19% Off

TOA Electronics 16-Channel UHF Wireless System, Includes WT-5810 Tuner, WM-5325 Rechargeable Body-Pack Transmitter and WH-4000H Headset Microphone, Frequency H01: 576 to 606MHz

SKU: TOWS55HH01US MFR: WS5325HH01US
Earn VIP Reward Points

Key Features

  • Experience crystal-clear audio with this 16-channel UHF wireless microphone system, perfect for presentations.
  • Enjoy freedom of movement with the WM-5325 rechargeable body-pack transmitter and WH-4000H headset microphone.
  • The included WT-5810 tuner ensures a stable wireless connection with a frequency range of 576 to 606MHz.
  • Benefit from a durable headset microphone featuring a unidirectional design for focused sound capture & quality.
  • Achieve optimal sound with a wide audio frequency response of 100 Hz - 15 kHz for natural voice reproduction.
  • This wireless system is ideal for presenters, offering reliable connectivity and exceptional sound performance.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

5 Year

$269.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

TOA Electronics WT-5810/WM-5325/WH-4000H Specifications

Tuner
  • Receiving Frequency

    H01: 576 to 606MHz

  • Channel Selectable

    16 channels

  • Receiving System

    Double super-heterodyne

  • Diversity System

    Space diversity

  • Mixing Output

    MIC: -60 dB, 600Ohms, balanced, XLR-3-32 type connector
    LINE: -20 dB, 600Ohms, unbalanced, phone jack

  • Mixing Input

    -20 dB, 10 kOhms, unbalanced, phone jack

  • Antenna

    Whip antenna

  • Receiving Sensitivity

    90 dB or more, Signal to Noise ratio (20 dBMuV input, 40 kHz deviation)

  • Squelch Sensitivity

    16 - 40 dBMuV variable

  • Squelch System

    Using together of noise SQ, carrier SQ and tone SQ

  • Tone Frequency

    32.768 kHz

  • Indicator

    ANT A/B, Audio (peak), Battery alarm, Channel number

  • Channel Check

    Usable frequencies scanning

  • Signal to Noise Ratio

    104 dB or more (A-weight, unbalanced output)

  • Harmonic Distortion

    1 % or less (typical)

  • Frequency Response

    100 Hz - 15 kHz, +/-3 dB

  • Power Source

    AC mains (supplied AC adapter must be used)

  • Power Consumption

    130 mA (12 V DC)

  • Operating Temperature

    -10 to 50 deg. C (14 to 122 deg. F)

  • Operating Humidity

    30 % to 85 %RH

  • Finish

    Resin, black

Transmitter

Jump to...
  • Modulation

    Frequency modulation

  • Frequency Range

    H01: 576 to 606MHz

  • Channel Selectable

    64 channels (the number of channels may differ from country to country)

  • RF Carrier Power

    Less than 50 mW (Factory preset 10 mW ERP)

  • Tone Frequency

    32.768 kHz

  • Oscillator

    PLL synthesized

  • Maximum Input Level

    -14 dB to -29 dB (Audio level control: Min. to Max.)

  • Maximum Deviation

    +/-40 kHz

  • Audio Frequency Response

    100 Hz - 15 kHz

  • Battery

    WB-2000 rechargeable battery (option) or AA alkaline dry cell battery

  • Battery Life

    Approx. 13 h (when the WB-2000 rechargeable battery is used)
    Approx. 10 h (when the alkaline battery is used)

  • Indicator

    Power/Battery lamps

  • Antenna

    Built-in type

  • Connector

    Dia. 3.5mm (Dia. 0.14") mini plug

  • Operating Temperature

    -10 to 50 deg. C (14 to 122 deg. F)(except battery)

  • Operating Humidity

    30 % to 85 %RH (no condensation)

  • Finish

    Resin, coating

Microphone

Jump to...
  • Microphone Type

    Electret condenser type

  • Directivity

    Unidirectional

  • Sensitivity

    -66 dB +/-3 dB (0 dB = 1 V/0.1 Pa, 1 kHz)

  • Maximum Input Level

    120 dB SPL

  • Cord Length

    1.3m (4.27')

  • Terminal

    Dia. 3.5mm monaural plug

  • Finish

    Frame: Stainless, black (silicon rubber)
    Gooseneck: Black (shrink tube)

General

Jump to...
  • Dimensions (WxHxD)

