33% Off

Tascam Model 12 Integrated Production Suite Mixer/Recorder/USB Interface

SKU: TSMODEL12 MFR: MODEL 12
Earn VIP Reward Points

Key Features

  • Tascam Model 12: Seamless USB interface for effortless computer recording sessions.
  • Achieve pristine audio with low noise circuitry, ideal for critical listening and mixing.
  • Shape your sound precisely using the intuitive channel EQ control for each input.
  • Utilize phantom power for condenser mics, ensuring studio-quality vocal and instrument tracks.
  • Flexible aux sends offer versatile routing for external effects and monitor mixes on stage.
  • This recording mixer is your all-in-one solution for podcasting, music, and live streams.
See More Product Details
Pre Order Now?
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

5 Year

$179.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Learn
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?JOHN L : I'm a composer/producer. Looks like a fantastic product, potentially.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Tascam Model 12 Specifications

Recording Section

Recording Section

Jump to...
  • Supported Media

    SD (512MB to 2GB), SDHC (4GB to 32GB), SDXC (64GB to 512GB)
    Class 10 or higher required.

  • File System

    SD card: FAT16, SDHC card: FAT32, SDXC card: exFAT

  • Recording File Format

    WAV(BWF)

  • Playback Format

    WAV, BWF

  • Sampling Frequency

    44.1k / 48k Hz

  • Bit Depth

    16 / 24 bit

  • Maximum Recordable Channel Number

    12ch (10ch + 2 stereo mix)

Audio Inputs

Jump to...
  • Mic Input

    CH1 to 6, 7/8, 9/10

  • Connector (Mic In)

    XLR 3-31 (1: GND, 2: HOT, 3: COLD, Balanced)

  • Maximum Input Level (Mic In)

    +10dBu

  • Nominal Input Level (Mic In)

    -8dBu

  • Minimum Input Level

    -58dBu

  • Gain Adjustable Range (Mic In)

    0 to 50dB

  • Input Impedance (Mic In)

    1.8k ohm

  • Phantom Power supply

    +48V

  • Line Input

    CH1 to 6, 7/8, 9/10

  • Connector (Line In)

    1/4" (6.3mm) TRS Phone jack (T: HOT, R: COLD, S: GND, Balanced)

  • Maximum Input Level (Line In)

    +22dBu

  • Nominal Input Level (Line In)

    +4dBu

  • Gain Adjustable Range (Line In)

    -10 to +40 dB: CH 1 to 6, -20 to +30 dB: CH 7/8 and 9/10

  • Input Impedance (Line In)

    22k ohm

  • Instrument Input

    CH1 to 6, 7, 9

  • Connector (Inst In)

    1/4" (6.3mm) TS Phone jack (T: HOT, R: GND, S: GND, Unbalanced)

  • Maximum Input Level (Inst In)

    +19.8dBV

  • Nominal Input Level (Inst In)

    +1.8dBV

  • Gain Adjustable Range (Inst In)

    -10 to +40 dB: CH 1 to 6, -20 to +30 dB: CH 7 and 9

  • Input Impedance (Inst In)

    1M ohm

  • Insert

    CH 1 and 2

  • Connector (Insert)

    1/4" (6.3mm) TRS Phone jack (T: Send, R: Return, S: GND)

  • Return (Ring)

    Maximum Input Level: +18dBu
    Nominal Input Level: 0dBu
    Input Impedance: 5k ohm

  • Send (Tip)

    Maximum Output Level: +18dBu
    Nominal Output Level: 0dBu
    Output Impedance: 100 ohm

  • Music/Talk

    CH 9/10

  • Connector (Music/Talk)

    1/8" (3.5mm) TRRS jack (for Smartphone, Unbalanced)

  • Maximum Input Level

    +8dBV

  • Nominal Input Level

    -10dBV

  • Input Impedance

    10k ohm

  • Main Output

    Connector: XLR 3-32 (1: GND, 2: HOT, 3: COLD, Balanced)
    Maximum Output Level: +22dBu
    Nominal Output Level: +4dBu
    Output Impedance: 200 ohm

