

  • Micro Class D amplifier for use in meeting/board rooms & signage applications
  • UL 2043-rated for plenum installation
  • Energy Star certified including Auto Off/Standby
  • Small in size (approx. 6" x 6" x 1.75") allows convenient & flexible placement
  • L/R Line inputs via: removable Transformer-Balanced Terminal Block, 1/8" TRS mini-jack and RCA connections
  • Bass & Treble Controls
  • Input signal present (-20dB) and Peak LED indicators
  • Clip Limiter prevents distortion due to overload
  • Remote Volume Control port for use with 10k Ohm pot
  • Volume Control Attenuators

Warranty Information

This product has a limited warranty of 60 months.

Product Documents

User Manual

Key Features

  • Experience powerful audio with this 60W TOA Electronics power amplifier at 4 Ohms.
  • This Class D micro amplifier is Energy Star 3.0 certified, saving you on power consumption.
  • Enjoy versatile input options with Line 1, Line 2, and Line 3 inputs on this amplifier.
  • Easily adjust bass and treble with convenient tone controls for optimal sound quality.
  • Ensure safe operation with built-in thermal and over current protection circuits.
  • Perfect for installations, this plenum-rated amplifier meets UL2043 standards.

What's in the box:

  • TOA Electronics AV-60S-AM Single-Channel Class D Plenum Rated Micro Amplifier
  • TOA Electronics 5 Year Limited Warranty
