TOA Electronics BG-2035 CU 35W 5 Channel Mixer Amplifier, 50Hz-20kHz Frequency Response, Euroblock Connections, 2 Channel Broadcast Capability, RCA Pin Jacks

SKU: TOBG2035CU MFR: BG2035CU
Earn VIP Reward Points

Key Features

  • Experience clear audio with this 35W mixer amplifier, perfect for small venues.
  • Control your sound precisely with the integrated EQ control for balanced output.
  • Connect various devices using multiple input channels, including mics and line inputs.
  • Utilize phantom power for condenser microphones, enhancing your audio recording setup.
  • Easily manage audio levels with intuitive gain controls for each input channel.
  • Enjoy versatile connectivity options with Euroblock and RCA jacks on this amplifier.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$39.99

2 Year

$69.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?Robert E : Use this product on a lease and has done well for us.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

TOA Electronics BG-2035 CU Specifications

  • Power Source

    120V AC, 60Hz

  • Rated Output

    35W

  • Power Consumption

    94W (Rated output), 50W (based on cULus standards)

  • Frequency Response

    50Hz-20kHz

  • Total Harmonic Distortion

    0.5% or less, at 1kHz, rated output

  • Input

    Mic: -60dB, 600 Ohm, electronically balanced, removal terminal block
    Line 1: -10dB / TEL: -20dB, Line 1/TEL selectable, 10kOhm, electronically balanced, removal terminal block
    Line 2, 3: -10dB, 10 kOhm, unbalanced, removal terminal block and RCA jacks module

  • Output

    Speaker: 4Ohm, 25V (18 Ohm), 70V (140 Ohm), balanced, removal terminal block
    MOH: 0dB, 600 Ohm, balanced, removal terminal block
    Line: 0dB, 600 Ohm, unbalanced, removal terminal block

  • Output Regulation

    2dB or less, no load to full load (1kHz)

  • Phantom Power

    On/off switch for mic, +24 V DC

  • S/N Ratio

    Mic: 60dB or more, Line 1/TEL, Line 2, 3, Module: 75dB or more (Band pass: 20Hz-20kHz, Tone controls: centered

  • Muting

    Manual mute / automatic mute

  • Tone control

    Bass: +/-10dB at 100Hz, Treble: +/- 10dB at 10kHz

  • Control

    Mic gain control, Line 1/TEL gain control, Line 2 gain control. Line 3 gain control, Module gain control, Bass tone control, Treble tone control, MOH out gain control, Mute control (Manual mute), Remote volume control, Mute sense control, Line 1/TEL selector switch, Phantom power switch (Mic), Auto mute switch (Mic, Line 1/TEL, module), Mute receiver switch (Mic, Line 1/TEL, Line 2, 3, module), MOH assign switch (Mic, Line 1/TEL, Line 2, 3, module), Power on/off switch

  • Indicators

    Power LED, Signal Level LED, Peak LED

  • Operating Temperature

    0 deg. C to +40 deg. C (32 deg. F to 104 deg. F)

  • Operating Humidity

    35% to 80% RH (no condensing)

  • Finish

    Panel: ABS resin, Black
    case: Steel plate, black paint

  • Dimensions (W x H x D)

    10.39 x 3.71 x 10.52" / 26.39 x 9.42 x 26.72cm

  • Weight

    11.68lbs / 5.29kg

About TOA Electronics BG-2035 CU

The TOA Electronics BG-2035 CU 35W 5 Channel Mixer Amplifier is a versatile and high-performance audio equipment, expertly engineered to serve as the primary component in any commercial audio system. Whether it's for background music (BGM), foreground music, or paging applications, this mixer amplifier delivers superior sound quality and reliable performance.

Boasting a robust power rating of 35 watts, the BG-2035 CU is equipped with five distinct channels, offering flexibility and control over your audio output. Its unique 2-zone operation feature allows for separate programming in two discrete zones, making it an ideal choice for multi-room audio setups.

The front panel of this mixer amplifier is designed with user-friendly controls, including individual level dials for each channel, ensuring precise and effortless sound adjustments. On the rear panel, you'll find removable euroblock connectors and DIP switches, simplifying the programming process and offering a seamless integration into your existing audio system.

Constructed with a rugged chassis, the BG-2035 CU promises durability and longevity. For added convenience, it can be easily rack-mounted using the optional MB-1000 rack mount brackets.

Incorporating the TOA Electronics BG-2035 CU 35W 5 Channel Mixer Amplifier into your commercial audio system ensures a superior sound experience, whether it's for music or paging applications. This mixer amplifier is not just a product, but a testament to TOA Electronics' commitment to quality and innovation in the field of audio technology.

TOA Electronics BG-2035 CU Features

  • Compact five channel Mixer-Amplifier for paging, background/foreground music distribution and music/messaging-on-hold
  • All inputs/outputs with removable terminal blocks allow quick and easy installation
  • Any of five inputs assignable to MOH/ZONE 2 output
  • RCA pin jacks for LINES 2 & 3
  • Phantom Power (+ 24V DC) incorporated for MIC input
  • Module slot accepts optional 900 Series plug-in modules for custom system configurations
  • Rear panel-mounted DIP switches allow easy configuring of settings
  • Provides auto/manual mute function with adjustable muting sensitivity
  • Incorporates Remote volume control connection
  • 2-channel broadcast capability together with zone 2 expansion capability in conjunction with BA-200 Series
  • Tamper-proof, front-panel bass and treble controls are recessed to protect their settings
  • Thermal protection circuitry prevents potential damage from excessive heat build-up
  • AC Mains Circuit Breaker
  • Supplied accessory security knobs for volume controls prevent unauthorized volume setting changes
  • UL/cUL Listed

Warranty Information

This product has a limited warranty of 60 months.

Product Documents

User Manual

Key Features

  • Experience clear audio with this 35W mixer amplifier, perfect for small venues.
  • Control your sound precisely with the integrated EQ control for balanced output.
  • Connect various devices using multiple input channels, including mics and line inputs.
  • Utilize phantom power for condenser microphones, enhancing your audio recording setup.
  • Easily manage audio levels with intuitive gain controls for each input channel.
  • Enjoy versatile connectivity options with Euroblock and RCA jacks on this amplifier.

What's in the box:

  • TOA Electronics BG-2035 CU 35W 5 Channel Mixer Amplifier
  • Accessory Security Knobs
  • TOA Electronics 5 Year Limited Warranty
