Tascam CG-2000 Video Sync/Master Clock Generator

SKU: TSCG2000 MFR: CG-2000
Earn VIP Reward Points

Key Features

  • Ensure seamless video sync with the CG-2000 Master Clock Generator for broadcast quality.
  • Achieve stable, low latency video output using Tascam's precise clock generation technology.
  • Easily integrate this video sync generator into your existing broadcast or studio setup.
  • Enjoy wide compatibility with various video formats, including 1080p and 720p, for flexibility.
  • Rely on the CG-2000's robust build for a reliable connection in critical video applications.
  • Get good value with this Tascam video master clock, offering high performance at a great price.
See More Product Details
On Backorder?Expected Availability: 08/21/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$129.99

3 Year

$179.99

4 Year

$215.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Tascam CG-2000 Specifications

  • Video Input: Connector

    BNCx2(A/B)

  • Video: Input level

    0.5Vp-p to 2.0Vp-p

  • Video: Input impedance

    75 Ohms (ON/OFF selectable by menu)

  • Video Input: SD video black burst

    NTSC(29.97), NTSC B/W(30), PAL(25)

  • Video Input: 720p

    50, 59.97, 60

  • Video Input: 1080p

    23.976, 24, 25, 29.97, 30, 59.94, 60

  • Video Input: 1080i/psf

    23.976, 24, 25, 29.97, 30

  • Video Input: Allowable freq. deviation

    +/-10ppm

  • Word/Ext Inputs: Connector

    BNCx2(A/B)

  • Word/Ext: Input level

    0.5Vp-p to 5.0Vp-p

  • Word/Ext: Input impedance

    75 Ohms /50 Ohms (75/50/OFF selectable by menu)

  • Word/Ext Input: WORD CLOCK

    32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

  • Word/Ext Input: ATOM

    10.0 MHz

  • Word/Ext Input: GPS

    10.0MHz

  • Word/Ext Input: Allowable freq deviation

    +/-50ppm

  • AES3/11 Input: Connector

    XLR-3-31(1:GND, 2:HOT, 3:COLD)

  • AES3/11: Input level

    0.2Vp-p to 10Vp-p

  • AES3/11: Input impedance

    110 Ohms

  • AES3/11 Input: Format

    AES11-2003, AES3-2003, IEC60958-4

  • AES3/11 Input: Supported frequencies

    32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

  • AES3/11 Input: Allowable freq. deviation

    +/-50ppm

  • Caliblation Input: Connector

    BNC

  • Caliblation: Input level

    0.5 to 5.0 Vp-p

  • Caliblation: Input impedance

    50 Ohms (ON/OFF selectable by menu)

  • Caliblation Input: ATOM

    10.0 MHz

  • Caliblation Input: GPS

    10.0MHz, PPS

  • Video Outputs: Connector

    BNCx4(1-4)

  • Video: Output level

    1.3Vp-p

  • Video: Output impedance

    75 Ohms

  • Video Outputs: SD video black burst

    NTSC(29.97), NTSC B/W(30), PAL(25)

  • Video Outputs: 720p

    50, 59.97, 60

  • Video Outputs: 1080p

    23.976, 24, 25, 29.97, 30, 50, 59.94, 60

  • Video Outputs: 1080i/psf

    23.976, 24, 25, 29.97, 30

  • Word Outputs: Connector

    BNCx12(1-12)

  • Word: Output level

    1.0Vp-p to 3.5Vp-p (adjustable in 0.5V steps by menu)

  • Word: Output impedance

    75 Ohms

  • Word Outputs: Supported frequencies

    32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
    1/4xFs, 1/2xFs, 1xFs, 2xFs, 4xFs, 256xFs (Only OUTPUTS 11-12)

  • AES3/11 Outputs: Connector

    XLR-3-31(1:GND, 2:HOT, 3:COLD)x2(1-2)

  • AES3/11: Output level

    2.5Vp-p

  • AES3/11: Output impedance

    110 Ohms

  • AES3/11 Outputs: Format

    AES11-2003, AES3-2003, IEC60958-4

  • AES3/11 Outputs: Supported frequencies

    32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

  • S/PDIF Outputs: Connector

    RCA pin jacks x2(1-2)

  • S/PDIF: Output level

    0.5Vp-p

  • S/PDIF: Output impedance

    75 Ohms

  • S/PDIF Outputs: Format

    IEC60958-3

  • Alarm Output: Connector

    6-pin Euroblock connector

  • Alarm: Output level

    Open collector

  • Alarm Output: Transmission method

    Parallel

  • Alarm: Output impedance

    10 Ohms

  • Alarm Output: Withstand voltage

    20V

  • Alarm Output: Maximum current

    35mA

  • USB: Connector

    4-pin type B

  • USB: Protocol

    USB2.0 High Speed (480Mbps)

  • USB: Power supply rating

    DC5.0V, 0.2A

  • Internal oscillator Type

    OCXO

  • Internal oscillator: frequency accuracy

    +/-0.01ppm(factory default value)

  • Internal oscillator: frequency stability

    +/-0.005ppm / day

  • Power

    AC100V to 240V, 50/60Hz

  • Power consumption

    14W

  • Operating temperature range

    0 to 40 deg. C / 32 to 104 deg. F

  • Dimensions

    483 x 45 x 310mm / 19.01 x 1.77 x 12.20"

  • Weight

    3.2kg / 7.27lbs

  • UPC Code

    043774030767

About Tascam CG-2000

Key Features

  • Ensure seamless video sync with the CG-2000 Master Clock Generator for broadcast quality.
  • Achieve stable, low latency video output using Tascam's precise clock generation technology.
  • Easily integrate this video sync generator into your existing broadcast or studio setup.
  • Enjoy wide compatibility with various video formats, including 1080p and 720p, for flexibility.
  • Rely on the CG-2000's robust build for a reliable connection in critical video applications.
  • Get good value with this Tascam video master clock, offering high performance at a great price.

What's in the box:

  • Tascam CG-2000 Video Sync/Master Clock Generator
  • 2x Power Cords
  • Rackmounting Screw Kit
  • Operation Manual
  • Tascam Warranty