    Tuner: 206 x 40.6 x 152.7mm (8.11 x 1.60 x 6.01") (excluding antenna)
    Transmitter: 62 x 102.5 x 23mm (2.44 x 4.04 x 0.91")

  • Weight

    Tuner: 590g (20.81 oz)
    Transmitter: 90g (3.17 oz) (with battery)
    Microphone: 50g (1.76 oz) (cable included)

About TOA Electronics WT-5810/WM-5325/WH-4000H

If you're seeking superior sound quality and reliable performance, consider the 16-Channel UHF Wireless System. This comprehensive audio solution includes the WT-5810 Tuner, WM-5325 Rechargeable Body-Pack Transmitter, and the WH-4000H Headset Microphone, all operating within the Frequency H01: 576 to 606MHz range.

The WT-5810 Space Diversity Tuner is engineered for exceptional performance, stability, and reliability. It features a PLL-synthesized oscillator, offering a broad selection of channels to avoid interference. The tuner employs true diversity and space diversity methods, significantly reducing noise potential during antenna changeovers. Its two-line LCD display facilitates quick meter reading, while the TOA diversity system eradicates dead spots and ensures stable signal reception. The tuner also boasts a squelch function for improved noise reduction and a compander function to minimize ambient noise pickup. Its Channel Check function simplifies channel setting operations on multiple wireless microphones used simultaneously, and a low battery indicator keeps you informed of the microphone battery voltage status.

The WM-5325 Rechargeable UHF Body-pack Transmitter, designed for speech reinforcement applications, offers 64 different operating frequencies thanks to its PLL-synthesizer system. Its high output power guarantees stable radio signal transmission, ensuring your voice is heard clearly and consistently.

Finally, the WH-4000H Headset Microphone, featuring a cardioid pick-up pattern, offers a lightweight design for comfortable wear. The adjustable band ensures a secure fit, making it an ideal choice for extended use.

In summary, this 16-Channel UHF Wireless System offers a comprehensive, high-quality audio solution, perfect for professionals seeking reliable and superior sound transmission.

TOA Electronics WT-5810/WM-5325/WH-4000H Features

  • WT-5810 Tuner:
  • Compact design for shelf-mount applications
  • Scanner function
  • Transmitter battery status display
  • 16 selectable channels
  • TOA Space Diversity reception
  • Front panel: Built-in antennas (2), Output volume control, Power switch, Channel display and adjust, Squelch adjust and bypass, LEDs: Antenna A/B, Battery, Peak and Power
  • Rear panel: Outputs: XLR-M (mic) and 1/4" phone jack (line), Mix-In 1/4" jack (line)
  • WM-5325 Transmitter:
  • Lightweight bodypack
  • 64 selectable channels
  • Single AA battery (ten hours)
  • Compatible with rechargeable TOA AA Battery (WB-2000-2) and charging stations (BC-5000-2/6/12)
  • Screw-on 3.5mm mini-plug jack accepts optional mics
  • Screw-on 3.5mm mini-plug connector
  • Adjustable mic sensitivity
  • Built-in concealed antenna
  • Low battery indication
  • Neck strap included
  • Compatible with receiver models: WT-5800, WT-5805, WT-5810, WT-4820
  • WH-4000H Headset Microphone:
  • Unidirectional electret condenser microphone element
  • 120 dB SPL Maximum input level
  • Connector for 3.5mm mini-plug
  • Secure and comfortably fitting headset

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience crystal-clear audio with this 16-channel UHF wireless microphone system, perfect for presentations.
  • Enjoy freedom of movement with the WM-5325 rechargeable body-pack transmitter and WH-4000H headset microphone.
  • The included WT-5810 tuner ensures a stable wireless connection with a frequency range of 576 to 606MHz.
  • Benefit from a durable headset microphone featuring a unidirectional design for focused sound capture & quality.
  • Achieve optimal sound with a wide audio frequency response of 100 Hz - 15 kHz for natural voice reproduction.
  • This wireless system is ideal for presenters, offering reliable connectivity and exceptional sound performance.

What's in the box:

  • TOA Electronics WT-5810 Tuner
  • WM-5325 Rechargeable Body-Pack Transmitter
  • WH-4000H Headset Microphone
  • Cable
  • Neck Strap
  • TOA Electronics 5 Year Limited Warranty