  • Sub Out, Aux Out

    Connector: 1/4" (6.3mm) TRS Phone jack (T: HOT, R: COLD, S: GND, Balanced)
    Maximum Output Level: +16dBu
    Nominal Output Level: -2dBu
    Output Impedance: 200 ohm

  • Phones Output

    Phones 1 and 2

  • Connector (Phones Out)

    1/4" (6.3mm) Stereo Phone jack

  • Maximum Output Level

    45mW + 45mW (32 ohm loaded)

  • Footswitch

    Compatible with TASCAM RC-1F Foot Switch

  • Connector (Footswitch)

    1/4" (6.3mm) TRS Phone jack

  • Click

    Metronome click

  • Connector (Click)

    1/4" (6.3mm) TRS Phone jack

  • USB Audio

    For connection with PC

  • Connector

    USB Type-C

  • Format

    USB2.0 High-Speed, Mass-storage class/USB Audio Class

  • Sampling Rate

    44.1k / 48k Hz

  • Bit Depth

    16 / 24 bit

  • Maximum Input

    12ch

  • Maximum Output

    10ch

Bluetooth

Jump to...
  • Bluetooth

    to MAIN or CH 9/10

  • Version

    5

  • Output Class

    Class 2 (Transmission range: approx. 33 ft. / 10 m)
    (Transmission range may vary, depending on surroundings)

  • Supported Profile

    A2DP

  • Supported A2DP Codecs

    SBC, AAC

  • A2DP Content Protection

    SCMS-T

Equalizer

Jump to...
  • Channel EQ

    Low-Cut: 100Hz, -12dB / Octave
    Hi-Shelving: +15dB / -15dB, Cut off frequency = 10kHz
    Mid-Peaking
    MONO: +15dB / -15dB, 100Hz to 8kHz Variable
    STEREO: +15dB / -15dB, Center frequency = 600Hz
    MID Band Q Fix, 0.5
    Low-Shelving: +15dB / -15dB, Cut off frequency = 80Hz

  • Master section EQ

    Hi-Shelving+15dB / -15dB, Cut off frequency = 10kHz
    MID-Peaking: +15dB / -15dB, 100Hz to 8kHz Variable, Q: 0.5/5
    Low-Shelving: +15dB / -15dB, Cut off frequency = 60Hz

Effects

Jump to...
  • Internal Effects

    Type: Hall 1
    Hall 2
    Room 1
    Room 2
    Plate
    Studio
    Live
    Delay 1
    Delay 2
    Ping Pong
    Chorus
    Flanger
    Delay + Hall 1
    Delay + Hall 2
    Chorus + Hall 1
    Chorus + Hall 2
    (Fx type and settings can be stored in the library slot)

Audio Performance

Jump to...
  • Frequency Response

    20Hz to 20kHz (+0.5/-0.5 dB, MIC IN to MAIN OUT)

  • S/N ratio

    -103dBu (MAIN OUT, MAIN fader: nominal position)

  • Equivalent Input Noise

    -128dBu (Mono Input Channel, Rs: 150 Ohm, GAIN knob: Max)

  • Total Harmonic Distortion

    0.004% (MIC IN to MAIN OUT, nominal input level, +2dBu, 1kHz, GAIN min.)

  • Crosstalk

    -95dB, channels / input and output
    (1kHz, PAN fully counter clockwise / fully clockwise)

  • Maximum Gain

    74dB (Mic to Main Out)
    50dB (Mic to Insert Out)
    74dB (Mic to Sub Out)
    75dB (Mic to Aux 1/2 Out)
    24dB (USB/SD to main out)
    (EQ flatten, PAN fully counter clockwise / fully clockwise)

Support

Jump to...
  • Supported PC

    Windows
    Compatible Computers: Windows-compatible computer with a USB2.0 port
    CPU: Dual core / 2GHz or faster
    Memory: 2GB or more
    Driver: USB Audio Class 2.0, Model 24 ASIO2.0, WDM (MME)
    Screen Resolution: 1280 x 800 Dots or more

    Mac
    Compatible Computers: Apple Mac computer with a USB 2.0 port
    CPU: Dual core / 2GHz or faster
    Memory: 2GB or more
    Driver: Core Audio
    Screen Resolution: 1280 x 800 Dots or more

