8x 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)
1x 10/100/1000 Mbps RJ45 Port
1x Gigabit SFP/RJ45 Combo Port
Auto-Negotiation/Auto MDI/MDIX
Yes
Desktop
Wall Mount
Yes
AC/DC Adapter (Input: 100-240V AC; Output: 53.5V DC/2.43A)
Standard: 802.3af PoE and 802.3at PoE+ compliant
PoE Ports: 8 ports
PoE Budget: 123W available for all PoE+ ports, 30W max per port
PoE Auto Recovery
Up to 820.21' (250m) PoE transmission distance
+/-6kV
4 Mbit
15 KB
20 Gbps
14.88 Mpps
8K
Port-based/802.1p/DSCP QoS
8 Priority Queues
Priority Schedule Mode
WRR (Weighted Round Robin):
Queue Weight Config
Bandwidth Control
Port-Based Rating Limit:
Storm Control
Multiple Control Modes (kbps/pps)
Broadcast/Multicast/Unknown-Unicast Control
802.1ab LLDP
Static Link Aggregation
Loop Prevention / Loopback Detection
Flow Control:
802.3x Flow Control
Mirroring:
Port Mirroring
One-to-One
Many-to-One
Ingress/Egress/Both
Port Statistics:
Port Mirror Status
Traffic Statistics
IGMP Snooping:
IGMP v1/v2/v3 Snooping
Fast Leave
MTU VLAN
Port-Based VLAN
802.1Q Tag VLAN:
Max 32 VLAN Groups
4K VID
Store-And-Forward
Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller
Omada Cloud-Based Controller
Omada Hardware Controller
Omada Software Controller
Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller
Yes. Requires the use of Omada Cloud-Based Controller
Web-based GUI
DHCP Client
Cable Diagnostics
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Unified Configuration
FCC, CE, RoHS
Operating Temperature: 32 Degree F-104 Degree F (0 Degree C-40 Degree C)
Storage Temperature: -40 Degree F-158 Degree F (-40 Degree C-70 Degree C)
Operating Humidity: 10%-90% non-condensing
Storage Humidity: 5%-90% non-condensing
Vietnam
8.2 x 4.9 x 1.02" (209 x 126 x 26mm)
810142820448
Omada Cloud Essentials - A Free and Easy Cloud-Based Network Management
Omada Cloud Essentials is a free, easy-to-use cloud-based management option for the Omada networking system, covering access points, switches, and gateways. It enables simple, centralized network management and monitoring with essential features, making it ideal for surveillance networks and small businesses that don't require the complexity of larger operations.
Exists Entirely in the Cloud. No Hardware or Software Controller Needed
Cloud Centralized Management for Multiple Sites
Access Anytime via Omada App or Web
Easy Setup, Use, and Maintenance
Unlimited Management Scale
Zero-Touch Provisioning (ZTP) without Unboxing
Abundant Functions for Reliable Surveillance Networking
Transmission Distance up to 250m
Priority Video Quality Guaranteed
Secure Traffic Separation via Port Isolation
PoE Auto Recovery
Multiple Application Scenarios
Surveillance: Works with IP Cameras
Wi-Fi Coverage: Works with Access Points
Wired Connections: Works with Non-PoE Devices such as PCs and Printers