  • Supported OS

    Windows: Windows 10 (May 2019 Update) , Windows 8.1 , Windows 7
    Mac: macOS Catalina (New), macOS Mojave, macOS Sierra (10.12)

General

Jump to...
  • Power

    AC 100 to 240V, 50/60Hz

  • Power Consumption

    16W

  • Operating Temperature

    41 to 95 Degree F (5 to 35 Degree C)

  • Dimensions (W x H x D)

    13.5 x 14.2 x 3.96" (343 x 360 x 98.5mm)
    (including knob height and protrusion)

  • Weight

    9.5 lbs (4.3kg)

  • UPC Code

    4907034132034

Related Articles & Videos

Best Instrument Accessories and Gear for Student Musicians

Best Instrument Accessories and Gear for Student Musicians

It's possible to find equipment that is both affordable and exceptional quality! Here is a list of the best instruments for students.
Read more

About Tascam Model 12

Connect. Create. Control.

  • 8 XLR mic inputs (with +48V support) / 10TRS line inputs, 3.5 mm (1/8”)stereo input and Bluetooth® 5.0 input
  • 1-knob compressor and 3 band EQ on all input modules
  • Equipped with 60mm faders
  • Selectable PFL/AFL modes and in-place solo (SIP)
  • Stereo output to MAIN L-R and SUB L-R, monaural send to AUX1 and AUX
  • Dual headphone outputs with individual volume and source selection
  • TASCAM FX equipped
  • Recording function with punch in/out support allows direct SD card 12trackrecording / 10 track playback
  • 12 in / 10 out USB audio interface function (USB Type-C connector)
Connect. Create. Control.

Stream Your Latest Music and Live Performances to Your Fan Base

The Model 12 incorporates several features for podcasting and internet streaming like mix-minus, smartphone input, multiple mic-ready channels, Bluetooth pairing, dual headphone monitoring,and internal multi-track recording. Use the Model 12 as a versatile live production recorder, USB audio interface and live streaming tool.

Stream Your Latest Music and Live Performances to Your Fan Base

All in One Production From Recording to Mastering

The Model 12’s seamless integrated workflow facilitates less focus on the technical and more on the creative. The comfortable, familiar feel of the Model 12’s 60mm faders and1-knob compressor, 3-band EQ, and TASCAM’s high-quality reverb effects allow fast tweaking of mixes and tones.

All in One Production From Recording to Mastering

Pristine Audio Quality

TASCAM’s Ultra-HDDA (High Definition Discrete Architecture) mic preamps with EIN(Equivalent Input Noise) of-128dB ensure natural low noise and high-grade sound quality. Additionally, Hi-Z line level inputs are included on all channels for direct instrument input.

Pristine Audio Quality

Compact Size with Plenty of Inputs

The compact Model 12 packs 8 XLR mic inputs (with +48V support), 10 TRS line inputs, a3.5mm (1/8”) TRRS input (for Smartphone) and Bluetooth 5.0 input to handle any small format recording or live production environment.

Compact Size with Plenty of Inputs

Versatile Routing for Perfecting Your Mix

Selectable PFL/AFL modes and solo in place (SIP) allow for flexible monitoring of individual channels, eliminating the need to mute each single channel when dialing in the perfect mix.

Versatile Routing for Perfecting Your Mix

Dual Headphone Monitor

Top-panel accessible dual headphone jacks allow monitoring of two discrete headphone mixes simultaneously for performers and engineers alike.

Dual Headphone Monitor

Key Features

  • Tascam Model 12: Seamless USB interface for effortless computer recording sessions.
  • Achieve pristine audio with low noise circuitry, ideal for critical listening and mixing.
  • Shape your sound precisely using the intuitive channel EQ control for each input.
  • Utilize phantom power for condenser mics, ensuring studio-quality vocal and instrument tracks.
  • Flexible aux sends offer versatile routing for external effects and monitor mixes on stage.
  • This recording mixer is your all-in-one solution for podcasting, music, and live streams.

What's in the box:

  • Model 12 Integrated Production Suite Mixer/Recorder/USB Interface
  • AC Adapter
  • Owner's Manual
  • Tascam 1 Year Limited Warranty
